Каталог запчастей рефрижераторов Carrier CitiMax 500/700
1A | 86-69005-00 NSI | FRAME, ASSY(ONLY FOR S- CONTROLLER UNITS) PRIOR UNIT S/N RKL94096676 |
1B |
86-69005-10 NSI | FRAME, ASSY (ONLY FOR H- CONTROLLER UNITS) STARTING UNIT S/N RKL94096676 ( include 10 pcs MCS from RKG94080884 to RKG94080893) |
2 | 58-69024-01 | PANEL, ROADSIDE |
3 | 58-69021-01 | PANEL, CURBSIDE |
4 | 58-69025-01 | COVER,FRONT |
5 | 58-69026-00 | FOAM |
6 | 67-66812-00 NSI | BRACKET |
7 | 62-61335-00 | DECAL， R404A |
7 | 62-61335-01 | DECAL， R134a (ONLYFOR R134a UNITS) |
8 | 34-60044-03 PL* | SCREW RLX M6 |
9 | 62-69087-01 | LABEL,CITIMAX 500 |
10 | 62-60390-03 | DECAL, CARRIER |
11 | 34-60068-20 PL* | SCREW,CAPTWASH |
11 | 34-60068-20 PL* | SCREW,CAPT WASH(ONLY FOR MHV UNITS) |
12 | 86-69004-00 NSI | CROSS BAR |
13 | 58-60681-00 | WASHER, M6X30MM |
14 | 67-66832-00 NSI | BRACKET (ONLYFOR MHV UNITS) |
5 | 65-66808-00 | OIL SEPERATOR |
10 | 34-60068-20 PL* | SCREW,CAPTWASH |
15 | 42-00243-03 | O-RING 5/8 |
20 | 42-00243-10 | O-RING 1/4 |
25 | 82-66805-00 NSI | TUBE, OIL - INCLUDES: |
26 | 40-60008-01 | NIPPLE |
27 | 40-60009-01 | SWIVEL NUT |
30 | 12-00694-03 | HP2 SWITCH CONTROL (ONLYFOR R404A UNITS) |
30 | 12-00694-01 | HP2 SWITCH CONTROL (ONLYFOR R134a UNITS) |
NS | 22-50078-01 SK | CONNECTOR 2 WAYS ( MATES WITH 22-50078-02SK ) |
NS | 22-50078-01A SK | SECONDARYLOCK |
31 | 40-60087-00 | VALVE 1/4 |
35 | 12-00694-02 | HP1 SWITCH SECURITY (ONLYFOR R404A UNITS) |
35 | 12-00694-00 | HP1 SWITCH SECURITY (ONLYFOR R134a UNITS) |
NS | 22-50078-01SK | CONNECTOR 2 WAYS ( MATES WITH 22-50078-02SK ) |
NS | 22-50078-01A SK | SECONDARYLOCK |
40 | 12-00695-01 | LPS SWITCH (ONLY FOR R404A UNITS) |
40 | 12-00695-00 | LPS SWITCH (ONLY FOR R134a UNITS) |
NS | 22-02392-00 SK | CONNECTOR2 WAYS ( MATES WITH 22-01585-00SK ) |
45 | 65-66809-00 | ACCUMULATOR (ONLYFOR R134a UNITS) |
50A | 56-69272-00 NSI | TUBE, ACCU (ONLY FOR R134a UNITS) |
55 | 81-66843-00 NSI | TUBE, ACCU - INCLUDES(ONLY FOR R134a UNITS): |
55 | 81-66868-00 | TUBE, ACCU - INCLUDES(ONLY FORR404A UNITS): |
56 | 40-60169-06 | FITTING |
60 | 42-00243-11 | O-RING |
70 | 34-60206-16 PL* | VIS H M6 |
75 | 62-69083-02 | DECAL SUCTIONLINE |
80 | 34-00944-10 PL* | WASHER, CONIC(ONLY FOR R134aUNITS) |
85 | 34-00945-10 PL* | WASHER, LOCK(ONLY FOR R134aUNITS) |
90 | 34-00363-13 PL* | NUT, HEX (ONLY FOR R134a UNITS) |
95 | 14-60000-03 | CPR (ONLY FOR R404AUNITS) |
100 | 81-66858-00 NSI | SUCT TUBE ASSY- INCLUDES: |
101 | 40-60169-06 | FITTING |
102 | 40-60159-01 | VALVE, 1/4 SCHRADER |
105 | 62-69083-03 | DECAL ROADDISCHARGE LINE |
110 | 62-69083-04 | DECAL ROADSUCTION LINE |
5 | 65-66808-00 | OIL SEPERATOR |
10 | 34-60068-20 PL* | SCREW,CAPTWASH |
15 | 42-00243-03 | O-RING 5/8 |
20 | 42-00243-10 | O-RING 1/4 |
25 | 82-66805-00 NSI | TUBE, OIL - INCLUDES: |
26 | 40-60008-01 | NIPPLE |
27 | 40-60009-01 | SWIVEL NUT |
30 | 12-00694-03 | HP2 SWITCH CONTROL (ONLYFOR R404A UNITS) |
30 | 12-00694-01 | HP2 SWITCH CONTROL (ONLYFOR R134a UNITS) |
NS | 22-50078-01 SK | CONNECTOR 2 WAYS ( MATES WITH 22-50078-02SK ) |
NS | 22-50078-01A SK | SECONDARYLOCK |
31 | 40-60087-00 | VALVE 1/4 |
35 | 12-00694-02 | HP1 SWITCH SECURITY (ONLYFOR R404A UNITS) |
35 | 12-00694-00 | HP1 SWITCH SECURITY (ONLYFOR R134a UNITS) |
