Каталог запчастей рефрижераторов Carrier VECTOR 1550
4 | 34-01184-58 | NUT, LOCK M8 |
5 | 34-60014-05 | BOLT, T -HEAD |
7 | 34-60095-30 | WASHER, LOCK M8 X 18MM |
10 | 34-01249-29 | WASHER, SPACER |
15 | 34-00361-15 | NUT, SELFLOCK |
20 | 34-60085-09 | WASHER, M8 X 22MM |
25 | 34-60152-00 | SCREW, HX WASHHD HM8 LG 25MM |
28 | 44-00406-00 | PIN, DOOR LATCH |
30 | 67-60873-00 | BRACKET |
32 | 68-61689-00 | BRACKET - INCLUDES: |
NS | 34-60098-81 | CAGE NUT |
35 | 67-60813-00 | BRACKET |
40 | 58-04406-00 | BUMPER |
45 | 79-60463-10 | DOOR ASSY, UPPERCURBSIDE ( SEE SECTION 1.1. ) |
50 | 79-60459-10 | DOOR ASSY, INNERCURBSIDE ( SEE SECTION 1.3.) |
55 | 79-60461-10 | DOOR ASSY, OUTERCURBSIDE ( SEE SECTION 1.4. ) |
60 | 79-60462-10 | DOOR ASSY, UPPERROADSIDE ( SEE SECTION 1.2.) |
65 | 79-60460-12 | DOOR ASSY, OUTERROADSIDE ( SEESECTION 1.4. ) |
70 | 79-60458-10 | DOOR ASSY, INNERROADSIDE ( SEE SECTION 1.3. ) |
90 | 34-60261-25 | SCREW, CAPTIVEVM TRL M8 |
100 | 34-00946-58 | NUT, HEX M8 |
105 | 68-61825-00 | BRACKET, RIGHT |
110 | 68-61825-01 | BRACKET, LEFT |
136 | 79-60770-20 | GRILLE ASSY, CONDENSER - INCLUDES: |
137 | 42-00521-00 | FOAM |
138 | NSS | SUPPORT |
139 | NSS | GRILLE |
140 | NSS | WASHER, FLATM5 X 15MM |
141 | 34-60238-16 | SCREW, M5 X 16MM |
142 | NSS | BRACKET, GRILLE ROADSIDE WITH HINGE |
143 | NSS | BRACKET, GRILLECURBSIDE WITH HINGE |
144 | NSS | NUT, M6 |
145 | NSS | SCREW, M6 BLACK |
146 | 62-60008-02 | DECAL, CARRIER |
147 | 58-60826-00 | PLATE ( CITYVERSION ) |
170 | 77-01359-00 | FRAME ASSY - INCLUDES: |
171 | 58-60612-01 | PLUG, RUBBER |
172 | 58-60612-00 | PLUG, RUBBER |
173 | 34-60152-00 | SCREW, HX HM8 LG 25MM |
174 | 44-00415-00 | HINGE |
330 | 42-60061-00 | GASKET, DOOR( CITYVERSION ) |
490 | 58-60816-00 | VIBRATION INSULATION, UPPERCURBSIDE ( CITYVERSION )( SEE SECTION 1.1. ) |
500 | 58-60816-01 | VIBRATION INSULATION, OUTERCURBSIDE ( CITY VERSION )( SEE SECTION 1.4. ) |
510 | 58-60816-02 | VIBRATION INSULATION, INNERCURBSIDE ( CITY VERSION )( SEE SECTION 1.3. ) |
520 | 58-60816-03 | VIBRATION INSULATION, INNERROADSIDE ( CITY VERSION )( SEE SECTION 1.3. ) |
530 | 58-60816-04 | VIBRATION INSULATION, OUTERROADSIDE ( CITY VERSION )( SEE SECTION 1.4. ) |
540 | 42-60123-00 | GASKET ( CITY VERSION ) ( SEESECTIONS 1.1. TO 1.4. ) |
550 | 42-01164-00 | SEAL ( CITY VERSION ) |
580 | 42-60152-00 | INSULATION, FOAM ON POD( CITY VERSION) |
600 | 68-14927-00 | PROTECTOR, JUNCTION BOX OF EVAPVENTILATIONS |
4 | 34-01184-58 | NUT, LOCK M8 |
5 | 34-60014-05 | BOLT, T -HEAD |
7 | 34-60095-30 | WASHER, LOCK M8 X 18MM |
10 | 34-01249-29 | WASHER, SPACER |
15 | 34-00361-15 | NUT, SELFLOCK |
20 | 34-60085-09 | WASHER, M8 X 22MM |
25 | 34-60152-00 | SCREW, HX WASHHD HM8 LG 25MM |
28 | 44-00406-00 | PIN, DOOR LATCH |
30 | 67-60873-00 | BRACKET |
32 | 68-61689-00 | BRACKET - INCLUDES: |
NS | 34-60098-81 | CAGE NUT |
35 | 67-60813-00 | BRACKET |
40 | 58-04406-00 | BUMPER |
45 | 79-60463-10 | DOOR ASSY, UPPERCURBSIDE ( SEE SECTION 1.1. ) |
50 | 79-60459-10 | DOOR ASSY, INNERCURBSIDE ( SEE SECTION 1.3.) |
55 | 79-60461-10 | DOOR ASSY, OUTERCURBSIDE ( SEE SECTION 1.4. ) |
60 | 79-60462-10 | DOOR ASSY, UPPERROADSIDE ( SEE SECTION 1.2.) |
65 | 79-60460-12 | DOOR ASSY, OUTERROADSIDE ( SEESECTION 1.4. ) |
70 | 79-60458-10 | DOOR ASSY, INNERROADSIDE ( SEE SECTION 1.3. ) |
90 | 34-60261-25 | SCREW, CAPTIVEVM TRL M8 |
100 | 34-00946-58 | NUT, HEX M8 |
105 | 68-61825-00 | BRACKET, RIGHT |
110 | 68-61825-01 | BRACKET, LEFT |
136 | 79-60796-20 | GRILLE ASSY, CONDENSER - INCLUDES: |
137 | NSS | SUPPORT |
138 | NSS | GRILLE |
139 | NSS | WASHER, FLAT M5 X 15MM |
140 | NSS | SCREW, M5 X 16MM |
141 | 62-61648-00 | LOGO, CARRIER VISIBILITY |
142 | 34-60263-08 | WASHER, QUICKLOCK |
143 | 42-00521-01 | FOAM |
144 | 34-60238-16 | SCREW, M5 X 16MM( CITY VERSION ) |
145 | 58-60826-00 | PLATE ( CITYVERSION ) |
170 | 77-01359-00 | FRAME ASSY - INCLUDES: |
171 | 58-60612-01 | PLUG, RUBBER |
172 | 58-60612-00 | PLUG, RUBBER |
173 | 34-60152-00 | SCREW, HX HM8 LG 25MM |
174 | 44-00415-00 | HINGE |
330 | 42-60061-00 | GASKET, DOOR ( CITY VERSION ) |
335 | 58-60153-01 | PLUG, DRAINPAN |
490 | 58-60816-00 | VIBRATION INSULATION, UPPERCURBSIDE ( CITYVERSION )( SEE SECTION 1.1. ) |
500 | 58-60816-01 | VIBRATION INSULATION, OUTERCURBSIDE ( CITY VERSION )( SEE SECTION 1.4. ) |
510 | 58-60816-02 | VIBRATION INSULATION, INNERCURBSIDE ( CITY VERSION )( SEE SECTION 1.3. ) |
520 | 58-60816-03 | VIBRATION INSULATION, INNERROADSIDE ( CITY VERSION )( SEE SECTION 1.3. ) |
530 | 58-60816-04 | VIBRATION INSULATION, OUTERROADSIDE ( CITY VERSION )( SEE SECTION 1.4. ) |
540 | 42-60123-00 | GASKET ( CITY VERSION ) ( SEESECTIONS 1.1. TO 1.4. ) |
550 | 42-01164-00 | SEAL ( CITY VERSION ) |
580 | 42-60152-00 | INSULATION, FOAM ON POD( CITY VERSION) |
600 | 68-14927-00 | PROTECTOR, JUNCTION BOX OF EVAPVENTILATIONS |
| 79-60463-10 | DOOR ASSY, UPPERCURBSIDE - INCLUDES: |
10 | 34-60206-16 PL | SCREW, CAP HXHD M6 X 16MM |
20 | 44-60087-00 | HINGE |
40 | 42-00174-100 | GASKET |
490 | 58-60816-00 | VIBRATION INSULATION, UPPERCURBSIDE ( CITYVERSION ) |
540 | 42-60123-00 NSI | GASKET ( CITY VERSION ) |
| 79-60462-10 | DOOR ASSY, UPPERROADSIDE - INCLUDES: |
10 | 34-60206-16 PL* | SCREW, M6 X 16MM |
20 | 44-60087-00 | HINGE |
40 | 42-00174-100 | GASKET |
