Каталог запчастей рефрижераторов Thermo King SLXe 300


CYLINDER BLOCK GROUP (TK486V)

REF

PART#

DESCRIPTION

QTY



101-380

ENGINE (TK486V, interim TIER 4 compliant, 12V,2200 rpm)

1



101-365

ENGINE (TK486V, interim TIER 4 compliant, 12V,2600 rpm)

1

1

NSS

•  BLOCK - cylinder

1

2

11-5499

•  PLUG - frost (30 mm)

8

3

55-6176

•  PLUG - pipe (1/4)

3

4

55-6229

•  PLUG

1

5

55-4593

PLUG - pipe (1/8)

1

6

51-1188

•  PLUG - frost (50 mm)

1

7

11-6555

•  PLUG - frost (12 mm)

2

8

13-318

•  SPACER

1

9

13-926

•  BUSHING - camshaft

1

10

13-927

•  BEARING - thrust (std)

2



13-928

•  BEARING - thrust (0.25mm os)

2

11

13-920

•  BEARING - main

5



13-921

•  BEARING - main (0.25mm us)

5

12

NSS

•  CAP - bearing

4

13

55-8852

•  BOLT - bearing cap

10

14

11-8919

LINER - service

4

15

41-2317

HEATER - frost plug

1





CRANKSHAFT & PISTON GROUP (TK486V)

REF

PART#

DESCRIPTION

QTY

1

13-1064

PISTON (std,incl 2-4)

4



13-1065

PISTON (w/ ring, 0.25 mm os)

4



13-1066

PISTON (w/ ring, 0.50 mm os)

4

2

13-355

RING SET (std)

2



13-461

RING SET (0.25 mm os)

4



13-455

RING SET (0.50 mm os)

4

3

11-8950

PIN - piston

4

4

11-8951

CIRCLIP

8

5

11-8952

ROD - connecting

4

6

11-8953

BUSHING - piston pin

4

7

13-924

BEARING - connecting rod(std)

4



13-925

BEARING - connecting rod (0.25 mm us)

4

8

55-8865

BOLT - connecting rod

8

9

12-750

FLYWHEEL

1

10

11-8947

•  GEAR - ring (before11/08)

1



13-1138

•  GEAR - ring (11/08& after)

1

11

55-8864

BOLT - flywheel

6

12

55-5816

PIN - dowel

1

13

13-351

CRANKSHAFT

1

14

11-6719

•  KEY - gear

1

15

13-352

GEAR - crankshaft

1

16

55-4668

PIN - spring

1

17

13-353

PULLEY - crankshaft

1

18

55-6249

WASHER

1

19

55-6250

BOLT - v-pulley

1

20

11-9592

SPEEDI SLEEVE- front seal

1


NOTE:     NOTE: Enginesbefore serial number EA00749, use gear ring 11-8947. Engineswith serial number EA00749 and after, use gear ring 13-1138.

CAMSHAFT & DRIVE GEAR GROUP (TK486V)

REF

PART#

DESCRIPTION

QTY

1

11-9261

CAMSHAFT (inclitems 2 thru5)

1

2

11-6719

•  KEY - gear

1

3

NSS

•  BEARING - thrust

1

4

55-5801

•  BOLT - plate

2

5

NSS

•  GEAR - camshaft

1

6

11-6717

TAPPET

8

7

11-8945

ROD - push

8

8

13-930

GEAR (w/bushing)

1

9

13-348

•  BUSHING - idler gear

1

10

13-345

SHAFT - idler gear

1

11

55-5772

SCREW - gear

2

12

101-362

PUMP - fuel injection (2200 rpm, see 204G1)

1



101-354

PUMP - fuel injection (2600 rpm, see 205C5)

1

13

51-2009

KEY - gear

1

14

13-350

FLANGE

1

15

13-349

GEAR - injection pump

1

16

55-9222

SCREW - gear

4

17

13-346

CAM - feed pump

1

18

55-9223

SCREW - cam

4

19

51-1154

WASHER

1

20

51-1155

NUT

1


GEAR CASE GROUP (TK486V)

REF

PART#

DESCRIPTION

QTY

1

13-319

CASE - gear

1

2

51-1146

STUD - injection pump

3

3

51-594

NUT

3

4

33-1953

O-RING - injection pump

1

5

203-348

GASKET - adhesive

A/R

6

55-5816

PIN - dowel

1

7

55-6234

PIN - dowel

2

8

55-8441

SCREW - case (16mm)

3

9

55-5809

SCREW - case (45mm)

1

10

33-3821

O-RING - gear case(16 mm)

1

11

33-4089

O-RING - gear case(20 mm)

1

12

13-322

COVER - gear case

1

13

33-4088

SEAL - oil

1

14

55-6367

STUD - fuel pump

3

15

55-6236

SCREW - cover (55 mm)

8

16

11-5082

COVER

1

17

55-4622

WASHER - sealing

4

18

55-8854

SCREW - cover (12 mm)

4

19

13-321

COVER - sound shield

1

20

33-4087

GASKET - cover

1

21

55-6237

SCREW - cover (85 mm)

7

22

11-5091

CAP - oil fill

1

23

33-1954

O-RING - cap

1

24

11-9592

SPEEDI SLEEVE- front seal

1

25

204-1011

TOOL - injection pumpgear remover

1


FLYWHEEL HOUSING GROUP (TK486V)

REF

PART#

DESCRIPTION

QTY

1

12-867

HOUSING - flywheel

1

2

11-6031

PLUG - access hole

1

3

55-8856

SCREW - housing (30 mm)

4

4

55-6537

SCREW - housing (25 mm)

6

5

55-8855

SCREW - plug (M12x 16)

1

6

55-5816

PIN - dowel

2

7

11-8924

CASE - oil seal

1

8

33-2974

SEAL - oil (axial)

1

9

33-2969

GASKET - oil sealcase

1

10

51-1149

SCREW - case (30mm)

6

11

55-6191

SCREW - case (35mm)

3

12

55-5816

PIN - dowel

2

13

51-1162

SCREW - housing

1

14

204-952

TOOL - seal installer

1

15

204-994

TOOL - seal remover

1


ENGINE COUPLING

REF

PART#

DESCRIPTION

QTY



102-900

COMPRESSOR - X430 LS C5 (dry,see 223C5)

1



8102-900

COMPRESSOR - X430 LS C5 (TSA,dry reman, see 223C5)

1



8102-972

COMPRESSOR - X430 LS C5 (EMEIA, dry reman, see 223C5)

1



8102-902

COMPRESSOR - X430LS C5 (7 qt sump,reman, see 230C8)

1



102-901

COMPRESSOR - X426 LS C5 (see226C5, EMEIA)

1



8102-901

COMPRESSOR - X426 LS C5 (see226C5, reman, EMEIA)

1

1

22-1027

CRANKSHAFT - X430

1

2

22-1101

SEAL - bellows (for 1.188 dia crankshaft)

1

3

22-1028

COVER - drive end

1

4

33-3004

SEAL (for1.188 dia crankshaft)

1

5

77-2916

COUPLING - compressor drive(SLX)

1



77-3067

COUPLING - compressor drive(SLXe)

1

6

55-9032

KEY (5/8 lg)

1

7

55-9300

SPACER - coupling

1

8

55-9092

SCREW - clutch/coupling

1

9

12-750

FLYWHEEL

1



11-8947

•  GEAR - ring (before11/08)

1



13-1138

•  GEAR - ring (11/08& after)

1

10

55-1123

PIN - dowel (30s)

8

11

77-2856

BUSHING (30s)

8



70-208

KIT - bushing (8 pin clutch,incl pins, bushings & adhesive)

1

12

77-2760

BUSHING - coupling (50s)

8



204-1114

ADHESIVE - bushing

A/R

13

51-814

PIN - dowel (50s)

8

14

107-364

CLUTCH

1



107-399

CLUTCH (SLXeonly)

1


NOTE:     NOTE: Enginesbefore serial number EA00749, use gear ring 11-8947. Engineswith serial number EA00749 and after, use gear ring 13-1138.

OIL SUMP GROUP (TK486V)

REF

PART#

DESCRIPTION

QTY

1

12-868

SUMP - oil (upper)

1

2

12-869

SUMP - oil (lower)

1

3

55-8437

•  PLUG - drain

2

4

203-348

GASKET - adhesive (RTVsilicone)

A/R

5

55-6246

SCREW - oil base(25 mm)

15

6

55-5809

SCREW - oil base(45 mm)

19

7

55-6237

SCREW - oil base(85 mm)

12

8

51-1150

SCREW - oil base(120 mm)

1

9

11-8667

DIPSTICK

1

10

33-4090

O-RING - dipstick

1

11

11-8923

CAP (units w/o oil level switch, push-in type)

1

12

55-9167

ELBOW - hose (90degree)

1

13

11-8984

HOSE - oil drain(10 in long)

1



11-5911

HOSE - oil drain(17 in long)

1

14

55-5081

CAP - hose

1

15

91-4823

CLIP - hose

1



55-1587

SCREW - clip

1



55-2086

FLATWASHER

1



55-4953

NUT

1

16

91-7191

BRACKET - clip

1

17

41-4470

SWITCH - oil level(threaded type)

1



33-4160

•  O-RING - switch

1

18

11-9338

VALVE - oil drain

1

19

11-9448

FITTING - oil drain(ESOC)

1

20

55-3744

ELBOW - hose (45degree)

1

21

13-1063

FITTING - oil drainw/cap

1


OIL FILTER & PUMP GROUP (TK486V)

REF

PART#

DESCRIPTION

QTY

1

13-357

PIPE - oil

1

2

55-4644

BOLT - eye

1

3

33-3833

SEAL - washer (10)

2

4

55-5792

NUT

1

5

51-1158

BOLT - eye

1

6

55-4622

WASHER - sealing (8)

2

7

101-362

PUMP - fuel injection (2200 rpm, see 204G1)

1

8

51-1159

PLUG

1

9

33-4089

O-RING - pipe

1

10

13-356

PIPE - oil pickup

1

11

55-8441

SCREW - pipe (16 mm)

2

12

13-323

COVER - oil pump

1

13

51-1147

•  PLUG

1

14

13-325

•  SPRING

1

15

13-324

•  VALVE - check

1

16

13-326

•  COVER - oil pump

1

17

13-328

ROTOR - outer

1

18

13-327

ROTOR - inner

1

19

51-592

SCREW - oil pump

7

20

33-2931

GASKET - oil filterbracket

1

21

11-9354

BRACKET - filter (incl22 - 30)

1

22

11-8964

•  ORIFICE

1

23

51-593

•  PLUG (3/8)

1

24

55-5763

•  PLUG (1/8)

2

25

11-8995

•  VALVE - check

1

26

51-1157

• WASHER - sealing (14)

1

27

11-8965

• SPRING

1

28

55-8868

•  BALL

1

29

51-1156

•  PLUG

1

30

51-1157

•  WASHER - sealing (14)

1

31

55-6188

SCREW - bracket (20 mm)

1

32

55-5809

SCREW - bracket (45 mm)

1

33

55-8869

SCREW - bracket (75 mm)

1

34

11-9182

FILTER - oil (EMI 3000)

1

35

11-9447

FITTING - oil inlet(ESOC)

1


CYLINDER HEAD & VALVE COVER (TK486V)

