Каталог запчастей рефрижераторов Carrier CitiMax 1000/1100
1 | 86-69054-00 NSI | FRAME, ASSY |
2 | 67-67405-00 | BRACKET |
3 | 58-69068-00 | SKIN, LEFT |
4 | 58-69069-00 | SKIN, RIGHT |
5 | 58-69067-00 | SKIN, FRONT |
6 | 62-60390-02 | DECAL, CARRIER175X70 |
7 | 62-69087-07 | LABEL, CITIMAX 1100 |
8 | 34-60044-03 PL* | SCREW, M6X20 |
9 | 58-60681-00 PL* | WASHER M6X30 |
10 | 42-69097-00 | FOAM |
11 | 42-00183-21 | TRIM, FLEXIBLE |
5 | 08-66887-00 | MCHE |
10 | 42-69085-07 | FOAM，t=6mm |
15 | 34-01152-25PL | BOLT, M6X25mm |
20 | 34-60095-27PL | WASHER, FLAT,M6 |
25 | 34-01146-06PL | WASHER, LOCK,M6 |
30 | 58-60298-03 | GROMMET |
35 | 34-60206-16PL | SCREW, M6X16mm |
40 | 42-69085-06 | FOAM，t=7mm |
45 | 67-67407-00 | FAN DECK |
50 | 62-61335-00 | DECAL, WARNING |
55 | 54-00737-01 | FAN & MOTOR, 24V |
60 | 73-66801-00 | GRILLE |
65 | 34-01152-35 | SCREW, M6X35MM |
70 | 34-60095-27 | WASHER, LOCK,M6 |
71 | 58-05100-00 | STA-STRAP (10 FOR BASIC,12 FOR LA) |
75 | 44-60121-00 | BRACKET, CLAMP |
80 | 58-60756-00 | CAP, 3/8” |
85 | 14-01092-06 | INDICATOR |
90 | 42-00243-09 | O-RING |
95 | 62-69083-01 | DECAL |
100 | 14-00326-03 | FILTER DRIER |
105 | 44-60009-03 | CLAMP, 3-1/8-4O.D. |
110 | 81-69060-00 | TUBE ASSY,LIQ，3/8”– INCLUDES: |
115 | 40-60009-02 | SWIVEL NUT，3/8” |
120 | 40-60008-02 | NIPPLE，3/8” |
125 | 40-60004-00 | CAP, 1/4” |
130 | 40-60159-01 | FITTING 1/4” |
135 | 40-60087-00 | VALVE 1/4” |
140 | 44-60044-03 | CLAMP, 3/8” |
145 | 56-69385-00 | TUBE,LIQUID，3/8” |
150 | 56-69386-00 | TUBE，3/8" |
155 | 34-60089-06 PL | NUT, LOCK M6 |
160 | 65-66819-00 | RECEIVER |
165 | 58-69027-00 | CAP, 13/16-16 |
170 | 42-00243-04 | O-RING |
175 | 62-69083-00 | DECAL |
180 | 81-69057-00 | TUBE ASSY, LIQ – INCLUDES: |
184 | 56-69384-00 | TUBE 1/2” |
185 | 40-60169-03 | FITTING |
190 | 22-69262-01 | HGV COIL, 24V |
195 | 22-69275-00 SK | CONNECTOR (1FORBASIC, 2 FOR LA) |
200 | 14-00475-00 | VALVE, HGV |
201 | 34-60000-25 | SCREW M5×25MM (1 FOR BASIC; 3 FOR LA) |
202 | 34-01151-05 | WASHER, FLAT,M5(1 FOR BASIC;3 FOR LA) |
203 | 34-01146-05 | WASHER, LOCK,M5(1 FOR BASIC;3 FOR LA) |
205 | 56-69388-00 | TUBE 3/8”(ONLY FOR BASICUNIT) |
210 | 82-66860-00 | TUBE – INCLUDES: (ONLYFOR BASIC UNIT) |
215 | 40-60009-04 | SWIVEL NUT，5/8” |
220 | 40-60008-04 | NIPPLE，5/8” |
225 | 56-69387-00 | TUBE, HOT GAS (ONLYFOR LA UNIT) |
230 | 42-00243-03 | O-RING (3 FOR BASIC;5 FOR LA) |