NS | 22-50078-01 SK | CONNECTOR 2 WAYS ( MATES WITH 22-50078-02SK ) |
NS | 22-50078-01A SK | SECONDARYLOCK |
40 | 12-00695-01 | LPS SWITCH (ONLY FOR R404A UNITS) |
40 | 12-00695-00 | LPS SWITCH (ONLY FOR R134a UNITS) |
NS | 22-02392-00 SK | CONNECTOR2 WAYS ( MATES WITH 22-01585-00SK ) |
45 | 65-66809-00 | ACCUMULATOR (ONLYFOR R134a UNITS) |
50A | 56-69272-00 NSI | TUBE, ACCU (ONLY FOR R134a UNITS) |
55 | 81-66843-00 NSI | TUBE, ACCU - INCLUDES(ONLY FOR R134a UNITS): |
55 | 81-66868-00 | TUBE, ACCU - INCLUDES(ONLY FORR404A UNITS): |
56 | 40-60169-06 | FITTING |
60 | 42-00243-11 | O-RING |
70 | 34-60206-16 PL* | VIS H M6 |
75 | 62-69083-02 | DECAL SUCTIONLINE |
80 | 34-00944-10 PL* | WASHER, CONIC(ONLY FOR R134aUNITS) |
85 | 34-00945-10 PL* | WASHER, LOCK(ONLY FOR R134aUNITS) |
90 | 34-00363-13 PL* | NUT, HEX (ONLY FOR R134a UNITS) |
95 | 14-60000-03 | CPR (ONLY FOR R404AUNITS) |
100 | 81-66858-00 NSI | SUCT TUBE ASSY- INCLUDES: |
101 | 40-60169-06 | FITTING |
102 | 40-60159-01 | VALVE, 1/4 SCHRADER |
105 | 62-69083-03 | DECAL ROADDISCHARGE LINE |
110 | 62-69083-04 | DECAL ROADSUCTION LINE |
232 | 40-60009-02 | SWIVEL NUT |
233 | 40-60169-02 | FITTING |
235 | 14-01092-06 | SIGHT GLASS |
240 | 44-60009-03 | CLAMP |
245 | 14-00326-03 | FILTER DRIER |
250 | 82-66804-00 PL | TUBE,LIQUID – INCLUDES: |
251 | 40-60008-02 | NIPPLE |
252 | 40-60009-02 | SWIVEL NUT |
255 | 54-00639-17 | MOTOR,12VDC – INCLUDES: |
255 | 54-00639-16 | MOTOR,24VDC – INCLUDES: |
256 | 54-00639-34 | BRUSH |
257 | 54-60006-31 | BRUSH CAP |
258 | 22-50078-02 SK | CONNECTOR2 WAYS(MATES WITH22-50078-01SK) |
260 | 48-60237-00 | HEAT SINK |
265 | 34-60000-25 PL* | 6MM HEX HEAD SCREW |
270 | 34-60089-05 PL* | NUT, LOCK |
275 | 34-60095-25 PL* | NUT |
280 | 73-60049-01 | FAN, GRILLE |
285 | 38-00613-00 | FAN BLADE CONDERSER |
290 | 58-04316-00 | BASE, MOUNTING |
295 | 62-60870-00 | DECAL,12V |
295 | 62-60870-01 | DECAL,24V |
300 | 67-66811-00 NSI | FAN BOX |
305 | 08-66871-00 | MCHE |
310 | 82-66803-00 PL | TUBE,DISCHARGE – INCLUDES: |
310A | 82-66808-00 PL | TUBE,DISCHARGE (ONLYFOR MHV UNITS)–INCLUDES: |
311 | 40-60008-03 | NIPPLE |
312 | 40-60009-03 | SWIVEL NUT |
313 | 40-60159-01 | VALVE, 1/4 SCHRADER |
315 | 34-60068-16 PL* | SCREW,CAPTWASH |
325 | 44-60044-01 | CLAMP |
330 | 42-00424-22 | SEAL |
335 | 42-00424-23 | SEAL |
340 | 14-00276-00 | VALVE SOLENOID ( ONLY FORMHV UNITS ) |
NS | 14-00276-10 | REPAIR KIT |
345 | 56-69271-00 PL | TUBE,CONDENSER ( ONLY FOR MHV UNITS) |
10 | 62-60063-00 | DECAL, R404A |
15 | 62-60870-00 | DECAL12V |
15 | 62-60870-01 | DECAL24V |
20 | 42-60007-13 | INSULATION |
25 | 62-61477-00 | DECAL CUTING RISK |
30 | 62-69083-02 | DECAL SUCTION LINE |
35 | 62-69083-01 | DECAL LIQUID LINE |
40 | 62-69083-00 | DECAL HOT GAS LINE |
45 | 42-00243-09 | O-RING |
50 | 42-00243-11 | O-RING |
55 | 58-60393-02 PL | FITTING COVER |
60 | 58-60734-00 PL | FITTING COVER |
65 | 44-00293-22 | CLAMP |
70 | 34-60068-16 PL* | SCREW,CAPTWASH |
75 | 38-00605-00 | FAN BLADE, EVAPORATOR |
80 | 54-00639-14 | MOTOR,DC 12V– INCLUDES: |
80 | 54-00639-15 | MOTOR,DC 24V– INCLUDES: |
81 | 54-60639-31 | CAP,BRUSH HOLDER |
82 | 54-00639-32 | BRUSH |
83 | 22-50078-02 SK | CONNECTOR2 WAYS(MATESWITH 22-50078-01SK) |
155 | 34-60000-16 PL* | SCREW,MACH HEHD |
160 | 34-60095-25 PL* | WASHER |