REF

PART#

DESCRIPTION

QTY

1

13-344

PIPE - breather

1

2

55-8442

•  CLAMP - hose (24)

2

3

91-3542

TUBE - sponge (insulation, cut to 11.0in lg)

1

4

13-337

COVER - valve

1

5

13-340

•  GASKET - valve cover

1

6

11-5103

•  KNOB - valve cover

3

7

33-3512

•  O-RING - cover

3

8

11-8671

•  BAFFLE - breather

1

9

13-338

•  PLATE - baffle

1

10

33-2762

•  O-RING

1

11

13-339

•  COVER - breather

1

12

51-598

•  SCREW - cover

8

13

13-332

SHAFT - rocker arm

1



13-335

•  SHAFT - rocker arm

1

14

13-333

•  SUPPORT - rocker arm

2

15

13-334

•  SUPPORT - rocker arm

3

16

55-6245

•  STUD - valve cover

3

17

11-6704

•  SPRING

4

18

13-336

•  ARM - rocker

8

19

55-8859

•• SCREW - valve adjust

8

20

55-8860

•• NUT

8

21

55-6193

SCREW - support (50 mm)

7

22

55-6246

SCREW - support (25 mm)

3

23

12-870

HEAD - cylinder

1

24

13-342

•  RETAINER - nozzle

4

25

13-341

•  PROTECTOR - nozzle

4

26

11-6707

•  GASKET - copper (nozzle seat)

4

27

55-6191

•  SCREW - nozzle retainer

4

28

51-1151

•  WASHER

4

29

11-6567

•  PLUG - frost (40 mm)

1

30

55-5803

•  PIN - spring

2

31

13-932

•  VALVE - intake

4

32

11-8928

•  GUIDE - valve (intake)

4

33

11-8935

•  SEAL - valve stem (intake)

4

34

13-659

•  VALVE - exhaust

4

35

11-8929

•  GUIDE - valve (exhaust)

4

36

11-8934

•  SEAL - valve stem(exhaust, marked w/ yellow stripe)

4

37

11-8932

•  SPRING - valve

8

38

11-8933

•  RETAINER - spring

8

39

55-8858

•  KEEPER - valve

8

40

11-8936

•  CAP - valve

8

41

55-8853

SCREW - cylinder head

18

42

33-4122

GASKET - cylinder head(SB-210/130/230)

1



33-4515

GASKET - cylinder head(SB-310/330)

1

43

13-126

LIFTER - engine

2

44

55-5801

SCREW - lifter

4

45

11-8942

FLANGE

1

46

55-5763

•  PLUG

1

47

33-2934

GASKET - flange

1

48

55-8441

SCREW - flange

4

49

203-348

GASKET - liquid

A/R

50

13-648

SEAT - valve (intake)

4

51

11-8927

SEAT - valve (exhaust)

4


INTAKE & EXHAUST MANIFOLD (TK486V)

REF

PART#

DESCRIPTION

QTY

1

33-2936

GASKET - intake manifold

1

2

13-343

MANIFOLD - intake

1

3

55-5763

•  PLUG

1

4

55-6188

SCREW - intake manifold (20 mm)

6

5

55-8717

SCREW - intake manifold (80 mm)

1

6

33-2765

GASKET - air heater

1

7

41-2147

HEATER - air

1

8

33-2764

GASKET - inlet

1

9

11-9266

INLET - intake manifold

1

10

55-6191

SCREW - inlet (35 mm)

4

11

33-2937

GASKET - exhaust manifold

1

12

11-8944

MANIFOLD - exhaust

1

13

51-1153

STUD - exhaust manifold

2

14

51-594

NUT

2

15

51-1152

SCREW - exhaust manifold (40 mm)

7


GASKET SET (TK486V)

REF

PART#

DESCRIPTION

QTY



30-291

KIT - gasket set

1

1

33-4122

•  GASKET - cylinder head (2200 rpm engine &2600 rpm engines bulit before 3/08)

1

2

33-3098

•  GASKET

1

3

33-1953

•  O-RING - fuel injection pump

1

4

11-8935

•  SEAL - valve stem(exhaust)

4



11-8934

•  SEAL - valve stem (intake)

4

5

13-341

•  PROTECTOR - nozzle

4

6

11-6707

•  GASKET - copper (nozzle seat)

4

7

13-340

•  GASKET - valve cover

1

8

33-2764

•  GASKET

1

9

33-2936

•  GASKET - intake manifold

1

10

33-2937

•  GASKET - exhaust manifold

1

11

33-2931

•  GASKET

1

12

33-3096

•  GASKET - water pump

1

13

33-1745

•  WASHER - sealing (16)

1



33-3833

•  WASHER - sealing (10)

2



55-4622

•  WASHER - sealing (8)

12

14

33-2767

•  GASKET

1

15

33-2768

•  GASKET

1

16

33-2765

•  GASKET - air heater

1

17

33-2934

•  GASKET - flange

1

18

33-2969

•  GASKET - oil sealcase

1

19

33-3097

•  GASKET - thermostat case

1

20

33-3512

•  O-RING (12.0)

3



33-3821

•  O-RING (16.0)

2



33-4089

•  O-RING (20.0)

1



33-4090

•  O-RING (31.5)

1



33-1954

•  O-RING (32.0)

3



33-2762

•  O-RING (50.0)

1

21

203-348

•  GASKET - adhesive (RTVsilicone)

A/R

22

33-4517

GASKET - cylinder head(2600 rpm enginesbuilt after 3/08)

1


FUEL INJECTION GROUP (TK486V)

REF

PART#

DESCRIPTION

QTY

1

101-362

PUMP - fuel injection (2200 rpm, see 204G2)

1



101-354

PUMP - fuel injection (2600 rpm, see 205C5)

1

2

13-356

SUPPORT - pump

1

3

55-6188

SCREW - support

2

4

13-371

PIPE - fuel injection

1

5

13-391

PIPE - fuel injection

1

6

13-392

PIPE - fuel injection

1

7

13-393

PIPE - fuel injection

1

8

13-368

RETAINER - tube (4 tubes)

1

9

55-8626

SCREW - retainer

1

10

11-6109

RETAINER - tube (3 tubes)

1

11

55-8626

SCREW - retainer

1

12

13-388

NOZZLE - injection (2200rpm engine, see 204G5)

4



13-389

NOZZLE - injection (2600rpm engine, see 205C10)

4

13

10-373

KIT - fuel return

1

14

13-310

•  HOSE &CLAMPS (nozzle to nozzle)

3

15

13-451

•  HOSE &CLAMPS (nozzle to pump)

1

16

13-342

RETAINER - nozzle (partof cylinder head,see 204F5)

4

17

55-6191

SCREW - retainer

4

18

51-1151

WASHER

4

19

204-1848

ADAPTER - compression tester

1



11-9446

•  VALVE (Schrader)

1



55-1819

•  SEAL - copper

1



55-4607

•  FLATWASHER

2



204-542

TESTER - compression

1




FUEL INJECTION PUMP GROUP (TK486V, 2200 RPM)

REF

PART#

DESCRIPTION

QTY

1

101-362

PUMP - fuel injection (2200 rpm)

1

2

42-100

•  SOLENOID - stop

1

3

33-2230

•  O-RING - solenoid

1

4

55-8448

•  SCREW - solenoid

2

5

13-440

•  COVER - governor

1

6

33-4168

•  GASKET - cover

1

7

55-6230

•  PLUG (12 mm)

1

8

33-4169

•  WASHER - sealing (12 mm)

1

9

12-925

•  LEVER - control

1

10

13-442

•  SPRING - lever

1

11

51-1205

•  NUT - lever

1

12

51-1206

•  NUT - ball joint

1

13

11-6125

•  RETAINER - shaft

1

14

55-5822

•  SCREW - retainer

1

15

51-1207

•  PLUG

1

16

33-4170

•  WASHER - sealing (18 mm)

1

17

13-444

•  LIFTER

1

18

55-4676

•  O-RING - lifter

1

19

55-5822

•  SCREW - lifter

1

20

13-445

•  STOPPER

1

21

33-4171

•  O-RING - stopper &eye bolt

2

22

13-450

•  JOINT - banjo (water)

1

23

55-5846

•  NUT

1

24

51-1155

•  NUT

1

25

51-1154

•  LOCKWASHER

1

26

13-446

•  JOINT - banjo (fuelin)

1

27

13-447

•  BOLT - eye

1

28

55-8620

•  WASHER - sealing (12 mm)

4

29

33-4172

•  O-RING - plug

1

30

33-4173

•  O-RING - plug

1

31

13-448

•  JOINT - banjo (fuel out)

1

32

13-449

•  BOLT - eye

1

33

13-511

•  PUMP - feed

1

34

33-4190

• O-RING - pump

1

35

33-4192

• O-RING - pump

1

36

33-4193

• O-RING - inner

1

37

55-6187

• SCREW - pump (socket head)

2

38

51-1269

• SCREW - pump (hex head)

4

39

51-612

•SCREW - idler limit

1


55-7802

SCREW - idler limit (Gensetunits)

1


FUEL INJECTION NOZZLE (TK486V)

REF

PART#

DESCRIPTION

QTY



13-388

VALVE - fuel injection

4

1

11-6787

•  HOLDER - nozzle

1

2

11-6108

•  SHIM SET

1

3

11-6788

•  SPRING - nozzle

1

4

11-6106

•  RETAINER - nozzle spring

1

5

11-6790

•  PIN

1

6

11-6789

•  PLATE - stop

1

7

13-370

•  NOZZLE

1

8

11-6786

•  NUT - nozzle case

1

9

33-4174

•  GASKET - nozzle

1

10

13-341

PROTECTOR - nozzle

4

11

11-6707

GASKET - copper (nozzle seat)

4




FUEL FILTER & HOSES

REF

PART#

DESCRIPTION

QTY



10-325

KIT - fuel filter

1

1

11-9015

•  HEAD - fuel filter

1



55-5579

•  SCREW - head

2



55-1173

•  LOCKWASHER

2



55-7072

•  FLATWASHER

2

2

11-9017

•  SPUD - fuel filter

1

3

11-9016

•  SHAFT - water bleed

1

4

11-9342

•  FILTER - fuel (EMI3000)

1

5

11-5320

•  ELBOW - hose (1/4)

3

6

10-243

•  KIT - sleeve &eyelet (1/4)

5

7

11-4841

•  NUT - hose (1/4)

5

8

11-4367

•  HOSE (1/4od x 35 ft lg)

A/R

9

11-4380

•  ELBOW - hose fitting(3/8)

1

10

10-242

•  KIT - sleeve &eyelet (3/8)

3

11

11-4941

•  NUT - hose (3/8)

3

12

11-4372

•  HOSE (3/8od x 35 ft lg)

A/R

13

101-362

PUMP - fuel injection (see 204G2)

1

14

11-7433

PUMP - fuel (see142F8)

1

15

10-342

KIT - check valve(fuel line)

1



11-9245

•  VALVE - check

1

16

13-963

ELBOW - hose fitting (3/8, before 9/09)

1

17

13-964

ELBOW - hose fitting (1/4, before 9/09)

1

18

92-6830

BRACKET - fuel fittings (before 9/09)