540 | 42-60123-00 NSI | GASKET ( CITY VERSION ) |
5 | 79-60459-10 | DOOR ASSY, INNERCURBSIDE - INCLUDES: |
10 | 79-60458-10 | DOOR ASSY, INNERROADSIDE - INCLUDES: |
20 | 79-60464-00 | LATCH ASSY, INNERROADSIDE DOOR - INCLUDES: |
21 | NSS | LATCH |
22 | NSS | HANDLE ASSY |
23 | 34-01184-60 | NUT, LOCK M10 |
24 | 73-00191-00 | SPRING |
30 | 44-00381-00 | HINGE, RELEASEPULL IN |
35 | 44-00381-01 | HINGE, RELEASE PULLIN |
40 | 44-00461-00 | HINGE, OUTERDOOR |
50 | 44-60086-01 | LOCK, DOOR |
60 | 68-12915-00 | PLATE |
70 | 68-61668-00 | BRACKET |
80 | 34-60206-16 | SCREW, HXHDM6 X 16MM |
100 | 34-01184-56 | NUT, LOCK M6 |
110 | 34-60095-46 | WASHER, LOCK M6 X 18MM |
NS | 58-60188-00 | BUMPER, RUBBER |
NS | 62-61451-00 | DECAL, LOCK UNLOCK |
510 | 58-60816-02 | VIBRATION INSULATION, INNERCURBSIDE ( CITY VERSION ) |
520 | 58-60816-03 | VIBRATION INSULATION, INNERROADSIDE ( CITY VERSION ) |
5 | 79-60461-10 | DOOR ASSY, OUTERCURBSIDE - INCLUDES: |
6 | 79-60460-12 | DOOR ASSY, OUTERROADSIDE - INCLUDES: |
10 | 34-60206-16 | SCREW, M6 X 16MM |
30 | 44-00382-00 | HINGE, PULL IN |
35 | 44-00382-01 | HINGE, PULLIN |
40 | 44-00384-00 | HINGE, OUTERDOOR |
60 | 68-12915-00 | PLATE |
500 | 58-60816-01 | VIBRATION INSULATION, OUTERCURBSIDE ( CITY VERSION ) |
530 | 58-60816-04 | VIBRATION INSULATION, OUTERROADSIDE ( CITY VERSION ) |
540 | 42-60123-00 | GASKET ( CITY VERSION ) |
270 | 76-00739-02 | SOUND PROOF KIT - INCLUDES: |
277 | 42-60146-00 NSI | INSULATION, BACK NOISEREDUCTION ( CITY VERSION ) |
278 | 42-60146-01 | INSULATION, BACK NOISEREDUCTION ( STANDARD VERSION ) |
280 | 44-60096-00 NSI | FASTENER |
284 | 42-60075-00 NSI | INSULATION, ROADSIDE LOWER |
286 | 42-60076-00 NSI | INSULATION, ROADSIDE FRONT |
288 | 42-60077-00 NSI | INSULATION, CURBSIDE FRONT |
290 | 42-60074-00 NSI | INSULATION, CURBSIDE LOWER |
292 | 42-60078-00 NSI | INSULATION, CURBSIDE UPPER |
295 | 76-61187-00 | FLAT BOTTOM PANELKIT - INCLUDES: |
296 | 58-04498-01 | BOTTOM PANEL |
300 | 67-00121-00 | BRACKET, HANGER |
301 | 34-60165-00 PL* | SCREW, VM TRL M8 |
305 | 34-60028-00 PL* | WASHER, FLATM8 X 30MM |
307 | 67-60365-02 | PLATE ASSY |
308 | 68-70316-00 | BRACKET, CONNECTOR |
310 | 76-61165-01 | LARGE BOTTOM PANELKIT - INCLUDES: |
320 | 79-60658-01 | BOTTOM PANEL- INCLUDES: |
321 | 42-60123-00 | GASKET |
325 | 67-60801-00 | BRACKET |
330 | 34-60028-00 PL* | WASHER, FLAT M8 X 30MM |
340 | 68-70353-00 | BRACKET, CONNECTOR |
350 | 67-60526-00 | BRACKET |
360 | 67-60798-00 | BRACKET |
370 | 67-60798-01 | BRACKET |
380 | 67-60800-00 | BRACKET |
390 | 67-60799-00 | BRACKET |
400 | 48-60188-14 | SPACER |
410 | 34-01153-30 PL* | SCREW, CAP HXHD M8 X 30MM |
420 | 34-60044-03 PL* | SCREW, M6 X 20MM |
430 | 34-60068-20 | SCREW, M6 X 20MM |
440 | 34-01197-20 PL* | SCREW, CAP HXHD M4 X 20MM |
450 | 34-60095-24 PL* | WASHER, LOCK M4 X 10MM |
45 | 14-00326-05 | FILTER DRIER, 1/2” |
60 | 34-60206-12 PL* | SCREW, HXHD M6 X 12MM |
65 | 22-60734-02 | COIL, COMPRESSOR UNLOADER ( MATES WITH 22--01613--02SK ) |
70 | 34-00361-61 PL* | NUT, LOCK1/4” X 20MM |
100 | 34-01152-25 PL* | SCREW, CAP HXHD M6 X 25MM |
105 | 34-01152-35 PL* | SCREW,CAP HXHD M6 X 35MM |
130 | 34-60068-20 | SCREW, M6 X 20MM |
150 | 34-60095-27 PL* | WASHER, LOCK M6 X 14MM |
155 | 34-60095-46 PL* | WASHER,LOCK M6 X 18MM |
160 | 34-60152-00 PL* | SCREW, HX HM8 LG:25MM |
195 | 42-00243-04 | O -RING, 1/2” |
205 | 42-00389-00 | INSULATION, ECONOMIZER |
210 | 42-00390-00 | INSULATION, FRONT ECONOMIZER |
240 | 42-60007-10 | INSULATION, TUBE |
285 | 44-60010-02 | CLAMP, TUBE 1/2” |
295 | 44-60010-01 | CLAMP, TUBE 3/8” |
325 | 56-61790-00 NSI | TUBE, 7/8” |
330 | 58-60620-02 | SPACER |
340 | 62-60063-00 | LABEL, R404A |
355 | 65-60086-01 | RECEIVER - INCLUDES: |
357 | 14-00220-05 | MOISTURE INDICATOR SIGHT GLASS |
358 | 14-00272-01 | VALVE RELIEF |
370 | 67-00243-00 | BRACKET |
375 | 67-00231-00 | BRACKET |
380 | 67-00232-00 | BRACKET |
395 | 68-15824-00 | BRACKET |
410 | 68-70687-01 | BRACKET |
415 | 79-60541-00 | CLAMP, DRIER |
435 | PL | LINE ASSY,INJECTION - INCLUDES: |
435A | 08-66614-00 | ECONOMIZER |
435B | 40-60009-03 | NUT, 1/2” |
435C | 40-60008-03 | SLEEVE, 1/2” |
436 | 14-00329-06 | LIV LIQUID INJECTION VALVE |
NS | 14-00269-10 | REPAIR KIT |
437 | 14-00372-20 | ECON EXPANSION VALVEWITH STRAP ANDSCREW |
438 | 14-60062-09 | ESV ECONOMIZER SOLENOID VALVE |
NS | 14-60062-10 | REPAIR KIT |
439 | 40-00168-04 | TEE |
440 | PL | TUBE, LIQUID1/2” - INCLUDES: |
440A | 40-60009-03 | NUT, 1/2” |
440B | 40-60008-03 | SLEEVE, 1/2” |
445 | PL | TUBE, 1/2” |
500 | 44-60010-04 PL* | CLAMP |
510 | 34-01152-60 PL* | SCREW |
REFRIGERATION KIT
20 | 12-00352-03 | CSP TRANSDUCER ( MATES WITH 22-61008-00 ) |
25 | 12-00352-04 | CDP TRANSDUCER ( MATES WITH 22-61008-00 ) |
30 | 12-00566-04 | CST THERMISTOR - INCLUDES: |
31 | 22-50078-01SK | CST CONNECTOR 2 WAYS ( MATES WITH 22-50078-02SK ) |
35 | 12-00628-41 | SWITCH, HIGH PRESSURE |
50 | 18-10143-20 | COMPRESSOR - INCLUDES: |
NS | NSS | COMPRESSOR |
NS | 22-04193-11 | CABLE, POWER D -RING |
NS | 46-00025-04 | OIL, UNIQEMA EMKARATERL -32 -3MAF T |
NS | 22-04193-12 | GREASE |
NS | 34-06343-00 PL* | SCREW, GROUND |
51 | 12-00653-01 | CDT THERMISTOR KIT - INCLUDES: |
NS | NSS | THERMISTOR |
NS | NSS | SYRINGE WITHTHERMALLY CONDUCTIVE DIELECTRIC COMPOUND1 |