165 | 34-01184-05 PL* | NUT,LOCK |
185 | 58-60298-03 | GROMMET |
190A | 14-00273-21 | VALVE,EXPANSION(ONLY FOR STAINLESS STEEL TXV UNITS) STARTING UNIT S/N PKN94055789 |
190 | 14-60039-00 | VALVE,EXPANSION(ONLY FOR COPPERTXV UNITS) PRIOR UNIT S/N PKN94055788 |
195 | 14-60009-03 | ORIFICE (ONLYFOR COPPER TXV UNITS) PRIORUNIT S/N PKN94055788 |
200 | 42-00032-00 | INSULATION |
210 | 58-01284-00 | TUBE,HEATSHRNK |
215 | 79-66886-00 | EVAPORATOR ASSY– INCLUDES: |
225 | 86-69008-00 | DRAIN PAN ASSY – INCLUDES: |
226 | 56-60790-06 NSS | TUBE,STRAIGHT |
245 | 68-69327-00 NSI | ANGLE |
250 | 08-66865-00 NSS | COILASSY,EVAP |
255 | 67-66822-00 NSI | COVER |
260 | 67-66823-00 NSI | COVER |
265 | 68-70482-00 | BRIDE DISTRI |
270 | 68-70481-00 | SUPPORT DISTRIBUTEUR |
275 | 81-66852-00 NSS | DISTR ASSY– INCLUDES: |
276 | 48-69013-00 NSS | DISTRIBUTOR |
277 | 56-69257-00 NSS | TUBE,DISTR |
278 | 56-69256-00 NSS | TUBE COPPER (ONLY FOR COPPER TXV UNITS) PRIOR UNIT S/N PKN94055788 |
278A | 56-69256-01 NSS | TUBE COPPER (ONLY FOR STAINLESS STEEL TXV UNITS) STARTING UNIT S/N PKN94055789 |
280 | 81-66850-00 NSS | SUCT LINE ASSY – INCLUDES: |
281 | 40-60004-00 | CAP |
282 | 40-60006-00 | ELBOW 90* ¼ SCHRADER |
283 | 56-69253-00 NSS | TUBE,EQUALIZER |
155 | 34-60000-16PL* | SCREW,MACH HEHD |
160 | 34-60095-25 PL* | WASHER |
165 | 34-01184-05 PL* | NUT,LOCK |
185 | 58-60298-03 | GROMMET |
190A | 14-00273-21 | VALVE,EXPANSION(ONLY FOR STAINLESS STEEL TXV UNITS) STARTING UNIT S/N PKN94055789 |
190 | 14-60039-00 | VALVE,EXPANSION(ONLY FOR COPPERTXV UNITS) PRIOR UNIT S/N PKN94055788 |
195 | 14-60009-03 | ORIFICE (ONLYFOR COPPER TXV UNITS) PRIORUNIT S/N PKN94055788 |
200 | 42-00032-00 | INSULATION |
210 | 58-01284-00 | TUBE,HEATSHRNK |
215 | 79-66886-00 | EVAPORATOR ASSY– INCLUDES: |
225 | 86-69008-00 | DRAIN PAN ASSY – INCLUDES: |
226 | 56-60790-06 NSS | TUBE,STRAIGHT |
245 | 68-69327-00 NSI | ANGLE |
250 | 08-66865-00 NSS | COILASSY,EVAP |
255 | 67-66822-00 NSI | COVER |
260 | 67-66823-00 NSI | COVER |
265 | 68-70482-00 | BRIDE DISTRI |
270 | 68-70481-00 | SUPPORT DISTRIBUTEUR |
275 | 81-66852-00 NSS | DISTR ASSY– INCLUDES: |
276 | 48-69013-00 NSS | DISTRIBUTOR |
277 | 56-69257-00 NSS | TUBE,DISTR |
278 | 56-69256-00 NSS | TUBE COPPER (ONLY FOR COPPER TXV UNITS) PRIOR UNIT S/N PKN94055788 |
278A | 56-69256-01 NSS | TUBE COPPER (ONLY FOR STAINLESS STEEL TXV UNITS) STARTING UNIT S/N PKN94055789 |
280 | 81-66850-00 NSS | SUCT LINE ASSY – INCLUDES: |
281 | 40-60004-00 | CAP |
282 | 40-60006-00 | ELBOW 90* ¼ SCHRADER |
283 | 56-69253-00 NSS | TUBE,EQUALIZER |
305 | 34-60098-62 PL* | NUT,RETAINER |
310 | 68-69328-00 NSS | WRAPPER,EVAP |
315 | 68-69329-00 NSS | SUPPORT,EVAP |
320 | 67-66829-00 NSS | FANDECK |
325 | 67-66818-00 NSS | TUBE SHEET |
330 | 67-66819-00 NSS | TUBE SHEET |
335 | 81-66848-00 NSI | DEFROST TUBEASSY – INCLUDES: |
336 | 56-69245-00 NSS | TUBE,SERPENTINE |
337 | 56-69246-00 NSS | TUBE,SERPENTINE |
338 | 68-69324-00 NSS | BRACKET, SEPENTINE |
339 | 40-60169-02 | FITTING |
| 22-69230-00 NSI | HARNESS – INCLUDES: |
| 22-69230-01 NSI | HARNESS (ONLY FOR MHV UNITS)- INCLUDES: |
10 | 58-60284-01 PL | ELBOW 19/19 |
20 | 22-50078-02 SK | HP1&HP2CONNECTOR 2 WAYS(MATES WITH 22-50078-01) |
30 | 22-60068-00 | INV&HGVCONNECTOR 2 WAYS |