1



55-5022

SCREW - bracket

2



55-7727

LOCKWASHER

2



55-7069

FLATWASHER

2

19

13-1078

HOSE - fuel linerouting (9/09 &after)

1

20

13-1232

SLEEVE - fuel hoseprotector (152m)

A/R


FUEL PUMP ASSEMBLY (TK486/486E, TK482/482E &
TK486V)

REF

PART#

DESCRIPTION

QTY

1

11-7433

PUMP - fuel

1

2

11-8970

•  PISTON

1

3

11-8971

•  SPRING - piston

1

4

55-8871

•  RETAINER

1

5

33-2940

•  GASKET

1

6

11-8998

•  TAPPET

1

7

55-8872

•  PIN - snap

1

8

11-8972

•  VALVE

2

9

11-8973

•  SPRING

2

10

11-8974

•  RETAINER - valve

1

11

33-2941

•  O-RING

1

12

11-8680

•  PUMP

1

13

11-8975

•  JOINT - banjo

1

14

33-2771

•  O-RING

1

15

11-8976

•  BOLT - eye

1

16

11-8977

•  GASKET

2

17

11-7499

•  JOINT - banjo (elbow, before engine S/N L68462)

1



13-128

•  JOINT - banjo (elbow, engine S/N L68462& after)

1

18

11-8681

•  BOLT - eye (withfilter)

1



11-2854

•• SCREEN (brass,#30)

1

19

33-1749

•  GASKET

4

20

13-127

•  JOINT - banjo (straight, engine S/N L68462& after)

1



11-7707

•  JOINT - banjo (straight, before engine S/NL68462)

1

21

11-8682

•  BOLT - eye

1

22

33-2942

O-RING

1

23

55-4750

NUT

3

24

55-6367

STUD - fuel pump

3




ENGINE MOUNT

REF

PART#

DESCRIPTION

QTY

1

92-6484

MOUNT - snubber

1

2

92-6483

SUPPORT - snubber mount

1



55-4723

SCREW - mount &support

5



55-365

LOCKWASHER

5



55-2038

FLATWASHER

5

3

91-8972

ISOLATOR - snubber (rear)

1

4

92-6771

RETAINER - isolator

1



55-4723

SCREW - retainer

2



55-2038

FLATWASHER

2



55-365

LOCKWASHER

2

5

92-7063

BRACKET - engine (compressor end, rear)

1

6

92-6946

BRACKET - engine (compressor end, front)

1



55-4723

SCREW - bracket

10



55-365

LOCKWASHER

10



55-2038

FLATWASHER

10

7

55-4963

NUT (5/8-18)

3

8

92-9484

BRACKET - engine (waterpump end, rear)

1

9

92-9485

BRACKET - engine (waterpump end, front)

1



55-4723

SCREW - bracket

6



55-365

LOCKWASHER

6



55-2038

FLATWASHER

6

10

91-4159

MOUNT - vibration

6

11

92-7797

MOUNT - vibration (setof 2, front, water pumpend)

2

12

55-2482

SCREW - engine (compressor end)

2

13

91-4675

SCREW - engine (center, water pump end)

1

14

92-9482

SCREW - engine (front,water pump end)

1

15

55-5749

WASHER - special

3

16

55-7364

WASHER - special

2

17

51-2328

NUT ASSEMBLY

1

18

55-7003

NUT (M12)

1

19

51-2319

PLATE - engine (front)

1



55-7023

SCREW-HH M12 X 80

1

20

92-6487

SHIELD - heat

1



51-2003

SCREW - shield

3


INTAKE & EXHAUST GROUP

REF

PART#

DESCRIPTION

QTY

1

11-9299

AIR CLEANER

1

2

11-9300

•  FILTER - air cleaner

1

3

92-9836

BRACKET - air cleaner

1



55-5022

SCREW - bracket

2



55-7069

FLATWASHER

2



55-7727

LOCKWASHER

2

4

92-6489

BRACKET - air cleaner

1



92-9837

BRACKET - air cleaner (units w/ ETV)

1



51-718

SCREW - bracket

2

5

55-4979

CLAMP - hose

2

6

13-1284

HOSE - air cleaner

1

7

41-2147

HEATER - air intake

1

8

33-2314

GASKET - exhaust

1

9

13-939

TUBE - exhaust (flexible)

1



55-4612

SCREW - tube

2



55-4621

NUT

2

10

99-496

CLAMP - exhaust tube

2

11

13-938

TUBE - muffler

1



55-5022

SCREW - tube

2



55-7069

FLATWASHER

2



55-7727

LOCKWASHER

2

12

12-919

MUFFLER

1



55-5022

SCREW - muffler

4



55-7727

LOCKWASHER

4



55-7069

FLATWASHER

4

13

90-430

KIT - muffler extension (optional)

1


COOLANT GROUP (5/10 & after, micro channel cond
coil)

REF

PART#

DESCRIPTION

QTY

1

78-1340

BELT - water pump

1

2

13-509

PUMP - water (see204D2)

1



813-509

PUMP - water reman(see 204D2)

1

3

41-6538

SENSOR - water temperature

1

4

13-1076

HOSE - outlet (thermostat to radiator)

1

5

13-1077

HOSE - inlet (radiator to engine)

1

6

55-4979

CLAMP - hose

2

7

55-3401

CLAMP - hose

2

8

67-2475

COIL - radiator (see242C9)

1

9

13-1075

HOSE - radiator to expansion tank

1

10

13-1074

HOSE - over flow

1

11

12-920

TANK - expansion

1

12

41-9489

•  SENSOR - coolant

1

13

11-9632

•  CAP - tank

1



55-5022

SCREW - tank

5

14

13-1123

SHROUD - expansion tank

1


WATER PUMP ASSEMBLY (TK486V)

REF

PART#

DESCRIPTION

QTY

1

13-509

PUMP - water (ELC compatible)

1



813-509

PUMP - water (ELCcompatible, remanufactured)

1

2

51-607

•  PLUG

2

3

33-3096

• GASKET - water pump

1



30-295

GASKET SET (inc items3, 4, 6, 16)

1

4

33-2768

GASKET

1

5

13-385

THERMOSTAT (160 F, 71 C)

1

6

33-2767

GASKET

1

7

11-8675

COVER - thermostat

1

8

55-6188

SCREW - thermostat

2

9

55-6248

SCREW - pump

3

10

13-358

PULLEY - water pump

1

11

77-1427

•  SHIM (1 mm)

A/R



77-2752

•  SHIM (0.5mm)

A/R

12

77-1428

•  SPACER

1

13

55-5792

NUT

4

14

13-815

JOINT - pump

1

15

33-3097

GASKET - joint

1

16

33-3098

O-RING - joint

1

17

55-8441

SCREW - joint

3

18

33-1745

WASHER - sealing

1

19

11-9256

PLUG

1

20

55-5780

COCK - drain

1

21

13-360

HOSE - drain

1

22

13-363

HOSE - inj pumpto water pump

1

23

13-514

HOSE - inj pumpto water pump

1



51-588

CLAMP - hose

4


BELTS & BLOWERS (SLXe)

REF

PART#

DESCRIPTION

QTY

1

78-1744

BELT - blowers

1

2

77-2902

PULLEY - alternator

1

3

45-2254

ALTERNATOR (37 amp, see 208F4)

1



41-8461

ALTERNATOR (37 amp, new exchange)

1



845-2254

ALTERNATOR (37 amp, remanufactured)

1



45-2258

ALTERNATOR (120 amp, see 241C1)

1

4

78-1620

TENSIONER - belt

1



55-4680

SCREW - tensioner

4



55-7005

NUT

3

5

77-2901

IDLER - grooved

1



55-1173

LOCKWASHER

1



55-7072

FLATWASHER

1



55-8472

SCREW - idler

3

6

77-2900

IDLER - smooth

1

7

92-6505

BLOCK - slider

1



55-5419

SCREW - idler

3

8

77-3069

PULLEY - motor (SLXe100/400/SPECTRUM)

1



77-3070

PULLEY - motor (SLXe200/300)

1

9

78-1615

FANSHAFT (see 225D13)

1

10

78-1618

BLOWER - upper

1

11

78-1619

BLOWER - lower

1

12

77-2903

SPINNING - condenser

2



55-9761

SCREW - spinning (M6 X 25)

2



51-1741

SCREW - spinning (M6 X 60, brass)

4



55-405

LOCKWASHER - dome

6



55-4607

FLATWASHER

4



55-7007

NUT

4

13

77-2908

PULLEY - motor (175 mm)

1



77-2945

PULLEY - motor (SLXSPECTRUM only, 161 mm)

1



55-7167

SCREW - pulley

2



55-7727

LOCKWASHER

2



55-4607

FLATWASHER

2

14

104-756

MOTOR (15 hp, 230-460/3/60, 12.5 hp, 190-380/3/50)

1



104-770

MOTOR (14 hp, 200/3/50-60, Japan)

1



104-793

MOTOR (SPECTRUM units, 12.5 hp, see 225E9)

1

15

78-1620

TENSIONER - clutch (see261F2)

1



51-1244

SCREW - tensioner

3



55-365

LOCKWASHER

3



55-2038

FLATWASHER

3

16

78-1696

CROSS DRIVE(see 226C2)

1

16

77-3068

PULLEY - idler (see261E7)

1

17

78-1830

BELT - engine to motor (SLXe200/300)

1



78-1831

BELT - engine to motor (SLXe100/400/SPECTRUM)

1

18

92-6509

GUARD - belt

1



51-718

SCREW - guard

4

19

107-399

CLUTCH

1

20

55-457

KEY - fan

2


TENSIONER CLUTCH

REF

PART#

DESCRIPTION

QTY

1

77-3065

BRACKET - tensioner

1

2

92-9487

BASE - tensioner

1

3

77-3072

•  PULLEY - idler (smooth)

1

4

55-8648

•  SCREW - pulley

1

5

77-3068

PULLEY - idler (grooved)

1

6

55-8648

SCREW - pulley

1



55-5354

SCREW - base

2



55-365

LOCKWASHER

2



55-2038

LOCKWASHER

2


CONDENSER BLOWERS

REF

PART#

DESCRIPTION

QTY

1

78-1618

BLOWER - upper

1

2

77-2928

•  PULLEY - blower

1



55-6215

•  SCREW - pulley

4



55-7727

•  LOCKWASHER

4



55-4613

•  FLATWASHER

4

3

77-2911

•  HUB - blower

1



55-7080

•  SCREW - hub to shaft

2



55-7727

•  LOCKWASHER

2



55-4613

•  FLATWASHER

2

4

78-1619

BLOWER - lower

1

5

77-2899

•  SPINDLE - blower

1



51-1438

•  SCREW - spindle (30mm)

4

6

51-1687

•  WASHER - wave

2

7

77-2929

•  PULLEY - blower

1

8

77-2779

•  BEARING - blower

2

9

77-2930

•  HUB - blower

1

10

55-9957

•  RING - snap

1



203-527

•  GREASE

A/R



51-898

SCREW - spindle to bracket

4



55-7727

LOCKWASHER

4



55-7069

FLATWASHER

4

11

92-6504

BRACKET - spindle support (upper)

1

12

92-6770

BRACKET - spindle support (lower, before 7/10)