235 | 22-69271-01 | MHV COIL,24V (ONLY FOR LA UNIT) |
240 | 14-00474-00 | VALVE, MHV |
245 | 82-66859-00 | TUBE– INCLUDES: (ONLYFOR LA UNIT) |
250 | 40-60009-04 | SWIVEL NUT，5/8” |
255 | 40-60008-04 | NIPPLE，5/8” |
260 | 82-66858-00 | TUBE– INCLUDES: (ONLYFOR LA UNIT) |
265 | 40-60009-04 | SWIVEL NUT，5/8 |
270 | 40-60008-04 | NIPPLE，5/8” |
300 | 12-00694-02 | HP1 SWITCH SECURITY |
305 | 12-00694-04 | HP2 SWITCH CONTROL(ONLY FOR C1000 UNIT) |
310A | 81-69058-01 | TUBE ASSY,5/8(ONLY FOR C1000) – INCLUDES: |
310B | 81-69058-00 | TUBE ASSY,5/8(ONLY FOR C1100) – INCLUDES: |
315 | 40-60009-04 | SWIVEL NUT，5/8” |
320 | 40-60008-04 | NIPPLE，5/8” |
325 | 40-69159-01 | FITTING 1/4”– INCLUDES: |
330 | 40-60087-00 | VALVE 1/4” |
335 | 40-60169-05 | FITTING |
340 | 62-69083-03 | DECAL，ROAD DISCHARGE LINE |
345 | 81-69059-00 | TUBE ASSY,OIL, 1/4” – INCLUDES: |
350 | 40-60009-01 | SWIVEL NUT |
355 | 40-60008-01 | NIPPLE，1/4” |
365 | 40-60169-14 | FITTING |
370 | 42-00243-10 | O-RING |
375 | 62-69083-05 | DECAL，OIL RETURN LINE |
385 | 65-66808-02 | OIL SEPARATOR |
10 | 79-69018-00 | EVAPORATOR ASSY (FORLA UNIT) |
10B | 79-69018-01 | EVAPORATOR ASSY (FOR BASICUNIT) |
11 | NSS | COIL ASSY -- INCLUDES: |
11A | 40-60159-00 | FITTING, 1/4”-- INCLUDES: |
NS | 40-60087-00 | VALVE, 1/4”: |
11B | 40-60004-00 | PLUG, 1/4” |
12 | 81-69064-00 | DEFROST TUBE-- INCLUDES: |
12A | 40-60007-03 | FITTING, 1/2” |
13 | 68-70481-01 | BRACKET |
14 | 68-70482-00 | BRACKET |
15 | 67-67408-00 | BRACKET (ONLYFOR LA UNIT) |
16 | 68-69401-00 | BRACKET (ONLYFOR LA UNIT) |
17 | 68-69604-00 | BRACKET |
20 | 14-00445-02 | EXPANSION VALVE |
30 | 22-02973-06 | SENSOR |
40 | 14-00446-00 | INJECTION VALVE(ONLY FOR LA UNIT) |
50 | 22-69270-01 | COIL, 24V (ONLY FOR LA UNIT) |
60 | 14-00205-01 | VALVE (ONLYFOR LA UNIT) |
70 | 12-00695-01 | LOW PRESSURE SWITCH - INCLUDES: |
NS | 22-02392-00 | SK CONNECTOR 2 WAYS |
|
| (MATES WITH22-01585-00SK) |
80 | NSA | SKIN ASSY - INCLUDES: |
81 | 58-69066-00 | TOP SKIN |
82 | 58-69064-00 | SIDE SKIN |
83 | 58-69065-00 | SIDE SKIN |
84 | 58-60399-00 | FITTING |
85 | 42-60042-01 | GASKET |
86 | 58-60401-00 | NUT, M20 X 1.5MM |
87 | 54-00737-01 | FAN & MOTOR, 24V- INCLUDES: |
87A | 22-50078-02 | SK EFM CONNECTOR 2 WAYS |
|
| ((MATES WITH 22-50078-01SK) |
88 | 34-60238-30 | SCREW |
89 | 58-60298-01 | GROMMET |
90 | 62-60390-02 | DECAL, CARRIER 105X42 |
100A | 22-69319-00 | HARNESS (ONLY FOR BASIC UNIT) - INCLUDES: |