NS | NSS | TUBE, BLACKSILICONE 70mL |
52 | 22-01585-00SK | CONECTOR 2 WAYS ( MATES WITH 22-02392-00SK ) |
65 | 22-60734-02 | COIL, COMPRESSOR UNLOADER( MATES WITH 22 -01613 -02SK ) |
85 | 34-06334-00 | SPACER |
95 | 34-01152-12 PL* | SCREW, M6 X 12MM |
105 | 34-01152-35 PL* | SCREW, CAP HXHD M6 X 35MM |
110 | 34-01152-45 PL* | SCREW, CAP HXHD M6 X 45MM |
115 | 34-01152-80 PL* | SCREW, HM6 X 80MM |
130 | 34-60068-20 | SCREW, M6 X 20MM |
135 | 34-60082-45 PL* | SCREW, HXHD M6 X 45MM |
140 | 34-60084-06 PL* | WASHER, LOCK M6 X 10MM |
150 | 34-60095-27 PL* | WASHER, LOCK M6 X 14MM |
155 | 34-60095-46 PL* | WASHER, LOCK M6 X 18MM |
170 | 34-60100-60 PL* | SCREW, HM12 X 60MM |
190 | 42-00243-03 | O -RING |
200 | 42-00384-02 | SEAL |
240 | 42-60007-10 | INSULATION, TUBE |
245 | 42-60007-11 | INSULATION, TUBE |
250 | 42-60007-13 | INSULATION, TUBE |
255 | 42-60007-14 | INSULATION, TUBE |
265 | 44-00285-20 | CLAMP |
270 | 44-00285-57 | CLAMP |
280 | 44-00293-22 | CLAMP, STEPLESS |
285 | 44-60010-02 | CLAMP, TUBE 1/2” |
300 | 44-60010-14 PL* | CLAMP, TUBE 7/8” |
390 | 68-15820-00 | BRACKET |
420 | PL | TUBE ASSY, SUCTION - INCLUDES: |
NS | 40-00169-55 | TEE, 1’3/8” 1’1/8” 5/8” |
421 | 14-00373-00 | BY -PASS VALVE |
NS | 14-00332-10 | REPAIR KIT |
422 | 40-00673-01 | SUCTION VALVE |
423 | 14-00263-10 | CSMV VALVE, SOLENOID - INCLUDES: |
NS | 22-02392-03 SK | CSMV CONNECTOR 4 WAYS ( MATES WITH 22-01585-04SK ) |
NS | 14-00263-20 | PISTON MOTOR ASSY |
NS | 14-00263-22 | CAP |
425 | PL | TUBE ASSY, DISCHARGE - INCLUDES: |
426 | 40-00673-00 | DISCHARGE VALVE |
427 | 40-60159-00 | FITTING, 1/4” SCHRAEDER |
430 | PL | TUBE, LIQUID 1/2” |
435 | PL | LINE ASSY, INJECTION - INCLUDES: |
435B | 40-60009-03 | NUT, 1/2” |
435C | 40-60008-03 | SLEEVE, 1/2” |
435D | 40-00169-06 | TEE, REDUCING 5/8” X 1/2” X 5/8” |
435E | 40-60009-03 | NUT, 1/2” |
435F | 40-60008-03 | SLEEVE, 1/2” |
435G | 42-00243-04 | O -RING |
470 | 42-60007-15 | INSULATION, TUBE |
15 | 79-01994-00 | COIL, CONDENSER |
55 | 22-01637-01 | ATS SENSOR - INCLUDES: |
56 | 22-50078-01SK | CONNECTOR 2 WAYS( MATES WITH22-50078-02SK ) |
80 | 34-00876-20 | SCREW, CAP HXHD M8 X 20MM |
90 | 34-01151-16 | WASHER, FLATM16 PRIOR TO SERIAL NUMBERZC245029 |
130 | 34-60068-20 | SCREW, M6 X 20MM |
145 | 34-60085-09 | WASHER, M8 X 22MM |
160 | 34-60152-00 | SCREW, HX HM8 LG:25MM |
165 | 34-60153-00 | NUT, LOCK HM16PRIOR TO SERIAL NUMBER ZC245029 |
175 | 38-00544-00 | ROTOR, CONDENSER FAN PRIOR TO SERIAL NUMBER ZC245029 |
175 |
| VENTILATION ASSY, CONDENSER FAN STARTING WITH SERIAL NUMBER ZC245029 - INCLUDES: |
176 | 48-00427-01 | STATOR, CONDENSER FAN |
177 | 54-00647-00 | MOTOR - INCLUDES: |
178 | 22-01613-16SK | CONNECTOR 6 WAYS ( MATES WITH22-01613-18SK ) |
179 | 34-60068-20 | SCREW, M6 X 20MM |
180 | 38-00609-00 | ROTOR, FAN |
181 | 34-01151-16 | WASHER, M16 |
182 | 34-60153-00 | NUT, LOCKM16 |
183 | 34-60224-06 | NUT, M6 |
184 | 58-60830-00 | GUARD, FAN |
215 | 42-60092-08 | GASKET |
220 | 42-60092-09 | GASKET |
315 | 48-00323-00 | STATOR, CONDENSER FAN PRIOR TO SERIAL NUMBER ZC245029 |
320 | 54-00555-03 | MOTOR PRIOR TO SERIALNUMBER ZC245029 - INCLUDES |
321 | 22-01613-16SK | CONNECTOR 6 WAYS ( MATES WITH22-01613-18SK ) |
260 | 42-60009-00 | INSULATION |
360 | 67-60840-00 | BAFFLE |
365 | 67-60841-00 | BAFFLE |
385 | 68-13996-00 | BRACKET ASSY ( ROADSIDE ) PRIOR TO SERIAL NUMBER ZC302049 |
385 | 86-61441-00 | BRACKET ASSY( ROADSIDE ) STARTING WITH S/N ZC302049 |
400 | 68-15847-00 | BRACKET |
405 | 68-70676-00 | BRACKET ASSY ( CURBSIDE ) PRIOR TO SERIAL NUMBER ZC302049 |
405 | 86-61440-00 | BRACKET ASSY ( CURBSIDE ) STARTING WITH S/N ZC302049 |
490 | 34-00876-30 | SCREW, CAP HXHD M8 X 30MM |
10 | 08-00277-00 NSI | COIL ASSY | |
30 | 12-01039-08 | SWITCH, AIR | |
35 | 68-61896-00 | CHANNEL | |
40 | 68-61910-00 | BRACKET | |
45 | 14-00247-01 | EXPANSION VALVE PRIORTO SERIAL NUMBERZC143001 | |
45 | 14-00393-00 | EXPANSION VALVE STARTING WITH SERIAL NUMBERZC143001 | |
50 | 14-00247-20 | COIL, 12V PRIORTO SERIAL NUMBER ZC143001 - INCLUDES: | |
50 | 14-00393-10 | COIL, 12V STARTING WITH SERIAL NUMBERZC143001 - INCLUDES: | |
NS | 22-50098-23SK | EVXV CONNECTOR 5 WAYS ( MATES WITH 22-50098-22SK ) | |
60 | 24-60035-00 | HEATER, ELECTRIC 3450WHTR3 - INCLUDES: | |
NS | 22-50098-47SK | HTR3 CONNECTOR 4 WAYS ( MATES WITH22-50098-48SK ) | |
61 | 24-60035-02 | HEATER, ELECTRIC 1800WHTR2 - INCLUDES: | |
NS | 22-50098-47SK | HTR2 CONNECTOR 4 WAYS ( MATES WITH22-50098-48SK ) | |
62 | 24-60035-01 | HEATER, ELECTRIC 3450WHTR1 - INCLUDES: | |
NS | 22-50098-47SK | HTR1 CONNECTOR 4 WAYS ( MATES WITH22-50098-48SK ) | |
74 | 44-60044-02 | CLAMP, TUBE | |
76 | 67-00225-00 | CLAMP, HEAT EXCHANGER | |
85 | 34-60068-20 | SCREW, M6 X 20MM | |
86 | 34-60095-46 | WASHER, LOCK M6 X 18MM | |
88 | 34-60095-27 | WASHER, LOCK M6 X 14MM | |
89 | 34-01152-35 | SCREW, CAP HXHDM6 X 35MM | |
90 | 34-60095-30 | WASHER, LOCK M8 X 18MM | |
98 | 34-01153-20 | SCREW, CAP HXHD M8 X 20MM | |
100 | 34-01152-25 | SCREW, CAP HXHDM6 X 25MM | |
116 | 34-60089-05 | NUT, LOCKM5 | |
130 | PL | TUBE, SUCTION1 -3/8” | |
135 | PL | STRAINER ASSY,LIQUID - INCLUDES: | |
136 | 40-00130-05 | TEE, COUPLING 1/2” X 3/8” | |
137 | 14-00176-02 | STRAINER | |
145 | 58-60297-00 | FITTING, AIR SENSING | |
146 | 58-60279-01 | HOSE, AIRCLEAR | |