1



55-5424

SCREW - bracket

7



55-7727

LOCKWASHER

7



55-7069

FLATWASHER

7


EVAPORATOR BLOWER

REF

PART#

DESCRIPTION

QTY

1

78-1615

FANSHAFT ASSEMBLY (see 225D13)

1



55-7004

SCREW - fanshaft

6



55-1173

LOCKWASHER

6



55-7072

FLATWASHER

6

2

92-6499

SHIELD - insulation

1



51-718

SCREW - shield

6



55-3045

WASHER - dome

6

3

77-2910

INLET - evaporator blower

2



55-9761

SCREW - inlet

6



55-3045

WASHER - dome

6

4

78-1616

BLOWER - evaporator

1



55-457

•  KEY - hub

1



55-7080

•  SCREW - blower to shaft

2



55-7342

•  LOCKWASHER

2



55-7085

•  FLATWASHER

2

5

98-8184

HOUSING - blower

1



55-7828

SCREW - housing (35mm)

4



55-6993

SCREW - housing (25mm)

5



55-7342

LOCKWASHER

9



55-7085

FLATWASHER

9

6

55-5111

CONNECTOR - sensor

2

7

40-974

KIT - sensor (partof main harness)

2

8

92-6502

PANEL - scroll

1



55-9761

SCREW - panel

4

9

91-3599

STOP - damper

2



55-9002

SCREW - damper stop

2



51-717

NUT

2

10

92-6501

SHAFT - damper blade

1



55-8559

SCREW - shaft

4



55-7342

LOCKWASHER

4

11

92-6500

BUSHING - damper pivot

1



55-9761

SCREW - bushing

2



55-6995

FLATWASHER

2



55-7042

NUT

2

12

92-6544

BLADE - damper

1

13

41-7852

MOTOR - damper

1



51-718

SCREW - motor

3

14

33-4514

SEAL - fanshaft

1


FANSHAFT

REF

PART#

DESCRIPTION

QTY



78-1615

FANSHAFT ASSEMBLY

1

1

NSS

HOUSING - fanshaft

1

2

51-1685

RING - snap

2

3

77-2898

BEARING

1

4

51-1684

WASHER - wave

1

5

77-2896

SHAFT - fan

1

6

77-2897

BEARING

2

7

51-1682

WASHER

2

8

51-1683

WASHER - wave

1

9

55-457

KEY

1



203-527

GREASE

A/R


CROSS SHAFT (30 units)

REF

PART#

DESCRIPTION

QTY



78-1696

CROSS DRIVEASSEMBLY

1

1

NSS

HOUSING

1

2

55-9958

WASHER - wave

1

3

77-3033

BEARING

2

4

77-2918

SHAFT

1

5

55-9957

RING - snap

2

6

51-1748

KEY

2


REFRIGERATION COMPONENTS w/ ETV (1/10 & after
micro channel cond coil)

REF

PART#

DESCRIPTION

QTY

1

102-900

COMPRESSOR - X430 LS C5 (dry,see 256D7)

1



8102-972

COMPRESSOR - X430 LS C5 (dryreman, see 256D7)

1

2

61-4127

VIBRASORBER - discharge

1

3

61-4133

TUBE - vibrasorber to 3-way valve

1

4

61-4138

TUBE - transducer

1

5

66-9246

FITTING - transducer

1

6

41-7962

TRANSDUCER - discharge

1

7

61-4137

TUBE - inlet (hotgas valve)

1

8

61-4132

SOLENOID - hot gas

1

9

66-8560

SOLENOID - pilot

1



41-1521

•  COIL

1

10

61-5265

TUBE - 3 way to solenoid

1

11

61-4136

TUBE - solenoid to compressor

1

12

61-1829

HOSE

1

13

61-4134

TUBE - defrost

1

14

61-6281

TUBE - defrost to receiver tank

1

15

61-5771

VALVE - 3-way (see256D1)

1

16

61-5104

TUBE - 3-way to condenser coil

1

17

67-2481

COIL - condenser/radiator (microchannel coil)

1



67-2474

•  COIL - condenser (microchannel coil)

1

18

61-5103

TUBE - condenser to joint

1

19

61-4232

TUBE - joint to check valve

1

20

61-4268

VALVE - check

1

21

61-4269

VALVE - check

1

22

61-4253

VALVE - throttling (electronic)

1



40-997

•  KIT - valve repair

1

23

67-2336

TANK - receiver

1



33-2419

•  O-RING

1



66-9918

•  INDICATOR - liquid

1

24

61-6280

TUBE - receiver to dehydrator

1

25

61-600

DEHYDRATOR

1

26

61-4142

TUBE - dehydrator to joint

1

27

67-2698

HEAT EXCHANGER

1

28

61-3679

VALVE - expansion

1



61-3677

VALVE - expansion (SLXe 400)

1



66-6380

FILTER - inlet

1



66-4441

FILTER - outlet

1

29

67-2786

COIL - evaporator

1

30

66-602

ELBOW

1

31

41-7960

TRANSDUCER - suction

1

32

61-4126

VIBRASORBER - suction

1

33

67-2335

TANK - accumulator

1

34

67-2337

TUBE - serpentine

1


REFRIGERATION COMPONENT MOUNTING

REF

PART#

DESCRIPTION

QTY

1

67-2336

TANK - receiver

1

2

66-9918

•  INDICATOR - liquid

1



33-2419

•  O-RING - liquid indicator

1



55-7005

NUT - tank

1



55-4931

WASHER - special

1

3

66-7392

VALVE - relief

1



33-1015

O-RING - relief valve

1

4

92-6493

BRACKET - receiver tank

1

5

92-6639

CLAMP - dehydrator

1



55-7022

SCREW - clamp

1

6

61-600

DEHYDRATOR

1

7

92-6495

TRAY - drip

1

8

67-2335

TANK - accumulator

1



55-5424

SCREW - tray &accumulator tank

4



55-7069

FLATWASHER

4



55-790

LOCKWASHER

4

9

92-6496

BRACKET - accumulator tank

1



51-718

SCREW - valve

2

10

61-4253

VALVE - throttling (electronic)

1



40-997

•  KIT - valve repair

1

11

55-6544

CLAMP - tube (1/4inch tube)

A/R

12

55-6389

CLAMP - tube (1/2inch tube)

A/R

13

91-372

CLAMP - tube (3/4inch tube)

A/R



55-7074

SCREW - clamp

A/R



55-4607

FLATWASHER

A/R



55-4608

LOCKWASHER

A/R

14

92-6494

BRACKET - 3-way valve

1



55-9761

SCREW - bracket

4

15

55-9246

CLAMP - discharge tube

2



55-7027

SCREW - clamp

2

16

66-9246

FITTING - transducer (SLXe300/400)

1



55-9761

SCREW - fitting

2

17

92-6498

CLAMP - serpentine tube

3



51-718

SCREW - clamp

3


COMPRESSOR GROUP

REF

PART#

DESCRIPTION

QTY



102-900

COMPRESSOR - X430 LS C5 (dry,see 223C5)

1

1

8102-972

COMPRESSOR - X430LS C5 (EMEIA, dry reman, see 223C5)

1



102-911

COMPRESSOR - X426 LS C5 (Sterling units, dry, see 226C5)

1



8102-911

COMPRESSOR - X426 LS C5 (Sterling units,dry reman, see 226C5)

1

2

12-918

FLANGE - compressor (SLX)

1



77-3066

FLANGE - compressor (SLXe)

1

3

55-1525

STUD - compressor (1.75in long)

4



55-1487

STUD - compressor (2.25in long)

2



55-402

FLATWASHER

6



55-375

LOCKWASHER

6



55-8318

NUT

6

4

55-308

ELBOW - test port

1

5

55-1983

CAP - flare

2



33-768

GASKET - flare

2

6

55-9106

SCREW - valve &cover

5

7

55-896

FLATWASHER

2

8

66-5318

VALVE - suction

1

9

66-2296

•  CAP - valve (plastic)

1



66-3015

•  CAP - valve (brass)

1

10

33-3007

•• GASKET - plastic cap

1



33-350

•• GASKET - brass cap

1

11

55-6804

WASHER - sealing

6

12

33-230

O-RING - valve

1

13

41-7960

TRANSDUCER - suction (ETV units)

1

14

66-9523

ADAPTER - suction valve(ETV units)

1

15

33-1221

O-RING - adapter

1

16

55-6776

SCREW - discharge valve

2

17

66-129

VALVE - discharge (incl9 & 10)

1

18

33-2805

GASKET - valve

3

19

55-9032

KEY - compressor

1

20

33-3004

SEAL - oil (largeshaft, 1-3/16 dia)

1

21

204-972

TOOL - keyway alignment

1

22

61-4256

VALVE - throttling (MTVunits, see 226D8)

1

23

22-759

MANIFOLD - discharge

1

24

55-3641

SCREW - manifold

4

25

55-3364

PLUG - pipe

2

26

91-4134

PLATE - cover

1

27

33-3101

GASKET - cover

1

28

11-2886

VALVE (Schrader, before 11/02)

1

29

66-8928

ADAPTER - o-ring seal

1

30

33-1461

O-RING - cap

1

31

66-9387

CAP - adapter

1

32

13-949

FITTING - restriction

1

33

61-1404

TUBE - outlet

1

34

66-8043

ADAPTER - oil tube

1

35

33-1223

O-RING - oil tube

2

36

66-7800

FILTER - oil

1

37

92-1893

BRACKET - filter

1

38

55-8848

SCREW - bracket

2



55-790

LOCKWASHER

2



55-371

FLATWASHER

2

39

33-1461

O-RING (5/16)

2

40

33-1015

O-RING (3/8id)

1

41

55-7119

CLAMP - tube

2



55-544

SCREW - clamp

1



55-411

FLATWASHER

2



55-4118

NUT

1

42

91-8080

CLAMP - filter

1

43

66-8928

ADAPTER - pump to tube

1

44

61-1403

TUBE - inlet

1

45

41-3669

SWITCH - hpco

1


COMPRESSOR - X430 LS C5

REF

PART#

DESCRIPTION

QTY



102-900

COMPRESSOR - X430 LS C5 (dry)

1



8102-900

COMPRESSOR - X430 LS C5 (TSA,dry, reman)

1



8102-927

COMPRESSOR - X430 LS C5 (EMEIA, dry, reman)

1

1

NSS

•  BODY - compressor

1

2

22-1027

•  CRANKSHAFT

1



55-1409

•• RIVET - counterweight

A/R

3

22-123

•  PLUG - oil metering

1

4

55-4720

•  PLUG

3

5

55-4213

•  PIN - dowel

1

6

77-169

•  BEARING - ball

1

7

77-2872

•  BEARING - ball (C5)

1

8

22-639

•  ROD - connecting

4

9

55-5062

•• BOLT - connecting rod

2

10

51-666

•• NUT (12 point)

2

11

11-475

•• BUSHING - piston pin

1

12

22-1246

•  BEARING SET - connecting rod (standard)

4



22-1264

•  BEARING SET (0.005 us)

4



22-1265

•  BEARING SET (0.010 us)

4



22-1266

•  BEARING SET (0.020 us)

4



22-1267

•  BEARING SET (0.030 us)