100B | 22-69319-01 | HARNESS (ONLY FOR LA UNIT) - INCLUDES: |
101 | 22-01585-00 | SK LP CONNECTOR 2 WAYS |
102 | 22-50078-58F | TERMINAL, FEMALE |
103 | 22-50078-59D | SEAL |
104 | 22-60248-04 | TERMINAL, FEMALE(ONLY FOR LA UNIT) |
105 | 22-60252-30 | INSULATION (ONLYFOR LA UNIT) |
106 | 22-50098-58 | CONNECTOR, MALE |
107 | 22-02393-01 | TERMINAL, MALE |
108 | 22-02394-03 | SEAL |
109 | 22-50078-55 | PLUG, RUBBER(ONLY FOR BASICUNIT) |
110A | 81-69061-00 | TUBE ASSY (ONLY FOR LA UNIT) |
110B | 81-69061-01 | TUBE ASSY (ONLY FORBASIC UNIT) |
120 | 81-69067-00 NSI | TUBE ASSY (M) -INCLUDES: |
121 | 56-69413-00 | TUBE |
122 | 56-69389-00 | TUBE，BALANCE TUBE |
130 | 08-60036-01 | HEAT EXCHANGER |
140A | 56-69391-00 | TUBE (ONLY FOR LA UNIT) |
140B | 56-69408-00 | TUBE (ONLY FOR BASICUNIT) |
150 | 56-69390-00 | TUBE (ONLY FOR LA UNIT) |
160 | 56-69392-00 | TUBE (ONLY FOR LA UNIT) |
170 | 81-69062-00 NSI | TUBE ASSY (ONLY FOR LA UNIT) |
180 | 81-69066-00 NSI | TUBE ASSY (ONLY FOR BASIC UNIT) |
190 | 81-69063-00 NSI | TUBE ASSY(ONLY FOR LA UNIT M) - INCLUDES: |
191 | 56-69395-00 | TUBE |
192 | 14-00444-00 | CHECK VALVE (ONLYFOR LA UNIT) |
193 | 56-69396-00 | TUBE |
200 | 56-69410-00 NSI | TUBE (ONLY FOR BASICUNIT) |
210 | 44-60041-75 | CLAMP |
220 | 44-60041-69 | CLAMP |
230 | 44-00293-22 | CLAMP, 1-5/16” |
240 | 44-00293-24 | CLAMP,1-1/2” (2 FOR LA 3 FOR BASIC) |
250 | 44-60121-00 | CLAMP |
255 | 34-60068-20 | SCREW, M6 X 20MMLG |
256 | 42-69104-00 | MOUSSE ADHSIVE |
260 | 42-00243-09 | O-RING, 3/8” |
270 | 42-00243-11 | O-RING |
280 | 42-00243-04 | O-RING, 1/2” |
290 | 58-60756-00 | CAP, 3/8” |
300 | 58-60734-00 | CAP |
310 | 58-69027-00 | CAP, 13/16-16 |
320 | 42-69098-00 | FOAM |
330 | 42-69098-01 | FOAM |
340 | 58-60264-06 | TUBE WATER, 6M, CUT TO LENGTH |
350 | 34-60206-16 PL | SCREW, M6X16MM |
|
| (3 FOR LA, 2 FOR BASIC) |
360 | 34-60206-12 PL* | SCREW, M6X12MM (ONLY FOR LA UNIT) |
370 | 34-01152-25 PL* | BOLT, M6X25mm |
380 | 34-60095-27 PL* | WASHER, LOCK,M6 |
390 | 42-00032-00 | INSULATION |
400 | 58-01284-00 | TUBE, HEAT |
410 | 62-60870-01 | DECAL, 24VDC |
420 | 62-69083-00 | DECAL, DEFROST LINE |
430 | 62-69083-01 | DECAL，LIQUID LINE |
440 | 62-69083-02 | DECAL，SUCTION LINE |
450 | 62-61478-00 | DECAL, WARNING BURN RISK |
460 | 42-60044-01 | CEMENT |
470 | 62-60063-00 | DECAL, REFRIGERANT |
| 22-69318-00 | HARNESS (C1100BASIC) – INCLUDES: |