148 | 58-60279-02 | HOSE, AIR RED | |
168 | 68-13643-00 | PLATE | |
186 | 67-00066-00 | CHANNEL | |
188 | 68-61911-01 | CHANNEL ASSY | |
194 | 68-13525-01 | HOLD DOWN | |
196 | 67-00023-00 | ANGLE | |
215 | 79-01693-04 | FAN ASSY, ENGINESIDE ( FANCOLOR BLACK ) | |
216 | 79-01693-05 | FAN ASSY, COMPRESSOR SIDE ( FANCOLOR WHITE ) | |
226 | 67-00184-00 | BRACKET | |
228 | 68-15115-00 | BRACKET, HEATER | |
230 | 44-00293-28 | CLAMP | |
260 | 34-01152-40 | SCREW, CAP HXHD M8 X 40MM | |
400 | 68-61939-01 | BRACKET, HEATER | |
NS | 58-60065-02SAV | TUBE, FUEL | |
75 | 44-60010-00 PL* | CLAMP, TUBE 1/4” |
80 | 34-01152-30 PL* | SCREW,CAP HXHD M8 X 30MM |
85 | 34-60068-20 | SCREW, M6 X 20MM |
86 | 34-60095-46 PL* | WASHER, LOCK M6 X 18MM |
88 | 34-60095-27 PL* | WASHER, LOCK M6 X 14MM |
89 | 34-01152-35 PL* | SCREW, CAP HXHD M6 X 35MM |
90 | 34-60095-30 PL* | WASHER, LOCK M8 X 18MM |
94 | 34-01153-45 PL* | SCREW,CAP HXHD M8 X 45MM |
98 | 34-01153-20 PL* | SCREW, CAP HXHD M8 X 20MM |
100 | 34-01152-25 PL* | SCREW,CAP HXHD M6 X 25MM |
109 | 34-01184-58 PL* | NUT,LOCK M8 |
138 | 58-00712-22 PL* | CLAMP, HOSE |
142 | 58-60154-01 | GROMMET |
149 | 58-60725-00 | HOSE, DRAIN |
150 | 42-60142-00 | GASKET |
152 | 79-01915-04 | POD, FIBERGLASS WITH GASKETS |
171 | 58-04446-03 | BLOWER HOUSING, CURBSIDE |
172 | 58-04446-02 | BLOWER HOUSING, ROADSIDE |
173 | 58-04455-00 | MOTOR MOUNT |
178 | 67-60707-00 | PLATE ASSY |
192 | 67-00122-00 | COVER ASSY |
207 | 68-13957-00 | COVER |
210 | 73-60110-00 | GRILLE |
225 | 79-60752-00 | EVAPORATOR FRAME ASSY |
250 | 67-00146-00 NSI | PANEL, BACK |
252 | 58-04462-01 | NOZZLE, SUPPLYAIR |
254 | 73-00194-00 | GRILLE, RETURN AIR |
256 | 42-00399-05 | GASKET |
270 | 34-60028-00 PL* | WASHER, FLAT M8 X 30MM |
280 | 34-60174-30 PL* | SCREW, CAP SKTHD M6 X 30MM |
290 | 42-60087-01 | FOAM, BLACK |
510 | 67-60663-00 | BRACKET, TOP PANEL |
520 | 67-60663-01 | BRACKET, TOP PANEL |
530 | 68-70586-00 | PANEL, TOP |
560 | 42-60141-00 | FOAM |
15 | 22-01968-00 | DEFROST THERMOSTAT - INCLUDES: |
16 | 12-00170-07 | THERMOSTAT |
17 | 22-02392-00 SK | CONNECTOR 2 WAYS( MATES WITH 22-1585-00SK ) |
20 | 12-00576-02 | THERMISTOR, DEFROST SENSOR DTT - INCLUDES: |
21 | 22-01585-00 SK | DTT CONNECTOR 2 WAYS ( MATES WITH 22-2392-00SK ) |
22 | 12-00352-03 | TRANSDUCER EVOP ( MATES WITH22-61008-00 ) |
25 | 12-00566-04 | THERMISTOR EVOT - INCLUDES: |
26 | 22-50078-02 SK | EVOT CONNECTOR 2 WAYS ( MATES WITH22-50078-01SK ) |
55 | 12-00566-51 | RAT & SAT SENSOR - INCLUDES: |
56 | 22-50078-01 SK | CONNECTOR 2 WAYS ( MATES WITH22-50078-02SK ) |
88 | 34-60095-27 PL* | WASHER, LOCK M6 X 14MM |
95 | 34-01197-16 PL* | SCREW, CAP HXHDM4 X 16MM |
97 | 34-60095-24 PL* | WASHER, LOCK M4 X 10MM |
100 | 34-01152-25 PL* | SCREW, CAP HXHD M6 X 25MM |
129 | 44-60061-00 | BASE |
235 | 44-00293-25 | CLAMP, STEPLESS |
500 | 42-60122-00 | GASKET |
20 | 10-60018-00 SV | SPEED SOLENOID, 12V - INCLUDES: |
21 | 22-50078-02 SK | CONNECTOR ( MATES WITH22 -50078 -01SK ) |
22 | 58-60201-00 | BOOT |
23 | 12-60041-00 | PLUG ASSY |
35 | 12-00448-01 | RPM SENSOR ( MATES WITH22-50078-100SK ) |
40 | 26-00131-00 | ENGINE, CT4 -91 TV- INCLUDES: |
40 | 26-00131-00 RM | ENGINE, CT4 -91 TV REMAN - INCLUDES: |
NS | 25-15494-00 | GASKET, EXHAUST PIPE |
NS | 29-70321-00 | GLOW PLUG |
NS | 30-60119-00 | OIL FILTER |
43 | 48-60188-09 | SPACER |
45 | 34-00873-30 PL* | SCREW, CAP HXHD M10 X 30MM |
50 | 34-00890-04 PL* | WASHER, FLAT |
54 | 34-00913-38 PL* | SCREW, CAP HXHD |
55 | 34-60082-16 PL* | SCREW, M12 X 16MM |
56 | 34-60095-27 PL* | WASHER, LOCK M6 X 14MM |
60 | 34-00944-10 PL* | WASHER, M10X22MM |
65 | 34-00945-10 PL* | WASHER, LOCK M10 |
70 | 34-00961-35 PL* | SCREW, HM10 X 35MM |
80 | 34-01184-62 PL* | NUT, LOCKM12 |
90 | 34-01241-20 PL* | SCREW, CAP HXHD M8 X 20MM |
91 | 34-01249-25 | SPACER, M8 X 25MM |
100 | 34-06210-00 NSI | PIN, DOWEL |
101 | 34-06333-00 | BOLT, HEX M12 X 1.25MM |
105 | 34-60068-20 | SCREW, M6 X 20MM |
110 | 34-60085-09 PL* | WASHER, M8 X 22MM |
115 | 34-60085-12 PL* | WASHER, M12 |
125 | 34-60109-90 PL* | SCREW, HXHDH M12 X 90MM |
130 | 34-60152-00 PL* | SCREW, M8 X 25MM |
140 | 44-01049-00 | CLIP, RETAINING |
155 | 86-04763-00 | BRACKET ASSY, SNUBBER |
160 | 48-60008-00 NSI | SPACER |
165 | 50-60329-01 | WATER PUMP BELT |
170 | 54-00589-51 | GENERATOR ASSY, 460V - INCLUDES: |
170 | 54-00589-60 | GENERATOR ASSY, 460V REMAN - INCLUDES: |
171 | 54-00630-24 | FAN COVER |
172 | 34-60119-02 PL* | FAN MOUNT BOLT |
173 | 34-06246-00 PL* | FAN MOUNT WASHER |
174 | 54-00630-23 | FAN |
175 | 54-00630-20 | SHIPPING SLEEVE |
176 | 58-60302-06 | GROMMET |
185 | 68-70729-00 | BELT, GUARD |
190 | 73-00175-02 | SHOCKMOUNT |
195 | 73-60081-02 | ROD, LINKAGE |
200 | 86-04793-00 | BRACKET, SOLENOID |
205 | 86-04325-00 | NUT ASSY |
240 | 34-60085-10 PL* | WASHER, M10 X 22MM |
255 | 34-60140-35 PL* | SCREW, CAP SKTHD M10 X 35MM |
270 | 68-16115-00 | BRACKET |
275 | 34-01184-56 PL* | NUT, LOCK M6 |
280 | 44-60013-00 | CLIP, LINKAGE ROD |
290 | 68-16112-00 | ANGLE |
295 | 73-60005-00 | SPRING |
5 | 30-00302-00 | FILTER, FUEL SECONDARY |
10 | 30-60055-05 | BOLT, BANJO |
15 | 34-01249-20 | SPACER, M6 X 25MM |
20 | 34-60000-40 PL* | SCREW, CAP HXHD M5 X 40MM |
25 | 34-60082-25 PL* | SCREW, HEAD CHC M6 X 25MM |
30 | 34-60095-25 PL* | WASHER, LOCK M5 X 12MM |