4

13

22-850

•  PISTON

4

14

NSS

•• PIN - piston

4

15

55-2122

•• RING - retaining

8

16

51-115

•• NUT

1

17

NSS

•• REED - piston

1

18

NSS

•• HEAD - piston

1

19

33-1549

•  GASKET - pump end

1

20

22-1277

•  HOUSING - oil pump

1



55-4210

•  PIN - dowel

1

21

33-1223

•• O-RING

2

22

22-1149

•  SHAFT - oil pump

1

23

55-9760

•  KEY - shaft

1

24

22-1160

•  PUMP - oil (inclitems 21-23)

1

25

33-239

•  O-RING

2

26

33-1175

•  O-RING

1

27

55-6752

•  PLUG - oil pumpcover

1



33-2095

•• O-RING

4

28

22-1278

•  COVER - pump

1

29

55-4211

•  PIN - dowel

1

30

22-784

•  REGULATOR

1

31

33-672

•• O-RING

1

32

55-681

•  SCREW - cover to housing

2



51-149

•  FLATWASHER

2

33

55-183

•  SCREW - pump

8

34

11-9001

•  VALVE - tee

1



203-393

•  SEALER - thread

A/R



55-1983

•  CAP - valve

1

35

22-611

•  SCREEN - oil pickup

1

36

33-2205

•  O-RING

1

37

99-4848

•  CLAMP - screen

1

38

55-291

•  NUT

1

39

55-366

•  LOCKWASHER

2

40

99-4849

•  BRACKET - screen

1

41

55-165

•  SCREW - bracket

2



55-366

•  LOCKWASHER

2

42

55-6751

•  PLUG - magnetic

2



33-2095

•  O-RING

2

43

33-2515

•  GASKET - oil sump

16

44

22-747

•  SUMP - oil (twodrain holes)

1

45

55-1417

•  SCREW - oil sump

16



55-896

•  FLATWASHER

16

46

22-350

•  SIGHT GLASS

3



33-822

•  O-RING

3

47

33-2552

•  GASKET - cylinder head

2

48

22-789

•  HEAD - cylinder

2

49

55-6805

•  SCREW (2 in lg)

12

50

55-6806

•  SCREW (2-5/8in lg)

8

51

55-6804

•  WASHER - sealing

20

52

33-2019

•  O-RING

20

53

22-656

•  SLEEVE - cylinder

4

54

33-408

•  O-RING

4

55

22-990

•  PLATE - valve

4

56

55-6750

•  PLUG - oil fill

1



66-8043

•  PLUG - oil fill (use with compr oil filter tube)

1

57

22-306

•  SCREEN - suction

1

58

33-1221

•  O-RING

1

59

22-653

•  VALVE - check

2

60

22-787

•  VALVE - check (oil return)

1

61

22-568

•  VALVE - check

2

62

22-1101

•  SEAL - crankshaft (for 1-3/16 diacrankshaft)

1

63

33-2513

•  GASKET - drive end

1

64

22-671

•  PLATE - crankshaft cover

1

65

55-9106

•  SCREW - housing

9



55-896

•  FLATWASHER

9

66

99-6545

•  PLATE - suction inlet

1

67

55-329

•  SCREW - plate

4

68

11-2886

•  VALVE (Schrader)

1



11-7777

•  CORE - valve

1



55-5672

•  CAP - valve

1

69

91-5630

•  PLATE - cover

1

70

91-9858

•  PLATE - cover (w/ lifting hole)

1

71

33-2805

•  GASKET - manifold

1

72

55-329

•  SCREW - plate

4

73

33-3103

•  GASKET - manifold

1



203-513

•  OIL - compressor (usew/ R134a, R404A)

A/R



67-404

OIL - compressor (R12,R22, R502, R403B,R402A & R401B)

A/R



30-243

KIT - gasket

1


NOTE:     NOTE: This compressor does not containcompressor oil. Add one gallon of oil before runningcom- pressor. For R404A, R134a & R407C, use 203-513 oil. For R12, R22, R502, R403B, R402A &
R401B, use 67-404 oil.

COMPRESSOR GASKET SET (30-243)

REF

PART#

DESCRIPTION

QTY



30-243

KIT - gasket

1

1

33-110

•  GASKET - pump housing(X426)

1

2

33-235

•  O-RING - dust seal

1

3

33-239

•  O-RING - oil galley

2

4

33-408

•  O-RING - cylinder sleeve

4

5

33-2205

•  O-RING - oil pickuptube

1

6

33-672

•  O-RING - regulator

1

7

33-822

•  O-RING - sight glass

1

8

33-1175

•  O-RING - oil pumpcover

1

9

33-1221

•  O-RING - throttling valve

1

10

33-1223

•  O-RING - oil pump

1

11

33-1549

•  GASKET - pump housing(X430)

1

12

33-2019

•  O-RING - cylinder headscrew

24

13

33-2095

•  O-RING - oil pumpplug

2

14

33-2513

•  GASKET - drive plate

1

15

33-2515

•  GASKET - oil sump

1

16

33-2805

•  GASKET - manifold

3

17

33-2552

•  GASKET - cylinder head

2

18

55-381

•  WASHER - oil fill

1

19

55-895

•  WASHER - oil pump

2

20

55-896

•  WASHER - compressor seal (3/8)

57


3-WAY VALVE ASSEMBLY (4/10 & after)

REF

PART#

DESCRIPTION

QTY

1

61-5771

VALVE - 3-way

1

2

60-300

•  KIT - valve repair

1

3

60-147

• FILTER

1

4

33-3538

•  GASKET

1

5

55-5415

• RING - retaining

1

6

61-5777

• VALVE - check (reverse flow)

1

7

33-1124

• O-RING

1

8

61-5778

• STEM

1

9

55-621

•  CAP

1


MICRO-CHANNEL CONDENSER COIL

REF

PART#

DESCRIPTION

QTY



60-331

KIT - micro-channel condenser coil (retro-fit kit, order con- denser/radiator coil separately)

1

1

13-1074

•  HOSE - over flow

1

2

92-8923

•  BRACKET - top

1

3

92-8922

•  BRACKET - bottom

1

4

33-4625

•  BLOCK - foam

2

5

33-314

•  GROMMET

1

6

61-5104

•  TUBE - inlet

1

7

61-5103

•  TUBE - outlet

1

8

13-1077

•  HOSE - coolant (inlet, see 242C0)

1

9

13-1076

•  HOSE - coolant (outlet, see 242C0)

1

10

51-2195

•  CLAMP - hose

2



51-124

•  SCREW - clamp

1



55-4742

•  WASHER - special

1

11

92-8287

•  BRACKET - clamp

1



55-2260

RIVET - bracket

2

12

13-1075

•  HOSE - radiator to expansion tank(see 242C0)

1

13

67-2481

COIL - condenser/radiator (not supplied withKit)

1



67-2474

•  COIL - condenser (microchannel coil)

1



67-2475

•  COIL - radiator (see242C0)

1



51-718

SCREW - coil

6



55-7075

FLATWASHER

4



55-7008

NUT

4


CONDENSER FRAME, EVAPORATOR PANELS &
GRILLES SLX 100

REF

PART#

DESCRIPTION

QTY

1

33-4404

GASKET - sill

1

2

92-6475

SCREEN - evaporator (inlet)

1

3

55-546

CLAMP - screen

13

4

92-6503

GRILLE - evaporator (outlet)

1

5

92-6492

CLAMP - distributor

1

6

92-6491

CLAMP - heat exchanger

2



55-9761

SCREW - clamp

5

7

99-2230

TUBE - drain

1

8

66-1273

VALVE - drain

1

9

67-2349

HEAT EXCHANGER (see 226A8)

1

10

67-2348

COIL - evaporator (SLX100, see 226A8)

1



67-2783

COIL - evaporator (SLXe100, see 242G0)

1



67-2786

COIL - evaporator (SLXe 200/400, see 242C9 300see 244C8)

1

11

91-5971

SHEET - insulation (trailer wall, 40 in x 16 in)

1

12

91-5972

SHEET - insulation (trailer wall, 20 in x 21 in)

1

13

98-7906

FRAME - unit (SLX)

1



98-9145

FRAME - unit (SLXe)

1


ELECTRIC COMPONENTS (50 units)

REF

PART#

DESCRIPTION

QTY

1

NSS

CONTROL BOX(see 242G7)

1

2

41-7965

HARNESS - main (50 units)

1

3

203-777

BATTERY - EON (880CCA, see 261E4)

1

4

42-250

CABLE - battery (positive)

1

5

41-7976

CABLE - battery (negative)

1

6

41-8105

SENSOR - RPM

1

7

41-4470

SWITCH - oil level

1



33-4160

•  O-RING - switch

1

8

41-6865

SWITCH - oil pressure

1

9

45-2177

STARTER (see 204G3)

1

10

44-9181

SOLENOID - throttle (see 225E5)

1

11

42-100

SOLENOID - stop (see 204G2)

1

12

41-2147

HEATER - intake (see204F7)

1

13

41-7960

TRANSDUCER - suction (unitsw/ ETV)

1

14

61-4253

VALVE - throttling (electric, units w/ ETV)

1



40-997

•  KIT - valve repair

1

15

40-974

KIT - sensor (graded)

2

16

66-8560

SOLENOID - pilot (seerefrigeration grid)

1

17

61-4132

SOLENOID - hot gas(units w/ ETV,see refrigeration grid)

1

18

45-2254

ALTERNATOR (37 amp, see 208F4)

1



41-8461

ALTERNATOR (37 amp, new exchange)

1



845-2254

ALTERNATOR (37 amp, remanufactured)

1

19

41-6538

SENSOR - water temperature

1

20

40-975

SENSOR - ungraded

3

21

41-3669

SWITCH - hpco

1

22

45-2242

HEATER - evaporator (optional)

3

23

41-7852

MOTOR - damper door(see 225D11)

1

24

104-756

MOTOR (400V)

1



104-770

MOTOR (200V)

1



104-798

MOTOR (400V20hp)

1

25

41-519

RECEPTACLE - power (380/3/50, mates w/ 41-520)

1



41-8762

RECEPTACLE - power (2/10& after, 32AMP380V)

1

26

41-4163

SWITCH - on/off (partof main harness)

1

27

41-7962

TRANSDUCER - discharge (unitsw/ ETV)

1

28

92-4612

RETAINER - sensor

1

29

40-1118

KIT - SafeGuard Battery Disconnect (optional)

1



92-8695

•  NAMEPLATE - SafeGuard BatteryKit

1



92-8693

•  NAMEPLATE - SafeGuard Reset

1


ELECTRIC COMPONENTS (30 units)

REF

PART#

DESCRIPTION

QTY

1

NSS

CONTROL BOX(see 242G7)

1

2

41-8025

HARNESS - main (30 units)

1

3

203-777

BATTERY - EON (880CCA, see 261E4)

1

4

42-250

CABLE - battery (positive)

1

5

41-7976

CABLE - battery (negative)

1

6

41-8105

SENSOR - RPM

1

7

41-4470

SWITCH - oil level

1



33-4160

•  O-RING - switch

1

8

41-6865

SWITCH - oil pressure

1

9

45-2177

STARTER (see 204G3)

1

10

44-9181

SOLENOID - throttle (see 225E7)

1

11

41-2147

HEATER - air intake(see 204F7)

1

12

41-7962

TRANSDUCER - discharge (unitsw/ ETV)

1

13

41-7960

TRANSDUCER - suction (unitsw/ ETV)