| 22-69318-02 | HARNESS (C1100 LA) – INCLUDES: |
| 22-69318-10 | HARNESS (C1000BASIC) – INCLUDES: |
| 22-69318-12 | HARNESS (C1000 LA) – INCLUDES: |
10 | 22-60275-11 | CONNECTOR 2 WAYS MALE |
20 | 22-60275-03 | CONNECTOR, FEMALE(BASIC) |
|
| (5 FOR BASIC, 10 FOR LA) |
30 | 22-69255-00 | CONNECTOR 4 WAYS MALE |
40 | 22-69255-20 | CONNECTOR FEMALE12-14 AWG |
50 | 22-69255-01 | CONNECTOR 6 WAYS MALE |
60 | 22-60300-08 | CONNECTOR 9 WAYS MALE |
70 | 22-60300-22 | CONNECTOR, FEMALE |
|
| (3 FOR BASIC, 7 FOR LA) |
80 | 22-60275-14 | CONNECTOR 6W |
90 | 22-60244-20 | CONNECTOR 16mm2Ȼ6 |
100 | 22-60244-19 | CONNECTOR 16mm2Ȼ5 |
110 | 58-69035-00 | CAP |
120 | 22-60254-08 | CONNECTOR 4 WM |
130 | 22-60254-26 | FEMALE TERMINAL |
140 | 22-60254-27 | FEMALE TERMINAL |
150A | 22-69275-00 | CONNECTOR, HGV/MHV(LA) |
150B | 22-69275-00 | CONNECTOR, HGV (BASIC) |
160 | 22-50078-02 | CONNECTOR, FEM |
170 | 22-50078-01A | LOCK (9 FOR C1100, 10 FOR C1000) |
180 | 22-50078-47D | TERMINAL, FEMALE |
190 | 22-02394-03 | SEAL (12 FORBASIC, 14 FORLA) |
200A | 22-50078-01 | CONNECTOR, FOR FAN(C1100) |
200B | 22-50078-01 | CONNECTOR, FORFAN & HP2 (C1000) |
210 | 22-50078-47B | TERMINAL, MALE |
220 | 22-02394-02 | SEAL |
230 | 22-50098-57 | CONNECTOR, FEM |
240 | 22-50078-58F | TERMINAL, FEMALE |
|
| (2 FOR BASIC, 4 FOR LA) |
250 | 22-50078-55 | PLUG, RUBBER(ONLY FOR BASIC UNIT) |
260 | 22-60313-03 | FUSE HOLDER |
270 | 22-02336-01 | FUSE 20A |
280 | 22-50078-47A | TERMINAL, MALE(ONLY FOR C1000) |
| 22-69320-00 | HARNESS– INCLUDES: |
300 | 22-60254-09 | CONNECTOR, 4 WAYS FEM |
310 | 22-60254-30 | MALE TERMINAL |
320 | 22-60254-29 | MALE TERMINAL |
330 | 22-50098-01 | SOCKET, BASEFOR RELAY |
340 | 22-50098-02A | TERMINAL, FEMALE |
350 | 22-50098-03B | TERMINAL, FEMALE |
5A | 12-66815-08 | LOGIC BOARD (24VDC, C1100)- INCLUDES: |
5B | 12-66815-10 | LOGIC BOARD (24VDC, C1000)- INCLUDES: |
10 | 22-02336-01 | FUSE 20A，EVAPORATORFAN MOTOR |
15 | 22-02336-01 | FUSE 20A，CONDENSERFAN MOTOR |
20 | 22-02336-08 | FUSE 7.5A，LOGIC BOARD |
30A | 12-00507-05 | THERMOSTAT (ONLYFOR C1100 LA UNIT) |
30B | 12-00507-01 | THERMOSTAT (ONLYFOR C1000 LA UNIT) |
35 | 10-00385-10 | RELEAY |
40 | 12-66816-00 | CAB COMMAND- INCLUDES: |
80 | 44-60024-25 | STA-STRAP |
90 | 22-69250-01 | CABLE FORCAB, COMMAND 10M |
100A | 22-69318-00 | HARNESS (ONLY FORC1100 BASIC UNIT) |
100B | 22-69318-02 | HARNESS (ONLY FORC1100 LA UNIT) |