35 | 34-60095-27 PL* | WASHER, LOCK M6 X 14MM |
40 | 40-60063-00 | SCREW, HOLLOW |
45 | 40-60239-01 | FITTING, HOSE FILTER |
50 | 42-60025-00 | SEAL, BONDED |
55 | 42-60070-06 | UPPER SEAL,14 X 20 X 2 |
58 | 42-60070-08 | LOWER SEAL, 14 X 18 X 1.5 |
60 | 44-60006-00 PL* | CLAMP, DOUBLE |
70 | 44-60042-03 PL* | COLLAR, TUBE |
75 | 44-60042-08 PL* | COLLAR, TUBE |
80 | 48-60063-00 | HEAD FILTER, FUEL |
90 | 79-01855-01 | TUBE ASSY,FUEL LINE |
95 | 79-60523-00 | TUBE ASSY - INCLUDES |
95A | 40-01153-00 | BANJO |
95B | 58-00580-00 | TUBE, RED 3/8” |
95C | 58-60215-02 NSI | TUBE, SLIT |
95D | 44-60042-03 | COLLAR, TUBE |
95E | 40-60236-00 | FITTING, BLACKFEMALE QUICK CONNECT |
95F | 40-60235-10 | FITTING, PURPLEMALE QUICK CONNECT |
100 | 79-60621-01 | HOSE ASSY - INCLUDES: |
100A | 40-60260-01 | FITTING, 3 CONNECTIONS |
100B | 58-00507-00 | TUBE, BLACK 1/4” |
100C | 58-60588-05 | HOSE, 3/16” |
100D | 44-60042-03 | COLLAR, TUBE |
100E | 40-60236-01 | FITTING, BLACK FEMALE QUICK CONNECT |
100F | 40-60235-10 | FITTING, PURPLE MALE QUICK CONNECT |
10 | 12-00592-00 | SWITCH, PRESSURE OIL - INCLUDES: |
11 | 22-50078-01 SK | CONNECTOR 2 WAYS( MATES WITH22-50078-02SK ) |
15 | 30-00450-00 | FILTER, LUBE OIL |
20 | 30-60055-05 | BOLT, BANJO |
25 | 34-01152-30 PL* | SCREW, CAP HXHD M6 X 30MM |
30 | 34-60082-25 PL* | SCREW, HEAD CHC M6 X 25MM |
35 | 34-60095-27 PL* | WASHER, LOCK M6 X 14MM |
40 | 34-60095-46 PL* | WASHER, LOCK M6 X 14MM |
45 | 40-60156-01 | ELBOW |
50 | 42-60025-00 | SEAL BONDED |
55 | 44-60006-00 PL* | CLAMP, DOUBLE |
70 | 48-60063-01 | FILTER HEAD |
80 | 67-00247-00 | BRACKET |
85 | 79-60600-04 | BANJO ASSY, BLACK- INCLUDES: |
90 | 79-60600-05 | BANJO ASSY, RED - INCLUDES: |
91 | 40-60132-06 | CLAMP, TUBE |
92 | 58-00509-00F05 | TUBE, 1/2” |
93 | 40-60026-05 | BANJO |
10A | 30-60125-00 | MUFFLER ( STANDARD VERSION ) |
10B | 30-60125-01 | MUFFLER ( CITY VERSION ) PRIOR TO SERIAL NUMBER ZC145082 |
10B | 30-60125-02 | MUFFLER ( CITY VERSION ) STARTING WITH S/N ZC145082 |
15 | 30-60126-00 | EXHAUST PIPE |
20 | 34-06188-00 PL* | NUT, JAM |
25 | 34-60152-00 PL* | SCREW, HX WASHHDM8 X 25MM |
55 | 68-61113-00 | PANEL ( THERMIC PROTECTION ) |
70 | 68-70768-00 | BRACKET |
85 | 44-60121-00 | BRACKET, CLAMP ( CITY VERSION ) |
100 | 25-15392-00 | STUD, M10 X 22MM |
5 | 30-00430-02 | AIR CLEANER - INCLUDES: |
NS | 30-00430-23 | FILTER |
10 | 34-60152-00 PL* | SCREW, HX HM8 LG 25MM |
12 | 44-60045-09 PL* | CLAMP, HOSE |
15 | 44-60045-11 PL* | CLAMP, HOSE |
20 | 58-60719-00 NSI | PLUG, PIPE 1/8” |
25 | 58-04502-00 | HOSE, AIR INLET ( UP ) |
30 | 58-04826-00 | HOSE, AIR INLET ( LOWER) |
35 | 68-13933-01 | BRACKET |
40 | 86-04309-00 NSI | TUBE ASSY,AIR INLET ( TUBE AND BRACKET ) |
60 | 58-60668-01 | PROTECTOR, END OF HOSE CLAMPS |
10 | 67-60830-00 | BRACKET |
20 | 34-60152-00 PL* | SCREW, HX HM8 LG 25MM |
30 | 30-60074-00 | CLAMP, AIR CLEANER |
40 | 30-00426-01 | AIR CLEANER - INCLUDES: |
NS | 30-00426-20 | PRIMARY FILTER |
41 | 30-00426-22 | COVER ASSY, BOTTOM |
42 | 30-00426-23 | VALVE |
NS | 30-00426-27 | ELEMENT, HIGH CAPACITY WITH TUBE ( FINAL ) |
50 | 34-01152-30 PL* | SCREW, CAP HXHD M6 X 30MM |
60 | 34-60095-46 PL* | WASHER, LOCK M6 X 18MM |
70 | 58-60636-01 | HOSE, AIR INLET ( LOWER ) |
80 | 44-60045-11 PL* | CLAMP, HOSE |
90 | 58-60814-00 | HOSE, AIR INLET ( UP ) |
100 | 34-01184-56 PL* | NUT, LOCK M6 |
120 | 44-60041-86 PL* | CLAMP |
130 | 44-60045-09 PL* | CLAMP, HOSE |
140 | 58-60668-01 | PROTECTOR, END OF HOSE CLAMPS |
1 | 58-60524-03 | COOLANT BOTTLE |
3 | 12-01145-04 | ENCT ENGINE COOLANT TEMPERATURE SENSOR - INCLUDES: |
NS | 22-50078-02 SK | CONNECTOR 2 WAYS( MATES WITH22-50078-01SK ) |
5 | 30-60014-00 | CAP, COOLANT BOTTLE |
6 | 34-01152-70 PL* | SCREW, CAP HXHD M6 X 70MM |
7 | 34-01184-56 PL* | NUT, LOCK M6 |
8 | 34-60095-46 PL* | WASHER, LOCK M6 X 18MM |
10 | 44-60045-09 PL* | CLAMP, HOSE |
12 | 44-60045-14 PL* | CLAMP |
15 | 44-60011-03 PL* | CLAMP |
20 | 44-60044-13 PL* | CLAMP |
24 | 44-60042-13 PL* | CLAMP |
25 | 44-60042-08 PL* | COLLAR, TUBE |
26 | 34-60068-20 | SCREW, M6 X 20MM |
30 | 58-04859-00 | HOSE, RADIATOR INLET |
32 | 58-04825-00 | HOSE, RADIATOR OUTLET |
36 | 58-60688-02 | HOSE, FUEL |
38 | 58-60862-00 | HOSE, FORMED |
50 | 68-70724-00 | BRACKET ASSY |
55 | 40-60319-00 | FITTING |
60 | 40-60320-01 | ELBOW, 90_ 1/4”x 3/8” |
75 | 58-60668-00 | PROTECTOR, ENDOF HOSE CLAMPS |
80 | 58-60668-01 | PROTECTOR, ENDOF HOSE CLAMPS |
90 | 44-60121-00 | BRACKET |
| 22-60928-02 NSI | HARNESS, ENGINE- INCLUDES: |
5 | 22-50098-16 SK | 2MP BLACK CONNECTOR, PLUG ASSY 35 WAYS |
5 | 22-50098-17 SK | 1MP WHITE CONNECTOR, PLUG ASSY 35 WAYS |
5 | 22-50098-18 SK | 3MP GREY CONNECTOR, PLUG ASSY 35 WAYS |
6 | 22-50098-19 SK | KIT PIN FOR 22-50098-16SK/17SK/18SK |
10 | 22-50078-01 SK | OC2 ENCT EVOT SCS CST CONNECTOR 2 WAYS ( MATES WITH 22-50078-02SK ) |
15 | 22-50078-05 SK | SLP FS CONNECTOR 3 WAYS ( MATES WITH 22-50078-08SK ) |
20 | 22-01660-03 SK | SATCOM CONNECTOR 5 WAYS |
21 | 22-01660-05 | DUST CAP FOR CONNECTOR 5 WAYS |
25 | 22-50078-02 SK | RAT AAT SAT ENOPS CONNECTOR 2 WAYS ( MATES WITH 22-50078-01SK ) |
30 | 22-61008-00 | EVOP CDP CSP CONNECTOR 3 WAYS |
35 | 22-50098-22 SK | EVXV CONNECTOR 5 WAYS ( MATES WITH22-50098-23SK ) |
40 | 22-02392-00 SK | DTT CDT CONNECTOR 2 WAYS ( MATES WITH22-01585-00SK ) |