1

14

61-4253

VALVE - throttling (electric, units w/ ETV)

1

15

40-974

KIT - sensor (graded)

2

16

66-8560

SOLENOID - pilot (seerefrigeration grid)

1

17

61-4132

SOLENOID - hot gas(units w/ ETV,see refrigeration grid)

1

18

45-2254

ALTERNATOR (37 amp, see 208F4)

1



41-8461

ALTERNATOR (37 amp, new exchange)

1



845-2254

ALTERNATOR (37 amp, remanufactured)

1

19

42-100

SOLENOID - stop (see 204G2)

1

20

40-975

SENSOR - ungraded

3

21

92-4612

RETAINER - sensor

1

22

41-3669

SWITCH - hpco

1

23

41-6538

SENSOR - water temperature (see 242C0)

1

24

41-7852

MOTOR - damper (see 225D11)

1

25

41-4163

SWITCH - on/off (partof main harness)

1

26

40-1118

KIT - SafeGuard Battery Disconnect (optional)

1



92-8695

•  NAMEPLATE - SafeGuard BatteryKit

1



92-8693

•  NAMEPLATE - SafeGuard Reset

1


COMPONENT MOUNTING

REF

PART#

DESCRIPTION

QTY

1

104-756

MOTOR (400V,see 261E9)

1



104-770

MOTOR (singletemp, 15 hp, see 261E9)

1



104-793

MOTOR (SPECTRUM, 12.5 hp, see 256C9)

1



104-798

MOTOR (Ferryunits, 400V, 20 hp, see 256C9)

1



51-1969

•  TIE ROD - motor

4



55-1669

SCREW - motor

6



55-365

LOCKWASHER

6



55-7020

WASHER - special

6

2

51-1700

KEY - clutch end

1

3

51-1701

KEY - blower end

1

4

93-179

BRACKET - motor

1



55-7350

SCREW - bracket to frame

2



55-6283

LOCKWASHER

2



55-5914

FLATWASHER

2

5

92-6514

BRACKET - harness

1



51-718

SCREW - bracket

4

6

45-2254

ALTERNATOR (37 amp, see 208F4)

1



45-2258

ALTERNATOR (120 amp, see 241C1)

1



55-8586

SCREW - alternator (M10)

1



55-7072

FLATWASHER

4



55-7005

NUT

3



55-6215

SCREW - alternator (M8)

1



55-7727

LOCKWASHER

1



55-7069

FLATWASHER

1

7

203-777

BATTERY - EON (880CCA)

1

8

93-359

BRACKET - battery

1



55-7341

SCREW - bracket

2



55-6988

FLATWASHER

2



55-7066

LOCKWASHER

2

9

92-580

•  ROD - battery (front,L shape)

2

10

41-519

RECEPTACLE - power (380/3/50, mates w/ 41-520)

1



41-8762

RECEPTACLE - power (2/10& after, 32AMP380/400V)

1



99-9052

•  COVER - receptacle

1

11

33-1697

•  GASKET - receptacle

2

12

92-1169

BRACKET - receptacle

1



55-9695

SCREW - bracket

4



55-9763

NUT

4

13

40-1118

KIT - SafeGuard Battery Disconnect (optional)

1


THROTTLE SOLENOID GROUP

REF

PART#

DESCRIPTION

QTY

1

92-6485

BRACKET - solenoid

1



55-5022

SCREW - bracket

4



55-7727

LOCKWASHER

4



55-7069

FLATWASHER

4

2

44-9181

SOLENOID

1



55-7007

NUT - solenoid

4



55-4638

FLATWASHER

4

3

91-3095

BOOT - plunger

1

4

55-2762

BOLT - eye

1



55-1533

NUT

1



55-1800

LOCKWASHER

1

5

11-4266

CLIP - clevis

1

6

13-937

ROD - speed control

1

7

13-383

JOINT - rod (ball)

1

8

92-6486

BRACKET - solenoid

1



55-4998

SCREW - bracket

2



55-7727

LOCKWASHER

4



55-7069

FLATWASHER

4

9

12-925

LEVER - injection control (see 204G2)

1


STARTER ASSEMBLY 12 VOLT (TK486V)

REF

PART#

DESCRIPTION

QTY



45-2177

STARTER (12V)

1

1

41-6508

•  ARMATURE (12V)

1

2

77-2468

•  BEARING

1

3

77-2469

•  BEARING

1

4

41-6509

•  YOKE - assembly

1

5

55-8894

•• SCREW - field coil

4

6

41-6510

•• BRUSH - positive (not for 24V)

2

7

41-6513

•  COVER - rear

1

8

41-6511

•  HOLDER - brush (notfor 24V)

1

9

41-6512

•• SPRING - brush

4

10

41-6510

•• BRUSH (notfor 24V)

2

11

55-8897

•  SCREW - cover

2

12

51-1161

•  BOLT - thru

2

13

41-6518

•  PINION - assembly

1

14

41-6519

•  SHAFT - pinion

1

15

77-2833

•  RETAINER

1

16

41-6520

•  CLUTCH - assembly

1

17

41-6521

•• BEARING - ball

1

18

77-2834

•• BEARING - ball

1

19

41-2156

•  STOPPER - pinion

1

20

41-6514

•  CASE - cover

1

21

41-6515

•  SOLENOID (12V)

1

22

41-6516

•  LEVER

1

23

41-6517

•  COVER - dust

1

24

55-8898

SCREW - starter

2


NOTE:     NOTE: See grid 212B9 for 24 volt starter.

ALTERNATOR (37 AMP)

REF

PART#

DESCRIPTION

QTY



45-2254

ALTERNATOR (TK extended life,37 amp)

1



41-8461

ALTERNATOR (37 amp, new exchange)

1



845-2254

ALTERNATOR (37 amp, remanufactured)

1

1

51-1255

•  NUT

1



51-1254

•  WASHER

1

2

41-6867

•  FAN

1

3

51-1272

•  SCREW - housing

4

4

51-1311

•  SCREW - flange

4

5

41-6886

•  HOUSING - front

1

6

77-2852

•  BEARING - fan end (front)

1

7

41-6869

•  FLANGE - bearing

1

8

41-6875

•  ROTOR

1

9

41-6872

•  STATOR

1

10

41-6870

•  RECTIFIER

1

11

77-2853

•  BEARING - rear

1



77-2851

•  SPACER - bearing

1

12

51-947

•  NUT

1



51-1261

•  INSULATOR

1



51-1265

•  FLATWASHER

1



51-1263

•  LOCKWASHER

1



51-1264

•  NUT

1



51-1266

•  NUT

1

13

51-1257

•  NUT

1



55-1260

•  NUT

1



55-1256

•  LOCKWASHER

1



55-1258

•  FLATWASHER

1

14

41-6866

•  HOUSING - rear

1

15

41-8851

•  BRUSH - set (inclholder)

1

16

51-1312

•  SCREW - brush

1

17

41-6871

•  CAPACITOR

1

18

51-1260

•  NUT

2



51-1259

•  LOCKWASHER

2


NOTE:     NOTE: The TK alternator (45-2254) replaces the Bosch alternator (41-5458), see Grid 101A3.

ALTERNATOR ASSEMBLY (120 AMP)

REF

PART#

DESCRIPTION

QTY



45-2258

ALTERNATOR (Extended life, w/ CW fan)

1



41-8465

ALTERNATOR (Standard life, w/ CW fan)

1



845-2258

ALTERNATOR (Remanufactured, w/ CW fan)

1

1

51-1255

•  NUT

1



51-1254

•  WASHER

1

2

41-6867

•  FAN (CW)

1

3

51-1272

•  SCREW - housing

4

4

51-1311

•  SCREW - flange

4

5

41-6886

•  HOUSING - front

1

6

77-2852

•  BEARING - fan end (front)

1

7

41-6869

•  FLANGE - bearing

1

8

41-6877

•  ROTOR

1

9

41-6874

•  STATOR

1

10

41-9899

•  RECTIFIER

1

11

77-2853

•  BEARING - rear

1



77-2851

•  SPACER - bearing

1

12

51-947

•  NUT

1



51-1261

•  INSULATOR

1



51-1265

•  FLATWASHER

1



51-1263

•  LOCKWASHER

1



51-1264

•  NUT

1



51-1266

•  NUT

1

13

51-1257

•  NUT

1



55-1260

•  NUT

1



55-1256

•  LOCKWASHER

1

14

41-6866

•  HOUSING - rear

1

15

41-8851

•  REGULATOR & BRUSH

1

16

51-1312

•  SCREW - brush

2

17

51-1260

•  NUT

2



51-1259

•  LOCKWASHER

2


CONTROL BOX (plastic box)

REF

PART#

DESCRIPTION

QTY

1

98-8373

CONTROL BOX - plastic

1



51-2014

•  INSERT - threaded (M4)

26



51-2015

•  INSERT - threaded (M6)

9

2

92-8311

•  PIN - hinge

2



51-2019

SCREW - control box to frame

5



55-8893

FLATWASHER

2

3

51-2016

BRACKET - cable tie

1

4

92-8314

BRACKET - cable tie

1



55-9694

SCREW - bracket

3

5

92-8312

PIN - door hinge

4

6

92-8365

COVER - harness

1



55-9761

SCREW - cover

2

7

33-4630

GASKET - cover

1

8

55-6010

PLUG - button

1

9

55-6141

CONNECTOR - harness grip(90 degrees)

1

10

55-9129

CONNECTOR - harness grip(straight)

1



55-2635

NUT - connector

1

11

45-2302

BOARD - controller - SR-2 (before 10/10, see 225D8)

1

12

45-2276

BOARD - interface

1

13

45-2446

BOARD - controller - SR-3 (10/10& after)

1

14

41-7965

HARNESS - main (50 units)

1



41-8025

HARNESS - main (30 units)

1

15

98-8374

DOOR - control box

1

16

33-4629

GASKET - control box door

1

17

51-2019

SCREW - door

6

18

45-2372

CONTROLLER - HMI

1



55-3018

SCREW - controller

4



55-2086

FLATWASHER

4

19

33-3628

GASKET - controller

1

20

92-6511

HARNESS - communication

1



51-2018

SCREW - receptacle

4



55-9696

NUT

4

21

92-3283

CAP - dust (6 pin)

1

22

92-3067

CAP - dust (5 pin)

1

23

NSS

TRAY - high voltage

1



55-9694

SCREW - tray

4

24

92-7975

COVER - high voltagetray (plastic)

1



55-9694

SCREW - cover

4

25

92-8309

COVER - highvoltage tray (usewith unit equipped with TracKing, see 244C9)

1

26

42-164

CABLE - USB-A SR-3

1


HIGH VOLTAGE TRAY ASSEMBLY

REF

PART#

DESCRIPTION

QTY

1

92-3287

TRAY - high voltage (190-380/3/50)

1



92-8366

TRAY - high voltage(for plastic control box, 190-380/3/50)

1



92-6940

TRAY - high voltage (200/3/50-60, Japan)

1

2

41-5630

CONTACTOR - motor (12volt coil)

2



41-5631

CONTACTOR - motor (24volt coil)

2



41-9391

CONTACTOR - motor (forplastic control box, 190-380/3/50)

2



55-9693

SCREW - contactor

2

3

44-9081

CONTACTOR - heater (optional on SLX, see grid 226A0)