40 | 22-01585-00 SK | LP CONNECTORS WAYS(MATES WITH 22-02392-00) |
50 | 22-50078-01 SK | EFM1&EFM2&EFM3&CFM1 CONNECTORS (MATES WITH 22-50078-02) |
60 | 22-60275-15 SK | CN3 CONNECTORS 9 WAYS (MATESWITH 22-60275-25) |
70 | 22-60300-10 SK | CN2 CONNECTOR 12 WAYS (MATESWITH 22-60300-11) |
80 | 10-00302-00 | EFMR1&EFMR2&CFMRRECEPTACLES |
90 | 22-60195-00 | FCFM&FEFM FUSE HOLDERS |
100 | 10-00286-21 | RELAY FOR 12VDC |
101 | 10-00286-09 | RELAY FOR 24VDC |
105 | 22-02336-05 | FUSE,25A FOR CFM1&CFM2 FOR 12VDC |
106 | 22-02336-01 | FUSE,20A FOR CFM1&CFM2 FOR 24VDC |
107 | 22-02336-01 | FUSE,20A FOR EFM1&EFM2&EFM3 FOR 12VDC |
108 | 22-02336-06 | FUSE,15A FOR EFM1&EFM2&EFM3 FOR 24VDC |
110 | 34-60000-12 PL* | SCREW,MACHHXHD |
115 | 34-60089-05 PL* | NUT,LOCK |
120 | 58-60306-05 PL* | WASHER,NYLON |
155 | 34-60000-16 PL* | SCREW,MACH HEHD |
160 | 34-60095-25 PL* | WASHER |
165 | 34-01184-05 PL* | NUT,LOCK |
185 | 58-60298-03 | GROMMET |
190A | 14-00273-21 | VALVE,EXPANSION(ONLY FOR STAINLESS STEEL TXV UNITS) STARTING UNIT S/N PKN94055789 |
190 | 14-60039-00 | VALVE,EXPANSION(ONLY FOR COPPERTXV UNITS) PRIOR UNIT S/N PKN94055788 |
195 | 14-60009-03 | ORIFICE (ONLYFOR COPPER TXV UNITS) PRIORUNIT S/N PKN94055788 |
200 | 42-00032-00 | INSULATION |
210 | 58-01284-00 | TUBE,HEATSHRNK |
215 | 79-66886-00 | EVAPORATOR ASSY– INCLUDES: |
225 | 86-69008-00 | DRAIN PAN ASSY – INCLUDES: |
226 | 56-60790-06 NSS | TUBE,STRAIGHT |
245 | 68-69327-00 NSI | ANGLE |
250 | 08-66865-00 NSS | COILASSY,EVAP |
255 | 67-66822-00 NSI | COVER |
260 | 67-66823-00 NSI | COVER |
265 | 68-70482-00 | BRIDE DISTRI |
270 | 68-70481-00 | SUPPORT DISTRIBUTEUR |
275 | 81-66852-00 NSS | DISTR ASSY– INCLUDES: |
276 | 48-69013-00 NSS | DISTRIBUTOR |
277 | 56-69257-00 NSS | TUBE,DISTR |
278 | 56-69256-00 NSS | TUBE COPPER (ONLY FOR COPPER TXV UNITS) PRIOR UNIT S/N PKN94055788 |
278A | 56-69256-01 NSS | TUBE COPPER (ONLY FOR STAINLESS STEEL TXV UNITS) STARTING UNIT S/N PKN94055789 |
280 | 81-66850-00 NSS | SUCT LINE ASSY – INCLUDES: |
281 | 40-60004-00 | CAP |
282 | 40-60006-00 | ELBOW 90* ¼ SCHRADER |
283 | 56-69253-00 NSS | TUBE,EQUALIZER |
1A | 86-69005-00 NSI | FRAME, ASSY(ONLY FOR S- CONTROLLER UNITS) PRIOR UNITS/N RKL94096676 |
1B | 86-69005-10 NSI | FRAME, ASSY (ONLY FOR H- CONTROLLER UNITS) STARTING UNIT S/N RKL94096676 |
2 | 58-69024-01 | PANEL, ROADSIDE |
3 | 58-69021-01 | PANEL, CURBSIDE |
4 | 58-69022-01 | COVER,FRONT |
5 | 58-69026-00 | FOAM |
6 | 67-66812-00 NSI | BRACKET |
7 | 62-61335-00 | DECAL, R404A |
7 | 62-61335-01 | DECAL, R134a(ONLY FOR R134aUNITS) |
8 | 34-60044-03 PL* | SCREW RLXM6 |
9 | 62-69087-00 | LABEL,CITIMAX700 |
10 | 62-60390-03 | DECAL,CARRIER |
11 | 34-60068-20 PL* | SCREW,CAPTWASH |
11 | 34-60068-20 PL* | SCREW,CAPT WASH(ONLY FOR MHV UNITS) |
12 | 58-60681-00 | WASHER, M6X30MM |
13 | 67-66832-00 NSI | BRACKET (ONLYFOR MHV UNITS) |
5 | 65-66808-00 | OIL SEPERATOR |
10 | 34-60068-20 PL* | SCREW,CAPTWASH |
15 | 42-00243-03 | O-RING 5/8 |
20 | 42-00243-10 | O-RING 1/2 |
25 | 82-66805-00 NSI | TUBE, OIL - INCLUDES: |
26 | 40-60008-01 | NIPPLE |
27 | 40-60009-01 | SWIVEL NUT |
30 | 12-00694-03 | HP2 SWITCH CONTROL |
NS | 22-50078-01 SK | CONNECTOR 2 WAYS ( MATES WITH22-50078-02SK ) |
NS | 22-50078-01A SK | SECONDARYLOCK |