45 | 22-50098-11 SK | HC CONNECTOR 19 WAYS ( MATES WITH22-50098-10SK ) |
50 | 22-50098-06 SK | SS CONNECTOR 1 WAY ( MATES WITH22-50098-05SK ) |
55 | 22-50078-30 SK | SM CONNECTOR 1 WAY ( MATES WITH22-50078-31SK ) |
60 | 22-50078-100 SK | ENRPM CONNECTOR 3 WAYS |
65 | 22-01613-02 SK | ESV LIV USV CONNECTOR 2 WAYS ( MATES WITH22-01613-00SK ) |
70 | 22-50078-07 SK | GRD1 CONNECTOR 1 WAY ( MATES WITH 22-50078-21SK ) |
85 | 22-01585-04 SK | CSMV CONNECTOR 4 WAYS ( MATES WITH22-02392-03SK ) |
95 | 22-50078-44 SK | LB CONNECTOR 10 WAYS ( MATES WITH 22-50078-45SK ) |
120 | 22-01737-00 | CONNECTION CABLE FOR SERIAL PORT- INCLUDES: |
125 | 22-01660-04 SK | CONNECTOR 5 WAYS |
| 22-60928-02 NSI | HARNESS, ENGINE- INCLUDES: |
5 | 22-50098-16 SK | 2MP BLACK CONNECTOR, PLUG ASSY 35 WAYS |
5 | 22-50098-17 SK | 1MP WHITE CONNECTOR, PLUG ASSY 35 WAYS |
5 | 22-50098-18 SK | 3MP GREY CONNECTOR, PLUG ASSY 35 WAYS |
6 | 22-50098-19 SK | KIT PIN FOR 22-50098-16SK/17SK/18SK |
10 | 22-50078-01 SK | OC2 ENCT EVOT SCS CST CONNECTOR 2 WAYS ( MATES WITH 22-50078-02SK ) |
15 | 22-50078-05 SK | SLP FS CONNECTOR 3 WAYS ( MATES WITH 22-50078-08SK ) |
20 | 22-01660-03 SK | SATCOM CONNECTOR 5 WAYS |
21 | 22-01660-05 | DUST CAP FOR CONNECTOR 5 WAYS |
25 | 22-50078-02 SK | RAT AAT SAT ENOPS CONNECTOR 2 WAYS ( MATES WITH 22-50078-01SK ) |
30 | 22-61008-00 | EVOP CDP CSP CONNECTOR 3 WAYS |
35 | 22-50098-22 SK | EVXV CONNECTOR 5 WAYS ( MATES WITH22-50098-23SK ) |
40 | 22-02392-00 SK | DTT CDT CONNECTOR 2 WAYS ( MATES WITH22-01585-00SK ) |
45 | 22-50098-11 SK | HC CONNECTOR 19 WAYS ( MATES WITH22-50098-10SK ) |
50 | 22-50098-06 SK | SS CONNECTOR 1 WAY ( MATES WITH22-50098-05SK ) |
55 | 22-50078-30 SK | SM CONNECTOR 1 WAY ( MATES WITH22-50078-31SK ) |
60 | 22-50078-100 SK | ENRPM CONNECTOR 3 WAYS |
65 | 22-01613-02 SK | ESV LIV USV CONNECTOR 2 WAYS ( MATES WITH22-01613-00SK ) |
70 | 22-50078-07 SK | GRD1 CONNECTOR 1 WAY ( MATES WITH 22-50078-21SK ) |
85 | 22-01585-04 SK | CSMV CONNECTOR 4 WAYS ( MATES WITH22-02392-03SK ) |
95 | 22-50078-44 SK | LB CONNECTOR 10 WAYS ( MATES WITH 22-50078-45SK ) |
120 | 22-01737-00 | CONNECTION CABLE FOR SERIAL PORT- INCLUDES: |
125 | 22-01660-04 SK | CONNECTOR 5 WAYS |
| 91-60321-10 NSA | CONTROL BOX ASSY - INCLUDES: |
10 | 79-60605-00 NSI | BOX ASSY- INCLUDES: |
NS | 86-61020-00 | BOX ONLY |
11 | 68-61644-01 NSI | DOOR |
12 | 44-00356-00 | HINGE |
13 | 44-00356-10 | HINGE AXLE |
14 | 58-60306-05 PL* | WASHER, M5 X 15MM |
15 | 34-60068-20 | SCREW, M6 X 20MM |
16 | 58-60306-06 PL* | WASHER, M6 X 18MM |
20 | 58-60298-03 | GROMMET, TAP ( STANDBY VERSION ) |
30 | 58-60631-21 | GROMMET, CABLE |
40 | 58-60631-00 | GROMMET, BRACKET |
50 | 58-60631-16 | GROMMET, CABLE |
60 | 34-60089-05 PL* | NUT, LOCK M5 |
65 | 34-60101-20 PL* | SCREW, CAP SKTHD M5 X 20MM |
70 | 44-60061-00 NSI | BASE, TY WRAP |
90 | 10-00375-01 | INDICATOR BUZZER |
120 | 34-60089-06 PL* | NUT, LOCK M6 |
190 | 68-70329-00 PL* | BRACKET |
200 | 42-60081-00 | GASKET, DOOR |
380 | 91-60255-01 NSA | BOX, STAND-BY FOR STANDARD - INCLUDES: |
380 | 91-60255-02 NSA | BOX, STAND -BY FOR LOW NOISE- INCLUDES: |
381 | 22-60389-00 | RECEPTACLE ASSY, 380 -5 -32A |
382 | 22-02324-01 | PIN |
383 | 58-60298-03 | GROMMET |
384 | 22-60299-14 | CABLE, ELECTRIC |
385 | 67-60365-02 | PLATE ASSY FOR STANDARD |
385 | 67-60531-00 | PLATE ASSYFOR LOW NOISE |
386 | 34-60002-05 PL* | WASHER, M5 |
387 | 34-01184-05 PL* | NUT, LOCK M5 |
388 | 58-60661-00 | CAP, SEAL |
390 | 62-02146-00 | DECAL, WARNING AUTOSTART |
400 | 62-03957-01 | DECAL, WARNING HIGH VOLTAGE |
410 | 58-00660-00 PL* | WASHER, CONDENSATE DRAIN |
430 | 44-01139-02 PL* | CABLE CLAMP |
470 | 62-60946-01 NSI | DECAL, COMPONENTS |
| 91-60321-10 NSA | CONTROL BOX ASSY - INCLUDES: |
60 | 34-60089-05 PL* | NUT, LOCK M5 |
100 |
| PANEL ASSY, OGF - INCLUDES: |
100A | PL | BRACKET |
100B | 34-60000-10 PL* | SCREW, MACH HXHD M5 X 10MM |
100C | 34-06206-14 PL* | SCREW, CAP PNHD M4 X 14MM |
100D | 34-60095-25 PL* | WASHER, LOCK M5 X 12MM |
100E | 22-01196-17 | F4 F7 F8 BATTERY CHARGER FUSE, TIME DELAYED 4A 600V |
100E | 22-01196-25 | BATTERY CHARGER FUSE,TIME DELAYED 6A 600V ( ADDITIONAL OPTION ) |
100F | 22-01196-30 | F18 F19 F20 CONDENSER FUSE,TIME LAG 12A 600V |
100G | 22-01196-15 | F10 F11 F12 HEATER FUSE,QUICK 12A 600V |
100H | 22-60540-20 | FUSE HOLDER, 3 POLES |
100I | 22-60540-10 | FUSE HOLDER, 2 POLES |
100J | 10-00471-03 | HTCON2 EVCON CDCON CONTACTOR, 9A |
100K | 10-00433-00 | CCON PSCON2 GENCON CONTACTOR, 30A |
100L | 10-00433-06 | PSCON1 HTCON1 CONTACTOR, 30A |
100L1 | 10-00433-50 | REVERSAL CONNECTION KIT |
100M | 10-00451-00 | OGF MODULE |
100N | 10-00392-21 | MECHANICAL INTERLOCK |
100P | 22-60870-02 | JUNCTION BLOCK, 105MM + 2 END STOP |
100Q | 22-60870-01 | JUNCTION BLOCK,230MM + 1JB +1 END STOP |
110 | 58-00836-11 PL* | SPACER, NYLON |
120 | 34-60089-06 PL* | NUT, LOCK M6 |
130 | 34-60101-16 PL* | SCREW, CAP SKTHD M5 X 16MM |
140 | 34-60095-25 PL* | WASHER, LOCK M5 X 12MM |
150 | 12-00438-16 | MODULE, LOGIC BOARD - INCLUDES: |
NS | 10-00385-04 | RELAY |
NS | 22-02336-08 | FUSE, 7.5 A |
NS | 22-02336-04 | FUSE, 10 A |
160 | 67-60231-00 PL* | BRACKET |
170 | 34-01152-50 PL* | SCREW, CAP HXHD M6 X 50MM |
180 | 34-60095-46 PL* | WASHER, LOCK M6 X 18MM |
210 | 12-00520-01 | DETECTOR, PHASE REVERSAL ( EXCEPT NO STANDBY ) |