1

4

41-4800

SELECTOR - phase

1



55-9695

SCREW - selector

2

5

41-7563

BRACKET - overload relay(190-380/3/50, before 9/12)

1



41-6096

BRACKET - overload relay(190-380/3/50, 9/12 &after)

1



41-738

BRACKET - overload relay(200/3/50-60, Japan)

1



55-9694

SCREW - bracket

2

6

41-7564

RELAY - overload (190-380/3/50, before 9/12)

1



41-6409

RELAY - overload (190-380/3/50, 9/12 & after)

1



41-6095

RELAY - overload (200/3/50-60, Japan)

1

7

41-5683

HARNESS - high voltage (SL)

1



41-9392

HARNESS - high voltage (SLX)

1



41-5745

•  CONNECTOR (6 pin)

1

8

41-4122

HARNESS - power (SL)

1



41-8026

HARNESS - power (SLX)

1



41-8189

HARNESS - power (SLX,Japan)

1

9

41-2274

HARNESS - heater

1


DOORS AND PANELS, UPPER SECTION

REF

PART#

DESCRIPTION

QTY

1

98-7914

COVER - top

1

2

33-3338

SEAL - door

1

3

92-7557

BRACKET - bulkhead

2

4

51-1746

SCREW - cover

7

5

98-9038

PANEL - upper

1



33-4757

•  TAPE - anti-abrasive

1

6

98-9039

PANEL - belts

1



33-4756

•  TAPE - anti-abrasive

1



55-9761

SCREW - panel

8



55-7740

WASHER - special

8

7

98-9040

GRILLE - condenser

1



33-4755

•  TAPE - anti-abrasive

1



51-718

SCREW - panel &grille (M6 X 16)

A/R



55-9761

SCREW - panel &grille (M6 X 25)

A/R

8

92-8923

PANEL - blockoff (top)

1

9

92-8922

PANEL - blockoff (bottom)

1



55-7032

SCREW - panel

4



55-7033

FLATWASHER

4

10

99-214

BOLT - unit

8



55-5234

WASHER

8



55-3686

NUT

8

11

33-4445

STRIP - foam (1 meter lg,cut to length)

A/R

12

92-7583

SCREEN - top (optional)

1



55-7372

SCREW - screen

2



55-7075

FLATWASHER

2



55-7354

NUT

2

13

92-9453

BRACKET - skin mount(93 mm tall)

6

14

92-9454

BRACKET - skin mount(83 mm tall)

2

15

92-7421

CLIP - panel (pinetree)

4

16

90-440

KIT - snow screen(optional)

1



55-8224

NUT

4



55-8216

FLATWASHER

4


DOORS, BOTTOM SECTION (5/10 & after micro
channel cond coil)

REF

PART#

DESCRIPTION

QTY

1

98-7912

PANEL - lower right

1

2

33-4405

INSULATION - panel (rightside)

1

3

98-8185

DOOR - engine (rightside)

1

4

33-4406

INSULATION - engine (rightside)

1

5

98-8186

DOOR - engine (left side)

1



91-5057

BUMPER - door

1

6

33-4407

INSULATION - engine (leftside)

1

7

98-8512

DOOR - control box (SLX)

1



98-9070

DOOR - control box (SLXe)

1

8

33-4446

SEAL - HMI

1

9

92-6522

LATCH - door

1

10

92-6774

•  LOCK - door

1

11

33-1435

BUMPER - latch handle

1

12

91-2704

RETAINER - door latch

2



51-1689

SCREW - latch

4

13

92-6524

STRIKE - door (upper)

1

14

92-6525

NUTSTRIP - latch

2

15

99-9973

SPRING - latch (cw top)

1

16

99-9974

SPRING - latch (ccw bottom)

1

17

92-6518

STRIKE - door (lower)

1



55-1173

LOCKWASHER

1



55-7072

FLATWASHER

1



51-1996

NUT

1

18

92-6518

BUMPER - door

1

19

33-4605

INSULATION - engine (curbside)

1

20

33-4445

STRIP - foam (1 meter lg,cut to length)

A/R

21

33-4447

SEAL - door

1

22

92-7203

BRACKET - door

1



92-7204

ANGLE - bracket

1

23

92-6877

HINGE - front doors

4



51-718

SCREW - hinge (M6)

8



51-1828

SCREW - hinge (M5)

8

24

90-451

KIT - hinge (leftside, includes 25 & 27)

2

25

92-9408

•  HINGE - left side

2

26

92-6520

HINGE

4

27

93-101

RETAINER - hinge

4

28

90-452

KIT - hinge (rightside, includes 27 & 28)

2

29

92-9409

•  HINGE - right side

2

30

98-9074

PANEL - bottom

1



51-1964

SCREW - cover

26

31

33-4852

STRIP - foam (100 ft, cut to length)

A/R


NAMEPLATES

REF

PART#

DESCRIPTION

QTY

1

93-345

NAMEPLATE - TK logo(76 x 86)

1



93-346

NAMEPLATE - TK logo(212 x 241)

1

2

93-347

NAMEPLATE - SLXe 100

1

3

93-354

NAMEPLATE - SLXe 200

1

4

93-355

NAMEPLATE - SLXe 300

1

5

93-380

NAMEPLATE - SLXe 400

1

6

93-356

NAMEPLATE - SLXe SPECTRUM

1

7

93-357

NAMEPLATE - SLXe Ferry

1

8

93-358

NAMEPLATE - SLXe Whisper

1

9

92-7228

NAMEPLATE - IR

1

10

92-8313

NAMEPLATE - CargoWatch

1

11

93-344

NAMEPLATE - USB

1

12

91-1086

HOLDER - records

1

13

92-4321

NAMEPLATE - voltage

1

14

92-5712

NAMEPLATE - On-Off

1

15

92-6530

NAMEPLATE - Engine Speed(SLX 100/200)

1

16

92-6643

NAMEPLATE - Engine Speed(SLX 400, SPECTRUM)

1

17

92-7104

NAMEPLATE - Engine Speed(SLX Whisper)

1

18

99-7834

NAMEPLATE - Caution

1

19

91-5882

NAMEPLATE - R404A

3

20

91-5886

NAMEPLATE - Refrigerant R404A

1

21

92-5374

NAMEPLATE - Sound Power(103 Ldb)

1



92-2923

NAMEPLATE - Sound Power(99 Ldb)

1



92-7422

NAMEPLATE - Sound Power(98 Ldb)

1



93-343

NAMEPLATE - Sound Power(95 Ldb)

1

22

92-6818

NAMEPLATE - Pressure Vessel(receiver tank)

1



92-6819

NAMEPLATE - Pressure Vessel(condenser coil)

1



92-6820

NAMEPLATE - Pressure Vessel(heat exchanger)

1



92-6821

NAMEPLATE - Pressure Vessel(accumulator tank)

1



92-6822

NAMEPLATE - Pressure Vessel(evaporator coil)

1

23

92-7103

NAMEPLATE - Caution, Fan

1

24

99-8421

NAMEPLATE - Caution, HighVoltage

1



99-9856

NAMEPLATE - Caution,High Voltage (multi-language)

1


DOWNLOAD CABLES (UNITS w/TG VI & SR-2/SR-3
MICROPROCESSOR)

REF

PART#

DESCRIPTION

QTY

1

204-1040

CABLE - data (5 pin Deutsch, 9 pin D PC, 20 ft)

1

2

44-9417

CABLE - data (15 pin D, 9 pin D PC, 20 ft)

1



44-9418

CABLE - data (15 pin D, 9 pin D PC, 50 ft)

1

3

204-918

ADAPTER - cable (15pin D PC to 5 pin Deutsch)

1

4

44-9563

CABLE - printer (15 in D, 25 pin D PC, 20 ft)

1

5

204-1027

CABLE - data (5 pin Deutsch, 25 pin D PC, 6 M)

1

6

204-1018

CABLE - DAS/HMI printer(6 pin Deutsch, 25 pin D, 20 ft)

1

7

204-1031

CABLE - adapter(for printer cables44-9563, 204-1026 & 204-1027)

1

8

204-1026

CABLE - DAS/HMI printer(6 pin Deutsch, 9 pin D, 20 ft)

1

9

204-1028

CABLE - DAS/HMIdata (6 pinDeutsch, 9 pinD printer w/ dc power, 20 ft)

1

10

204-844

PRINTER (12V,see 192A1)

1

11

204-1020

PRINTER - hand held(12V, see 192A2)

1

12

204-1109

ADAPTER - serial port to USB

1

13

41-8132

CABLE - RS232 Bluetooth adapter

1

14

N/A

COMPUTER - Windows based

1


NOTE:     NOTE: Red cables are printer cables.Black or gray cables are download cables.

TracKing GPRS (w/ micro channel coil)

REF

PART#

DESCRIPTION

QTY



40-1095

KIT - TracKing (EU)

1



40-1101

KIT - TracKing (UK)

1



40-1107

KIT - TracKing (noSIM card)

1

1

41-7377

•  ANTENNA (6m)

1

2

92-6878

•  BRACKET - antenna

1



51-1768

•  MOUNT - cable

6



55-2332

•  BANDWRAP

6



55-9693

•  SCREW - bracket

4



55-9763

•  NUT

4

3

41-9514

•  MODULE - TracKing EU SIM

1



41-9515

•  MODULE - TracKing UK SIM

1



41-9517

•  MODULE - TracKing (no sim card)

1



55-3669

•  RIVET - module

4



55-5960

•  WASHER

4

4

92-8950

•  PLATE - module

1

5

41-9823

•  HARNESS - module to pc board

1

6

92-8894

•  NAMEPLATE - Danger TracKing

1


DOOR SWITCH - LOW PROFILE

REF

PART#

DESCRIPTION

QTY

1

40-1135

KIT - door switch(3 wire)

1

2

40-907

KIT - door switch(2 wire)

1



55-8421

SCREW - door switch(1 in)

2



51-1321

SCREW - door switch(3/4 in)

2



55-2001

FLATWASHER

4


REAR VIEW THERMOMETER, TEMP WATCH

REF

PART#

DESCRIPTION

QTY

1

40-916

THERMOMETER - forward view (Temp Watch,15 ft sensor harness)

1



40-917

THERMOMETER - rear view (15 ft sensor harness)

1



40-918

THERMOMETER - rear view (60 ft sensor harness)

1

2

91-8733

•  BRACKET - remote light

1

3

91-9274

•  SUN VISOR

1



55-5640

•  SCREW - sheet metal(#10)

11



55-2001

•  FLATWASHER

16



55-5294

•  CLAMP - harness

5



55-2330

•  BANDWRAP

A/R

4

40-1119

KIT - temperature display (left side, degrees F)

1



40-1120

KIT - temperature display (left side, degrees C)

1

5

40-1121

KIT - temperature display (right side, UK,degrees C)

1

6

NSS

•  DISPLAY

1

7

55-5294

•  CLAMP - harness

5



51-321

•  RIVET

5


STATUS/TEMPERATURE/FUEL LEVEL DISPLAYS

REF

PART#

DESCRIPTION

QTY

1

40-1109

KIT - status/temp/fuel leveldisplay (left side,w/fuel gauge)

1

2

40-1110

KIT - status/temperature/fuel leveldisplay (left side)