31 | 40-60087-00 | VALVE |
35 | 12-00694-02 | HP1 SWITCH SECURITY |
NS | 22-50078-01 SK | CONNECTOR 2 WAYS ( MATES WITH22-50078-02SK ) |
NS | 22-50078-01A SK | SECONDARYLOCK |
40 | 12-00695-01 | LPS SWITCH |
NS | 22-02392-00 SK | CONNECTOR 2 WAYS ( MATES WITH22-01585-00SK ) |
55 | 81-66868-00 | TUBE, ACCU– INCLUDES: |
56 | 40-60169-06 | FITTING |
60 | 42-00243-11 | O-RING |
70 | 34-60206-16 PL* | VIS H M6 |
75 | 62-69083-02 | DECAL SUCTION LINE |
95 | 14-60000-03 | CPR |
100 | 81-66858-00 NSI | SUCT TUBE ASSY – INCLUDES: |
101 | 40-60169-06 | FITTING |
102 | 40-60159-01 | VALVE, 1/4 SCHRADER |
105 | 62-69083-03 | DECAL ROAD DISCHARGE LINE |
110 | 62-69083-04 | DECAL ROAD SUCTIONLINE |
125A | 65-66807-00 | RECEIVER PRIOR UNITS/N RKT94106089 |
125B | 65-66807-01 | RECEIVER STARTING UNIT S/N RKT94106089 |
130 | 56-69220-00 PL | TUBE, COND |
135A | 56-69217-00 PL | TUBE, REC PRIOR UNITS/N RKT94106089 |
135B | 56-69217-01 PL | TUBE, REC STARTING UNIT S/N RKT94106089 |
140 | 22-60268-00 | COIL 12V,DEFROST |
140 | 22-60268-00 | COIL 12V,DEFROST ( ONLY FOR MHV UNITS) |
140 | 22-60268-01 | COIL 24V,DEFROST |
140 | 22-60268-01 | COIL 24V,DEFROST (ONLYFOR MHV UNITS) |
145 | 62-69083-00 | DECAL HOTGAS LINE |
150 | 42-00243-09 | O-RING |
160 | 82-66801-00 PL | TUBE,HOT GAS - INCLUDES: |
161 | 40-60169-02 | FITTING |
165 | 34-00373-53 PL* | CLAMP |
170 | 14-00333-01 | VALVE SOLENOID |
NS | 14-00333-10 | REPAIR KIT |
175 | 34-01197-12 PL* | SCREW, CAP HEXH |
175 | 34-01197-12 PL* | SCREW, CAP HEX H (ONLY FOR MHV UNITS) |
180 | 34-01146-04 PL* | WASHER, LOCK |
180 | 34-01146-04 PL* | WASHER, LOCK(ONLY FOR MHV UNITS) |
185 | 34-01151-04 PL* | WASHER, FLAT |
185 | 34-01151-04 PL* | WASHER, FLAT(ONLY FOR MHV UNITS) |
186 | 34-01184-04 PL* | NUT, LOCK |
190 | 56-69234-00 PL | TUBE, HOTGAS |
190A | 56-69270-00 PL | TUBE, HOTGAS ( ONLY FOR MHV UNITS) |
195 | 56-69292-00 | TUBE, INJECTION |
200 | 62-69083-01 | DECAL LIQUID LINE |
205 | 56-69236-00 PL | TUBE, INJECTION |
210 | 22-60405-00 | COIL 12V,INJECTION |
210 | 22-60405-01 | COIL 24V,INJECTION |
215 | 68-61207-00 | BRACKET |
220 | 14-00269-01 | INJECTION VALVE,ODF,1/4" |
NS | 14-00269-10 | REPAIR KIT |
225 | 56-69221-00 PL | TUBE, INJECTION |
230 | 82-66800-00 PL | TUBE,LIQUID - INCLUDES: |
231 | 40-60008-02 | NIPPLE |
232 | 40-60009-02 | SWIVEL NUT |
233 | 40-60169-02 | FITTING |
235 | 14-01092-06 | INDICATOR |
240 | 44-60009-03 | CLAMP |
245 | 14-00326-03 | FILTER,DRIER |
250 | 82-66804-00 PL | LIQUID, TUBE - INCLUDES: |
251 | 40-60008-02 | NIPPLE |
252 | 40-60009-02 | SWIVEL NUT |
255 | 54-00639-17 | MOTOR,12VDC - INCLUDES: |
255 | 54-00639-16 | MOTOR,24VDC - INCLUDES: |
256 | 54-00639-34 | BRUSH |
257 | 54-60006-31 | BRUSH CAP |
258 | 22-50078-02 SK | CONNECTOR2 WAYS(MATES WITH22-50078-01SK) |
260 | 48-60237-00 | DISSIPATEUR |
265 | 34-60000-25 PL* | 6MM HEX HEAD SCREW |
270 | 34-60089-05 PL* | NUT, LOCK |
275 | 34-60095-25 PL* | NUT |
280 | 73-60049-01 | FAN GRILLE |
285 | 38-00613-00 | FAN BLADE, CONDENSER |
290 | 58-04316-00 | BASE, MOUNTING |
295 | 62-60870-00 | DECAL,12V |
295 | 62-60870-01 | DECAL,24V |
300 | 67-66810-00 NSI | FAN BOX |
305 | 08-66872-00 | MCHE |
310 | 82-66802-00 PL | TUBE,DISCHARGE – INCLUDES: |
310A | 82-66808-00 PL | TUBE,DISCHARGE(ONLY FOR MHV UNITS)– INCLUDES: |