220 | 68-12979-00 PL* | GROUND STRAP |
230 | 22-60599-00 SK | FUSE, HOLDER |
280 | 22-60340-02 | FUSE, MIDIFUSE 60A |
290 | 34-60095-24 PL* | WASHER, LOCK M4 X 10MM |
300 | 34-01184-54 PL* | NUT, LOCK M4 |
310 | 10-00328-00 | RELAY, 70A |
320 | 10-00385-00 | RELAY |
330 | 22-50098-01 | RECEPTACLE, RELAY |
350 | 10-00366-03 | CURRENT SENSOR |
360 | 22-60927-00 NSI | HARNESS, CONTROL BOX ( SEESECTION 10.2.1 ) |
420 | 22-60626-00 | HARNESS, MICRO/ DISPLAY ( SEE SECTION10.2.1 ) |
480 | 22-02336-04 | FUSE, 10A |
490 | 22-02336-08 | FUSE, 7.5A |
500 | 22-02336-06 | FUSE, 15A |
520 | 22-02336-50 | FUSE REMOVAL TOOL |
| 22-60927-00 NSI | HARNESS, CONTROL BOX- INCLUDES: |
5 | 22-01622-02 SK | 4MP CONNECTOR 16 WAYS |
7 | 22-01622-01 SK | 5MP CONNECTOR 12 WAYS |
10 | 22-60275-11 SK | C2 CONNECTOR 2 WAYS ( MATES WITH 22-60275-21SK ) |
15 | 22-50098-10 SK | HC CONNECTOR 19 WAYS ( MATES WITH22-50098-11SK ) |
20 | 22-50078-18 SK | CONNECTOR ( MATES WITH RELAY 10-00328-00 ) |
25 | 22-50098-01 SK | CONNECTOR ( MATES WITH RELAY 10-00385-00 ) |
30 | 91-60260-00 NSI | JUNCTION BOX- INCLUDES: |
31 | NSS | BOX |
32 | NSS | JUNCTION BLOCK- INCLUDES: |
33 | NSS | RAIL 0.11M |
34 | NSS | FITTING |
35 | NSS | FITTING |
NS | 62-61430-00 | DECAL ON INTERNAL COVER |
NS | 62-03957-01 | DECAL, WARNING HIGH VOLTAGE |
40 | 22-50098-48 SK | HTR 1,2&3 CONNECTOR 4 WAYS ( MATES WITH22-50098-47SK ) |
45 | 22-01585-00 SK | EVHTS CONNECTOR 2 WAYS ( MATES WITH22-02392-00SK ) |
50 | 22-01613-18 SK | CDM1&2 CONNECTOR 2 WAYS ( MATES WITH 22-01613-16SK ) |
55 | 22-01613-06 SK | BTYC CONNECTOR 3 WAYS ( MATES WITH 22-01613-04SK ) |
57 | 22-04193-50 | CABLE, POWERSCROLL COMPRESSOR |
60 | 22-60626-00 | HARNESS, MICRO / DISPLAY - INCLUDES: |
65 | 22-50078-44 SK | DISPLAY CONNECTOR 10 WAYS ( MATES WITH22-50078-45SK |
70 | 22-50078-73 SK | RS CONNECTOR 2 WAYS ( MATES WITH 22-50078-72SK ) |
75 | 22-60275-21 SK | C2 CONNECTOR 2 WAYS ( MATES WITH 22-60275-11SK ) |
80 | 22-01622-00 SK | 6MP CONNECTOR 8 WAYS |
A |
| DISPLAY ASSY - INCLUDES : |
1 | 10-01129-02 SV | SWITCH, TOGGLE |
3 | 10-01129-10 | SWITCH, TOGGLE |
3A | 58-60158-04 | SWITCH, CAP |
4 | 22-01851-04 | HARNESS - INCLUDES : |
NS | 22-50078-45 SK | C10 CONNECTOR 10 WAYS( MATES WITH22-50078-44SK ) |
NS | 22-50078-72 SK | C2 CONNECTOR 2 WAYS( MATES WITH22-50078-73SK ) |
NS | NSS | DISPLAY RIBBON CONNECTOR 8 WAYS |
5 | 34-60095-25 PL* | WASHER, LOCK M5 X 12MM |
7 | 34-60000-25 PL* | SCREW, CAP HXHD M5 X 25MM |
10 | 68-12877-01 | BRACKET |
11 | 91-00312-03 SK | DISPLAY PANEL ( SEE DETAILSECTION 11.1. ) - INCLUDES: |
12 | 62-02448-04 | DECAL, SWITCH |
13 | 62-10237-00 | DECAL, CAUTION |
16 | 34-60244-00 | WASHER, QUICK DISCONNECT |
35 | 34-60068-20 | SCREW, M6 X 20MM |
| 91-00312-03 SK | DISPLAY PANEL - INCLUDES : |
1 | 76-50125-00 | KEY PAD ASSY |
2 | 76-61145-00 | DISPLAY ASSY- INCLUDES: |
NS | 42-00502-00 | GASKET |
3 | 34-06129-06 PL* | SCREW, TF PNHD |
4 | 34-06196-10 PL* | SCREW, TF PNHD |
5 | 34-06196-11 PL* | SCREW, TF PNHD |
6 | 42-00396-00 NSI | GASKET |
7 | 42-00405-00 NSI | GASKET |
8 | 58-01395-00 NSI | BEZEL, MICRO |
9 | NSS | SUPPORT |
10 | 58-01396-02 SV | DOOR ASSY |
11 | 58-04342-00 SV | WINDOW |
12 | 58-04344-01 SV | LATCH - INCLUDES: |
13 | NSS | SPRING |
14 | 58-04385-00 | PLUG, HOLE |
15 | 58-00660-00 PL* | WASHER |
17 | 34-00829-09 PL* | WASHER, PLAIN |
18 | 42-60113-00 | GASKET |
NS | 62-10353-00 | DECAL, LOGICOLD |
10 | 22-60921-10 | CABLE, BATTERY + - INCLUDES: |
NS | 22-60923-00 | TERMINAL, BATTERY |
NS | 22-60923-50 | CAP, TERMINAL BATTERY |
15 | 22-60922-00 | CABLE, BATTERY - - INCLUDES: |
NS | 22-60924-00 | TERMINAL, BATTERY |
NS | 22-50078-21 SK | GRD1 CONNECTOR 1 WAY ( MATES WITH 22-50078-07SK ) |
16 | 22-60359-02 | STRAP, GROUND |
19 | 12-00683-02 | BATTERY CHARGER, 12V 40A - INCLUDES : |
NS | 22-50078-39SK | BTYC OUTPUT CONNECTOR 2W ( MATESWITH 22-50078-40SK ) |
NS | 22-50098-46SK | BTYC INPUT CONNECTOR 3W ( MATESWITH 22-01660-01SK ) |
20 | 30-60110-02 | BATTERY, 75A |
22 | 34-01152-35 PL* | SCREW, CAP HXHDM6 X 35MM |
25 | 34-60089-06 PL* | NUT, LOCKM6 |
28 | 34-60201-03 PL* | NUT, LOCKM8 |
31 | 34-60095-27 PL* | WASHER, LOCK M6 X 14MM |
32 | 34-60095-30 PL* | WASHER, LOCK M8 X 18MM |
34 | 34-60096-09 PL* | WASHER, LOCK M8 X 16MM |
35 | 34-60152-00 PL* | SCREW, HX WASSHED HM8 LENGTH 25MM |
36 | 34-60068-20 | SCREW, M6 X 20MM |
37 | 34-60087-50 PL* | SCREW, CAP SKTHD M8 X 50MM |
45 | 44-60133-00 | BASE, CLAMP |
50 | 44-60121-00 | BRACKET, CLAMP |
65 | 67-00239-00 | BRACKET, BATTERY |
85 | 68-70567-00 | BRACKET, UPPER |
90 | 67-00240-00 | BRACKET, FRONT |
100 | 67-00120-00 | BRACKET, CLAMP DOUBLE |
105 | 67-00235-00 | NUT, PLATE |
TAIL LIFT OPTION:
500 | 12-00683-20 | BATTERY CHARGER, 12V 40A - INCLUDES : |
500 | 12-00683-01 | BATTERY CHARGER, 24V 20A - INCLUDES : |
NS | 22-50078-39 SK | BTYC OUTPUT CONNECTOR 2W ( MATESWITH 22-50078-40SK ) |
NS | 22-50098-46 SK | BTYC INPUT CONNECTOR 3 WAYS ( MATES WITH22-01660-01SK ) |
505 | 68-70762-00 | BRACKET, BATTERY CHARGER |
510 | 34-60152-00 PL* | SCREW, HXHD M8 X 25MM DACROMET |
510 | 34-60152-01 PL* | SCREW, HXHDM8 X 25MM ZINC FLAKE |
520 | 67-00235-00 | NUT, PLATE |
NS | 76-61416-01 NSA | DC HARNESS KIT, PROLONGATOR 18M- INCLUDES: |
NS | 22-60930-02 | DC HARNESS, BTYC2+ |