100C | 22-69318-10 | HARNESS (ONLY FORC1000 BASIC UNIT) |
100D | 22-69318-12 | HARNESS (ONLY FORC1000 LA UNIT) |
110 | 34-66895-05 | NUT, HEX M5 |
120 | 34-66895-06 | NUT, HEX M6 |
130 | 42-00183-21 | TRIM, FLEXIBLE |
140 | 44-60024-09 | STA-STRAP |
10 | 62-61478-00 | DECAL, WARNING BURN RISK |
20 | 62-69083-00 | DECAL, DEFROST |
30 | 62-69083-01 | DECAL，LIQUID LINE |
40 | 62-69083-02 | DECAL，SUCTION LINE |
50 | 62-69083-03 | DECAL，ROAD DISCHARGE LINE |
60 | 62-69083-05 | DECAL，OIL RETURN LINE |
80 | 62-61335-00 | DECAL, MAIN R404A |
90 | 62-60390-02 | DECAL, CARRIER105X42 |
95 | 62-60390-03 | DECAL, CARRIER175X70 |
100 | 62-60870-01 | DECAL，24VDC |
110 | 62-60063-00 | DECAL，R404A |
120 | 62-69087-07 | LABEL，CITIMAX 1100 |
130 | 62-69087-12 | LABEL，CITIMAX 1000 |
140 | 62-60764-01 | DECAL |
150 | 62-61774-00 | DECAL |
1 | 77-69189-00 | HOSE KIT |
5 | 44-66821-00 | CLAMP |
6 | 44-66820-00 | CLAMP, DN22 |
7A | 44-66815-02 | CLAMP, DN16.1(C1100) |
7B | 34-69001-12 | CLAMP, DN12.7(C1000) |
8 | 44-66815-01 | CLAMP, DN10.7 |
9 | 44-66815-00 | CLAMP, DN8.0 |
10 | 34-66897-05 | SCREW, M3 |
|
| (15 FOR C1100 UNIT,20 FOR C1000UNIT) |
10A | 34-66899-00 | WASHER, LOCK, M3 |
|
| (15 FOR C1100 UNIT,20 FOR C1000UNIT) |
11 | 40-69076-04 | TEE,180° |
12A | 40-69074-03 | 5/8 ORFS DN16.1，90°(C1100) |
12B | 40-69074-02 | 5/8 ORFS DN16.1，90°(C1000) |
13 | 40-69073-05 | FITTING, 1/2ORFS 135° |
14 | 40-69074-00 | FITTING, 3/8ORFS 90° |
15 | 40-69074-01 | FITTING, 1/4ORFS 90° |
16 | 58-69070-00 | HOSE ASSY, DN22, 6.5M(C1100) - INCLUDES: |
16A | 40-69137-05 | FITTING, 3/4 ORP 180° |
16B | 40-69136-05 | FITTING, 3/4 ORP 90° |
16 | 58-69070-04 | HOSE ASSY, DN22, 6.5M(C1000) - INCLUDES: |
16A | 40-69137-06 | FITTING, 5/8 ORP 180° |
16B | 40-69136-05 | FITTING, 3/4 ORP 90° |
17 | 58-69070-01 | HOSE ASSY, DN16.1, 5M (C1100)- INCLUDES: |
17A | 40-69137-02 | FITTING, 5/8 ORP 180° |
18 | 58-69070-02 | HOSE ASSY, DN8.0, 6M - INCLUDES: |
18A | 40-69136-00 | FITTING, 3/8 ORFS 90° |
18B | 40-69136-01 | FITTING, 1/4 ORFS 90° |
19 | 58-69070-03 | HOSE ASSY, DN10.7, 2M - INCLUDES: |
19A | 40-69136-06 | FITTING, 1/2 ORFS 90° |
20 | 58-69052-12 | HOSE，DN12.7，6M (C1000) |
21 | 40-69131-42 | FITTING, 1/2 (C1000) |
22 | 40-69077-00 | FITTING, 1/2 ORP 90°(C1000) |
23 | 40-69077-01 | FITTING, 5/8 ORP 90°(C1000) |
24 | 40-69076-05 | TEE, DN12.7 (C1000) |
© All Rights Reserved
refxolod.ru