311 | 40-60008-03 | NIPPLE |
312 | 40-60009-03 | SWIVEL NUT |
313 | 40-60159-01 | VALVE, 1/4 |
315 | 34-60068-16 PL* | SCREW,CAPTWASH |
325 | 44-60044-01 | CLAMP |
330 | 42-00424-21 | SEAL |
335 | 42-00424-23 | SEAL |
340 | 14-00276-00 | VALVE SOLENOID ( ONLY FOR MHV UNITS) |
NS | 14-00276-10 | REPAIR KIT |
345 | 56-69268-00 PL | TUBE,CONDENSER ( ONLY FOR MHV UNITS) |
10 | 62-60063-00 | DECAL, R404A |
10 | 62-03797-13 | DECAL, R134a(ONLY FOR R134aUNITS) |
15 | 62-60870-00 | DECAL 12V |
15 | 62-60870-01 | DECAL 24V |
20 | 42-60007-13 | INSULATION |
25 | 62-61477-00 | DECAL, CUTINGRISK |
30 | 62-69083-02 | DECAL, SUCTION LINE |
35 | 62-69083-01 | DECAL, LIQUIDLINE |
40 | 62-69083-00 | DECAL, HOT GAS LINE |
45 | 42-00243-09 | O-RING |
50 | 42-00243-11 | O-RING |
55 | 58-60393-02 PL | FITTING COVER |
60 | 58-60734-00 PL | FITTING COVER |
65 | 44-00293-22 | CLAMP |
70 | 34-60068-16 PL* | SCREW,CAPTWASH |
75 | 38-00605-00 | FAN BLADE |
80 | 54-00639-14 | MOTOR,DC12V – INCLUDES: |
80 | 54-00639-15 | MOTOR,DC24V – INCLUDES: |
81 | 54-60639-31 | CAP, BRUSH HOLDER |
82 | 54-00639-32 | BRUSH |
83 | 22-50078-02 SK | CONNECTOR 2 WAYS(MATES WITH22-50078-01SK) |
85 | 73-60007-00 | MOTOR MOUNT |
90 | 34-60068-20 PL* | SCREW,CAPTWASH |
95 | 44-60024-25 PL | STA-STRAP |
100 | 44-60024-05 PL | STA-STRAP |
105 | 79-66885-00 | EVAPORATOR ASSY– INCLUDES: |
110 | 08-60036-00 | LIQUID GASHEAT EXCHANGER |
115 | 82-66807-00 PL | TUBE LIQUID ASSY- INCLUDES: |
116 | 40-60170-02 | NUT |
117 | 40-60165-00 | FITTING |
120 | 81-66856-00 PL | TUBE GAS ASSY- INCLUDES: |
121 | 40-60169-06 | FITTING |
125 | 81-66857-00 PL | TUBE LIQUIDASSY - INCLUDES: |
126 | 40-60169-02 | FITTING |
127 | 82-66822-00 | Tube asy (ONLY FOR MHV UNITS) |
128 | 14-00181-09 | CHECK VALVE (ONLY FOR MHV UNITS) |
129 | 56-69299-00 | Tube (ONLY FOR MHV UNITS) |
130 | 56-69265-00 PL | TUBE,EQUALIZER |
135 | 44-60044-01 | CLAMP |
140 | 34-60206-16 PL* | SCREW |
145 | 68-60314-00 PL | BRACKET |
150 | 44-60100-01 | CLAMP |
155 | 34-60000-16 PL* | SCREW,MACHHEHD |
160 | 34-60095-25 PL* | WASHER |
165 | 34-01184-05 PL* | NUT,LOCK |
175 | 34-60095-46 PL* | WASHER |
180 | 34-01184-06 PL* | NUT,LOCK |
185 | 58-60298-03 | GROMMET |
190 | 14-60039-00 | VALVE,EXPANSION |
190 | 14-60050-00 | VALVE,EXPANSION (ONLYFOR R134a UNITS) |
195 | 14-60009-04 | ORIFICE |
200 | 42-00032-00 | INSULATION |
210 | 58-01284-00 | TUBE,HEATSHRNK |
215 | 68-60314-01 PL | BRACKET |
220 | 44-60041-75 | CLAMP |
225 | 79-66887-00 | EVAPORATOR ASSY– INCLUDES: |
235 | 86-69009-00 | DRAIN PAN ASSY- INCLUDES: |
236 | 56-60790-06 NSS | TUBE,STRAIGHT |
255 | 68-69327-00 NSI | ANGLE |
260 | 08-66867-00 NSS | COIL ASSY,EVAP |
265 | 67-66827-00 NSI | COVER |
270 | 67-66828-00 NSI | COVER |
275 | 68-70482-00 | BRACKET |
280 | 68-70481-00 | SUPPORT DISTRIBUTEUR |
285 | 81-66853-00 NSS | DISTR ASSY - INCLUDES: |
286 | 14-00363-06 NSS | DISTRIBUTEUR |
287 | 56-69257-00 NSS | TUBE,DISTR |
288 | 56-69256-00 NSS | TUBE COPPER |
290 | 81-66851-00 NSS | SUCT LINE ASSY- INCLUDES: |
291 | 40-60004-00 | CAP |
292 | 40-60006-00 | VALVE |
293 | 56-69253-00 NSS | TUBE,EQUALIZER |
315 | 34-60098-62 PL* | NUT |
320 | 68-69331-00 NSS | WRAPPER,EVAP |
325 | 68-69332-00 NSS | SUPPORT,EVAP |
330 | 67-66829-00 NSS | FAN DECK |
335 | 67-66824-00 NSS | TUBE SHEET |