NS | 22-60930-03 | DC HARNESS, BTYC2 - |
NS | 22-60599-00 SK | FUSE HOLDER |
NS | 22-60340-07 | FUSE, 30A |
NS | 22-60930-00 | AC HARNESS, BATTERY CHARGER SUPPLY - INCLUDES: |
NS | 22-01613-06 SK | BTYC2 CONNECTOR 3 WAYS ( MATES WITH22-01613-04SK ) |
NS | 58-60298-03 | GROMMET |
NS | 22-01196-25 | BATTERY CHARGER FUSE,TIME LAG 6A 600V |
10 | 22-60921-10 | CABLE, BATTERY + - INCLUDES: |
11 | 22-60923-00 | TERMINAL, BATTERY |
12 | 22-60923-50 | CAP, TERMINAL BATTERY |
15 | 22-60922-00 | CABLE, BATTERY - - INCLUDES: |
16 | 22-60924-00 | TERMINAL, BATTERY |
NS | 22-50078-21SK | GRD1 CONNECTOR 1 WAY ( MATES WITH 22-50078-07SK ) |
17 | 22-60359-02 | STRAP, GROUND |
19 | 12-00683-02 | BATTERY CHARGER, 12V 40A - INCLUDES : |
NS | 22-50078-39SK | BTYC OUTPUT CONNECTOR 2W ( MATES WITH 22-50078-40SK ) |
NS | 22-50098-46SK | BTYC INPUT CONNECTOR 3W ( MATES WITH 22-01660-01SK ) |
20 | 30-60110-02 | BATTERY, 75A |
22 | 34-01152-35 PL* | SCREW, CAP HXHD M6 X 35MM |
25 | 34-60089-06 PL* | NUT, LOCK M6 |
28 | 34-60201-03 PL* | NUT, LOCK M8 |
31 | 34-60095-27 PL* | WASHER, LOCK M6 X 14MM |
32 | 34-60095-30 PL* | WASHER, LOCK M8 X 18MM |
34 | 34-60096-09 PL* | WASHER, LOCK M8 X 16MM |
35 | 34-60152-00 PL* | SCREW, HX WASSHED HM8 LENGTH 25MM |
37 | 34-60087-50 PL* | SCREW, CAP SKTHD M8 X 50MM |
40 | 34-01184-58 PL* | NUT, LOCKM8 |
45 | 44-60133-00 | BASE, CLAMP |
50 | 44-60121-00 | BRACKET, CLAMP |
65 | 58-60827-00 | BRACKET, BATTERY |
85 | 68-70842-00 | BRACKET |
90 | 34-60272-00 | TIE ROD |
100 | 67-00120-00 | BRACKET, CLAMP DOUBLE |
105 | 67-00235-00 | NUT, PLATE |
110 | 34-60085-09 PL* | WASHER, M8 X 22MM |
TAIL LIFT OPTION:
500 | 12-00683-20 | BATTERY CHARGER, 12V 40A - INCLUDES : |
500 | 12-00683-01 | BATTERY CHARGER, 24V 20A - INCLUDES : |
NS | 22-50078-39 SK | BTYC OUTPUT CONNECTOR 2W ( MATES WITH 22-50078-40SK ) |
NS | 22-50098-46 SK | BTYC INPUT CONNECTOR 3 WAYS ( MATES WITH22-01660-01SK ) |
505 | 68-70762-00 | BRACKET, BATTERY CHARGER |
510 | 34-60152-00 PL* | SCREW, HXHD M8 X 25MM DACROMET |
510 | 34-60152-01 PL* | SCREW, HXHD M8 X 25MM ZINC FLAKE |
520 | 67-00235-00 | NUT, PLATE |
NS | 76-61416-01 NSA | DC HARNESS KIT, PROLONGATOR 18M - INCLUDES: |
NS | 22-60930-02 | DC HARNESS, BTYC2+ |
NS | 22-60930-03 | DC HARNESS, BTYC2- |
NS | 22-60599-00 SK | FUSE HOLDER |
NS | 22-60340-07 | FUSE, 30A |
NS | 22-60930-00 | AC HARNESS, BATTERY CHARGER SUPPLY - INCLUDES: |
NS | 22-01613-06 SK | BTYC2 CONNECTOR 3 WAYS ( MATES WITH22-01613-04SK ) |
NS | 58-60298-03 | GROMMET |
NS | 22-01196-25 | BATTERY CHARGER FUSE,TIME LAG 6A 600V |
10 | 62-61771-00 | DECAL, WARNING BATTERY PRIOR TO SERIAL NUMBER ZC316059 |
11 | 62-61771-01 | DECAL, WARNING BATTERY STARTING WITH S/N ZC316059 |
25 | 62-60942-00 | DECAL, SERVICE |
50 | 62-10353-00 | DECAL, LOGO LOGICOLD |
70 | 62-02142-01 | DECAL, CAUTION RADIATOR FILL |
100 | 62-61774-00 | DECAL, WARNING |
141 | 62-61648-00 | LOGO, CARRIER VISIBILITY |
180 | 62-10383-00 NSI | DECAL, STARTUP DELAY |
190 | 62-60280-00 NSI | DECAL, STANDBY SAFETY |
210 | 62-10358-00 NSI | LABEL, DANGER |
215 | 62-02144-02 | DECAL, DANGER BELT ROTATION |
220 | 62-03957-01 | DECAL, WARNING HIGH VOLTAGE |
225 | 62-61342-01 NSS | DECAL, ENGINE SPEED SETTING |
310 | 62-60008-02 | DECAL, CARRIER |
315 | 62-61765-00 | DECAL, VECTOR 1550 |
320 | 62-61343-00 | DECAL, WARNING DISCONNECT BATTERY ( STANDARD VERSION ) |
320 | 62-02139-01 | DECAL, WARNINGDISCONNECT BATTERY ( CITY VERSION ) |
325 | 62-60390-03 | DECAL, CARRIER |
330 | 62-02143-01 | DECAL, WARNING BEWARE OF FAN BLADE |
335 | 62-61476-00 | DECAL, DANGER FAN ROTATION |
345 | 62-03958-00 NSI | DECAL, WARNING HEAT HAZARD |
350 | 62-60787-00 NSI | DECAL, ARROW |
430 | 62-03882-00 | DECAL, CARRIER TRANSICOLD |
470 | 62-60192-00 | DECAL, WARNING ROTATION |
480 | 62-11263-02 | DECAL, POE COMPRESSOR OIL |
485 | 62-61753-00 | DECAL, WARNING |
570 | 62-61621-02 | DECAL, LOGO CITY |
| 76-61320-40 | COLDTOUCH FULL PACKAGE- INCLUDES: |
10 | NSS | DISPLAY, COLDTOUCH |
15 | 12-00699-50 | CRADLE |
20 | NSS | TRANSMITTER |
30 | 22-60956-00 | HARNESS, COLD TOUCH - INCLUDES: |
NS | 22-02336-10 | FUSE, 1A |
40 | 22-60957-00 | HARNESS, TRANSMITTER - INCLUDES: |
NS | 22-02336-03 | FUSE, 3A |
| 76-61320-10 | COLDTOUCH SCREEN PACKAGE - INCLUDES: |
10 | NSS | DISPLAY, COLDTOUCH |
15 | 12-00699-50 | CRADLE |
30 | 22-60956-00 | HARNESS, COLDTOUCH - INCLUDES: |
NS | 22-02336-10 | FUSE, 1A |
| 76-61320-20 | COLDTOUCH REMOTE PACKAGE - INCLUDES: |
20 | NSS | TRANSMITTER |
40 | 22-60957-00 | HARNESS, TRANSMITTER - INCLUDES: |
NS | 22-02336-03 | FUSE, 3A |
1 | 07-00375-00SV | CSMV DRIVE TESTER |
2 | 07-60085-02 | GENERATOR MB LIFT TOOL |
3 | 07-60122-00 | ROD THREADED |
4 | 07-60083-01 | LOCK BELL TOOL |
5 | SKM 5670 | BRACKET |
6 | 07-60137-00 | GENERATOR SPACER |
1 | 07-60030-00 | CRIMPING PLIER FOR DEUTSCH CONNECTORS |
2 | 07-60036-00 | EXTRACTING TOOL SIZE 4 ( WHITE) |
2 | 07-60035-00 | EXTRACTING TOOL SIZE 8 ( GREEN ) |
2 | 07-60034-00 | EXTRACTING TOOL SIZE 12 ( YELLOW ) |
2 | 07-60031-00 | EXTRACTING TOOL SIZE 16S ( BRIGHT BLUE ) |
2 | 07-60033-00 | EXTRACTING TOOL SIZE 16 ( DARK BLUE ) |
2 | 07-60032-00 | EXTRACTING TOOL SIZE 20 ( RED ) |
3 | 07-60038-00 | CRIMPING PLIER GM FOR PACKARD CONNECTORS |
4 | 07-60037-00 | CRIMPING PLIER LM FOR PACKARD CONNECTORS |
© All Rights Reserved
refxolod.ru