340 | 67-66825-00 NSS | TUBE SHEET |
345 | 81-66849-00 NSI | DEFROST TUBE ASSY - INCLUDES: |
346 | 56-69248-00 NSS | TUBE,SERPENTINE |
347 | 56-69249-00 NSS | TUBE,SERPENTINE |
348 | 68-69325-00 NSS | BRACKET, SEPENTINE |
349 | 40-60169-02 | FITTING |
| 22-69231-00 NSI | HARNESS - INCLUDES: |
| 22-69231-01 NSI | HARNESS (ONLY FOR MHV UNITS)- INCLUDES: |
10 | 58-60284-01 PL | ELBOW 19/19 |
20 | 22-50078-02 SK | HP1&HP2CONNECTOR 2WAYS (MATES WITH 22-50078-01) |
30 | 22-60068-00 | INV&HGV CONNECTOR 2 WAYS |
40 | 22-01585-00 SK | LPCONNECTORS WAYS (MATES WITH 22-02392-00) |
50 | 22-50078-01 SK | EFM1&EFM2&EFM3&CFM1 CONNECTORS (MATES WITH 22-50078-02) |
60 | 22-60275-15 SK | CN3 CONNECTORS 9 WAYS(MATES WITH 22-60275-25) |
70 | 22-60300-10 SK | CN2 CONNECTOR 12 WAYS(MATES WITH 22-60300-11) |
80 | 10-00302-00 | EFMR1&EFMR2&CFMRRECEPTACLES |
90 | 22-60195-00 | FCFM&FEFM FUSEHOLDERS |
100 | 10-00286-21 | RELAYFOR 12VDC |
101 | 10-00286-09 | RELAYFOR 24VDC |
105 | 22-02336-05 | FUSE,25AFOR CFM1&CFM2 FOR12VDC |
106 | 22-02336-01 | FUSE,20AFOR CFM1&CFM2 FOR24VDC |
107 | 22-02336-01 | FUSE,20AFOR EFM1&EFM2&EFM3 FOR 12VDC |
108 | 22-02336-06 | FUSE,15AFOR EFM1&EFM2&EFM3 FOR 24VDC |
110 | 34-60000-12 PL* | SCREW,MACHHXHD |
115 | 34-60089-05 PL* | NUT,LOCK |
120 | 58-60306-05 PL* | WASHER,NYLON |
| 22-69252-00 NSI | HARNESS – INCLUDES: |
| 22-69252-01 NSI | HARNESS (ONLY FOR MHV UNITS)- INCLUDES: |
10 | 58-60284-01 PL | ELBOW 19/19 |
20 | 22-50078-02 SK | HP1&HP2 &RAS CONNECTOR 2 WAYS (MATES WITH 22-50078-01) |
30 | 22-60068-00 | INV&HGV CONNECTOR 2 WAYS |
40 | 22-01585-00 SK | LP CONNECTORS WAYS(MATES WITH 22-02392-00) |
50 | 22-50078-01 SK | EFM1&EFM2&EFM3&CFM1 CONNECTORS (MATES WITH 22-50078-02) |
60 | 22-60244-24 | TERMINALS ø6 FOR 25mm^2 |
70 | 22-60244-19 | TERMINALSø5 FOR 25mm^2 |
80 | 22-69255-00 | CONNECTOR4 WAYS MALE |
90 | 22-69255-01 | CONNECTOR6 WAYS MALE |
100 | 22-60275-14 | CONNECTOR6 WAYS MALE |
110 | 22-60300-08 | CONNECTOR9 WAYS MALE |
120 | 22-60275-11 | CONNECTOR 2 WAYS MALE |
9A. ELECTRICAL CONTROLKIT (ONLY FOR S- CONTROLLER UNITS) PRIOR UNIT S/N RKL94096676 CITIMAX 500/700
20 | 10-00286-21 | RELAY |
30 | 12-00507-00 | THERMOSTAT |
40 | 12-00512-21 | SENSOR,THERM |
50 | 22-02336-04 | FUSE 12VDC 10A |
51 | 22-02336-08 | FUSE 24VDC 7.5A |
80 | 22-60168-05 | CABLE |
90 | 22-69230-00 | HARNESS CITIMAX500 |
90 | 22-69230-01 | HARNESS CITIMAX 500 (ONLY FORMHV UNITS) |
90 | 22-69231-00 | HARNESS CITIMAX 700 |
90 | 22-69231-01 | HARNESS CITIMAX 700 (ONLY FORMHV UNITS) |
100 | 34-60000-12 PL | SCREW,MACHHXHD |
110 | 34-60089-05 PL* | NUT, LOCK |
120 | 58-60306-05 | WASHER, NYLON |
130 | 44-60024-25 | STA-STRAP |
140 | 91-69044-00 NSA | LOGIC BOARD ASSY- INCLUDES: |
140 | 91-69044-01 NSA | LOGIC BOARDASSY (FOR MHVONLY) – INCLUDES: |
140A | 67-66814-00 | ELECTRICALBOX |
150 | 12-66808-01 | LOGIC BOARD |
150 | 12-66808-02 | LOGIC BOARD(ONLY FOR MHV UNITS) |
160 | 34-06196-00 PL | SCREW, TF PNHD |
170 | 34-00946-52 PL | NUT, LOCK |
180 | 58-69029-00 | SPACER, NYLON |
190 | 79-60409-00 | CAB COMMAND - INCLUDES: |
200 | 22-60166-00 | BRACKET |
| 22-69251-00 NSI | HARNESS – INCLUDES: |
| 22-69251-01 NSI | HARNESS (ONLY FOR MHV UNITS)- INCLUDES: |
10 | 58-60284-01 PL | ELBOW 19/19 |
20 | 22-50078-02 SK | HP1&HP2 &RAS CONNECTOR 2 WAYS (MATES WITH 22- 50078-01) |
30 | 22-60068-00 | INV&HGVCONNECTOR 2 WAYS |
40 | 22-01585-00 SK | LP CONNECTORS WAYS(MATES WITH 22-02392-00) |
50 | 22-50078-01 SK | EFM1&EFM2&EFM3&CFM1 CONNECTORS (MATES WITH 22-50078-02) |
60 | 22-60244-20 | TERMINALSø6 FOR 16mm^2 |
70 | 22-60244-19 | TERMINALSø5 FOR 16mm^2 |
80 | 22-69255-00 | CONNECTOR4 WAYS MALE |
90 | 22-69255-01 | CONNECTOR6 WAYS MALE |
100 | 22-60275-14 | CONNECTOR6 WAYS MALE |
110 | 22-60300-08 | CONNECTOR9 WAYS MALE |
120 | 22-60275-11 | CONNECTOR 2 WAYS MALE |
40 | 12-66814-01 | CAB COMMAND– INCLUDES（REPLACE 12-66814-00）: |
50 | 68-69358-00 | BRACKET, DISPLAY(OPTION) |
60 | 68-69353-00 | BRACKET MGT (OPTION) |
70 | 34-66892-18 | SCREW M4 |
80 | 44-60024-25 | STA-STRAP |
90 | 22-69250-00 | CABLE |
100 | 22-69251-00 | HARNESS CITIMAX500 |
100 | 22-69251-01 | HARNESS CITIMAX500 (FOR MHV UNITS) |
100 | 22-69252-00 | HARNESS CITIMAX700 |
100 | 22-69252-01 | HARNESS CITIMAX700 (FOR MHV UNITS) |
110 | 34-66895-05 | NICK-PLATED BRASSNUT, M5 |
120 | 34-66895-06 | NICK-PLATED BRASSNUT, M6 |
130 | 42-00183-21 NS | EDGE GUARD |
40B | 12-66816-00 | Cab command(Optional)-include： |
40B-1 | 22-69289-00 | Bracket |
version | series number | |
E | before SKB94119618 （include SKB94119642--SKB94119691） | |
F | after SKB94119618 （ exclude SKB94119642--SKB94119691） | |
| 77−69 007−00 NSA | TUBE, DISCH — INCLUDES: |
1 | 40−60 008−03 | NIPPLE |
2 | 40−60 009−03 | SWIVEL NUT |
3 | 56−69 231−00 PL | TUBE, DISCH |
4 | 40−60 087−00 | MECHANISMESCHRADER |
5 | 40−60 159−01 | VALVE, ¼ SCHRADER |
6 | 40−60 169−03 | FITTING |
7 | 34−60 206−16 | SCREW M6 |
8 | 42−243−04 | O-RING |
10 | 40−60 004−00 | CAP |
10 | 62-61477-00 | DECAL, CUTTING RISK |
20 | 62-69083-00 | DECAL, HOT GAS LINE |
30 | 62-69083-01 | DECAL, LIQUID LINE |
40 | 62-69083-02 | DECAL, SUCTION LINE |
50 | 62-69083-03 | DECAL, ROAD DISCHARE LINE |
60 | 62-69083-04 | DECAL, ROAD SUCTIONLINE |
80 | 62-61335-00 | DECAL, MAIN R404A |
80A | 62-61335-01 | DECAL, MAIN R134a(ONLY FOR R134aUNITS) |
90 | 62-60390-03 | DECAL, CARRIER |
100 | 62-60870-00 | DECAL, 12VDC |
101 | 62-60870-01 | DECAL, 24VDC |
110 | 62-60063-00 | DECAL, R404A |
110A | 62-03797-13 | DECAL, R134a (ONLYFOR R134a UNITS) |
120 | 62-69087-00 | LABEL, CITIMAX 700 |
130 | 62-69087-01 | LABEL, CITIMAX 500 |
140 | 62-60764-00 | DECAL |
150 | 62-61774-00 | DECAL |
1 |
| HOSE KIT-INCLUDES: |
2 | 58-60745-30 | HOSE,ID-OD8-16mm |
3 | 58-60745-32 | HOSE,ID-OD12.7-21.5mm |
4 | 58-60745-33 | HOSE,ID-OD16.1-24.1mm |
5 | 44-60129-01 | CLAMP |
6 | 44-60129-03 | CLAMP |
7 | 44-60129-04 | CLAMP |
8 | 40-60289-01 | FITTING,90° |
9 | 40-60288-01 | FITTING,180° |
10 | 40-60289-04 | FITTING,90°(ONLY FOR CITIMAX 500 ) |
11 | 40-60288-04 | FITTING,180° |
12 | 40-60285-33 | FITTING,180° |
13 | 40-60288-12 | FITTING,180° |
15 | 40-60301-00 | ELBOW,90DEG |
16 | 40-60301-01 | ELBOW,90DEG |
17 | 40-60285-42 | FITTING,180° |
18 | 58-69030-00 NS | HOSE,ASSY FOR SUCTION(ONLY FOR CITIMAX 700 ) |
19 | 40-69111-00 | FITTING 90 ORFS(ONLY FOR CITIMAX 700) |
20 | 44-66814-00 | CLAMP (ONLY FOR CITIMAX 700 ) |
21 | 58-69031-00 | HOSE (ONLY FOR CITIMAX 700 ) |
22 | 40-69110-00 | FITTING ORFS (ONLYFOR CITIMAX 700) |
23 | 98-60591-00 | INSTRUCTIONS |
© All Rights Reserved
refxolod.ru