1

3

40-1111

KIT - status/temperature/fuel leveldisplay (right side)

1

4

40-1112

KIT - status/temperature/fuel leveldisplay (flush mount)

1

5

40-1070

KIT - status/fuel leveldisplay (left side,w/fuel gauge)

1

6

40-1068

KIT - status/fuel leveldisplay (left side)

1

7

40-1069

KIT - status/fuel leveldisplay (right side)

1

8

40-1071

KIT - status/fuel leveldisplay (flush mount,w/fuel gauge)

1

9

40-1067

KIT - status/fuel leveldisplay (flush mount)

1

10

40-980

KIT - status display (left side)

1



40-984

KIT - status display(left side, UK, T-Series after11/11)

1



350-4665

KIT - status display (Carrier units only)

1

11

40-981

KIT - status display(flush mount, TSA)

1



40-989

KIT - status display(flush mount, EMEIA)

1

12

40-996

KIT - status display(right mount, Australia)

1



40-985

KIT - status display (right side, EMEIA)

1

13

40-1119

KIT - temperature display(left side, degrees F)

1



40-1120

KIT - temperature display (left side, degrees C)

1

14

40-1121

KIT - temperature display (right side, UK,degrees C)

1

15

41-9024

DISPLAY - face platedecal (status/temp/fuel leveldisplay)

1

16

41-9025

DISPLAY - face platedecal (status/fuel leveldisplay)

1

17

41-9023

DISPLAY - face platedecal (status display)

1

18

41-6742

HARNESS - fuse (multitemp units)

1

19

41-1932

FUSE (1 amp)

1

20

40-1160

KIT - fuel level(flushmount)

1

21

40-1165

KIT - fuel level(left side)

1


FLUSH MOUNT CONTROLLER

REF

PART#

DESCRIPTION

QTY



40-1008

KIT - control box

1

1

45-2107

•  CONTROLLER - flush mount(single temp)

1



55-3443

•  SCREW - controller

1

2

90-335

•  KIT - box, remotecontroller

1

3

41-7032

•  HARNESS - controller to evap

1

4

41-8190

•  HARNESS - control box to evaporator

1

5

92-6682

•  NAMEPLATE - Rear RemoteControl

1

6

41-6586

HARNESS - evaporator

1


REMOTE INDICATOR LIGHT

REF

PART#

DESCRIPTION

QTY

1

40-915

KIT - remote statuslight

1

2

55-5294

•  CLAMP - harness

5



55-5640

•  SCREW - clamp

5



55-2001

•  FLATWASHER

5



55-2330

•  BANDWRAP

8



55-396

•  LOCKWASHER - internal tooth

1



55-3941

•  SCREW - sheet metal

1

3

41-5841

•  HOLDER - fuse

1

4

41-1932

•  FUSE (1 amp)

1

5

91-9274

•  SUN VISOR

1

6

91-8733

•  BRACKET - remote light

1



55-5640

•  SCREW - bracket

4



55-2001

•  FLATWASHER

4


CargoPrinter

REF

PART#

DESCRIPTION

QTY



40-1083

CargoPrinter

1

1

90-387

•  COVER - CargoPrinter

1

2

41-9363

•  SWITCH - on/off

1

3

41-9317

•  KEYPAD &PRINTER

1

4

92-8491

OPERATING INSTRUCTIONS - English

1



92-8492

OPERATING INSTRUCTIONS - Spanish

1



92-8493

OPERATING INSTRUCTIONS - French

1



92-8494

OPERATING INSTRUCTIONS - Italian

1



92-8495

OPERATING INSTRUCTIONS - German

1



92-8496

OPERATING INSTRUCTIONS - Polish

1

5

92-8696

NAMEPLATE - CargoPrint

1

6

41-6580

HARNESS - printer

1

7

205-256

PAPER (packof 10)

1


TAIL LIFT CHARGER

REF

PART#

DESCRIPTION

QTY



40-1158

KIT - tail liftcharger

1

1

92-9557

•  BOX - tail liftcharger

1

2

51-2183

•  CONNECTOR - harness grip

1

3

55-6409

•  CONNECTOR - harness grip

4

4

33-1178

•  GROMMET (3/16id)

2

5

92-9560

•  PANEL

1



51-1457

•• STUD - self clinching

13



55-7042

•  NUT - panel

6

6

42-379

•  HOLDER - fuse, mini

1



55-9763

•  NUT - holder

2

7

55-548

•  CLAMP (.437dia)

1



55-3065

•  CLAMP (.5 dia)

2



55-9763

•  NUT - clamp

3

8

44-8680

•  FILTER - power

1



55-9763

•  NUT - filter

2

9

41-7275

•  FUSE (30 amp)

1



41-7420

•  FUSE (50 amp)

1



41-3666

•  FUSE (60 amp)

1

10

42-380

•  HOLDER - fuse, maxi

3

11

45-2456

•  CHARGER

2



55-9763

•  NUT - charger

8

12

99-4976

•  STRIP - gasket (50 ft)

A/R

13

92-9558

•  COVER

1



51-718

•  SCREW - cover

6

14

92-9559

•  NAMEPLATE - Tail Lift Charger

1

15

92-7367

•  NAMEPLATE - IR Logo

1

16

40-1012

KIT - battery cable(30 ft. 4ga,ordered seperately)

A/R



40-1176

KIT - battery cable(45 ft. 4ga,ordered seperately)

A/R



40-1013

KIT - battery cable(60 ft. 4ga,ordered seperately)

A/R


PLASTIC FUEL TANK

REF

PART#

DESCRIPTION

QTY

1

12-839

TANK - fuel (230L,plastic inc items2 - 5)

1

2

11-9629

•  CAP - fuel

2



11-9726

•• KEY - fuel tank

1

3

11-9599

•  GAUGE - fuel (before6/10)

1



13-1025

•• DIAL - fuel gauge

1



13-1082

•  GAUGE - fuel (6/10& after)

1



13-1083

•• DIAL - fuel gauge

1



33-4818

•• O-RING - gauge to tank

1

4

11-9134

•  VALVE - ball check

1

5

13-1006

•  TUBE - fuel

2



90-351

KIT - fuel tank

1



90-374

KIT - fuel tank(Schwarzmuller)

1



90-392

KIT - fuel tank(for replacing steelfuel tank)

1

6

51-626

•  WASHER - wedge(not required withlonger bracket 98- 8499)

8

7

55-5270

•  FLATWASHER

12

8

55-3686

•  NUT

8

9

55-1670

•  SCREW - bracket

4

10

33-3872

•  STRIP - anti chaffing

2

11

98-6659

•  STRIP - fuel tank

2

12

98-8499

•  BRACKET - hanger (partof kit 90-351)

2



92-7625

•  BRACKET - hanger (partof kit 90-374)

2



92-7626

•  BRACKET - hanger (partof kit 90-392)

2

13

13-794

GAUGE - fuel (electronic)

1

14

41-9222

•  DIAL - fuel (electronic)

1



33-4818

•  O-RING - gauge to tank

1

15

10-243

KIT - sleeve &eyelet

2

16

11-4370

CONNECTOR - fuel line(1/4 straight)

2

17

11-4841

NUT (1/4)

2

18

11-9030

HOSE - fuel (1/4)

A/R

19

13-960

ANTISIPHON (optional, not included withfuel tank)

1

20

41-8131

CONVERTER - fuel level(DAS, optional)

1


DUAL PLASTIC FUEL TANKS

REF

PART#

DESCRIPTION

QTY

1

12-839

TANK - fuel (230L,plastic)

2

2

11-9629

•  CAP - fuel

2



11-9726

•• KEY - fuel tank

1

3

11-9599

•  GAUGE - fuel

1

4

55-4515

FITTING (3/8)

2

5

10-242

KIT - sleeve &eyelet (3/8)

2

6

11-4941

NUT (3/8)

2

7

11-4372

HOSE - fuel (3/8)

A/R

8

11-4860

ELBOW (1/4)

2

9

10-243

KIT - sleeve &eyelet (1/4)

2

10

11-4841

NUT (1/4)

2

11

11-4367

HOSE - fuel (1/4)

A/R

12

98-6659

STRIP - fuel tank

4

13

33-3872

STRIP - anti chaffing

4

14

51-626

WASHER - wedge

16

15

55-5270

FLATWASHER

24

16

55-3686

NUT

16

17

55-1670

SCREW - bracket

8

18

98-8499

BRACKET - hanger

4


FUEL TANK (EMEIA, 18 IN DIAMETER)

REF

PART#

DESCRIPTION

QTY

1

12-451

TANK - fuel (50 gallon, steel)

1

2

11-2593

•  GAUGE - fuel (mechanical)

1

3

11-5450

•• DIAL - fuel gauge

1

4

33-4818

•• O-RING - gauge to tank

1

5

11-5946

•  CAP - fuel tank(non-vented, non-fused)

1

6

33-381

•• GASKET - cap

1

7

55-2313

•  BALL - check

1

8

11-5331

•  TUBE - fuel pickup

2

9

11-5339

•  PLUG - fuse

1

10

55-5617

•  VENT

1

11

11-9741

•  COVER - port

1

12

33-3878

•  GASKET - cover

1



55-1510

•  SCREW - cover (10-32)

5



55-431

•  FLATWASHER

5



55-1511

•  LOCKWASHER

5

13

98-2315

CHANNEL - fuel tank

2

14

98-4170

BRACKET - channel

8

15

98-2316

STRAP - hanger

2

16

55-2252

SCREW (1/2-13)

8



55-5270

FLATWASHER (1/2)

12



55-3686

NUT (1/2-13)

12

17

33-4479

STRIP - chafing (4 in lg)

2



99-9701

STRIP - chafing (67 in lg)

2

18

99-1596

NAMEPLATE - Diesel Fuel Only

1

19

11-4370

CONNECTOR - hose fitting (1/4)

1

20

10-243

KIT - sleeve &eyelet (1/4)

1

21

11-4841

NUT (1/4)

1

22

11-4367

HOSE (1/4od x 35 ft lg)

1

23

11-8982

FITTING (3/8)

1

24

10-242

KIT - sleeve &eyelet (3/8)

1

25

11-4941

NUT (3/8)

1

26

11-4372

HOSE (3/8od x 35 ft lg)

1

27

13-878

ANTISIPHON

1

28

13-1019

GAUGE - fuel (electronic)

1

29

41-9223

•  DIAL - gauge

1

30

99-1596

NAMEPLATE - Diesel Fuel Only

1


FUEL FILTER (Optional)

REF

PART#

DESCRIPTION

QTY



10-415

KIT - fuel/water filter(with primer pump)

1

1

13-994

•  FILTER &GASKET

1

2

13-995

•  BOWL

1

3

51-1865

•  ELBOW - fuel

2

4

51-1864

•  PLUG

2

5

92-7963

•  NAMEPLATE - Fuel SystemBleeding

1

6

13-1197

•  VALVE

1

7

204-1913

TOOL - wrench

1


NOTE:     NOTE: EMEIA is usingKit 10-415, not 10-429.
NOTE:     NOTE: The wrench 204-1913is NOT part of Kit 10-415 or Kit 10-429.

FUEL FILTER (Optional w/ electric heater)

REF

PART#

DESCRIPTION

QTY



10-431

KIT - fuel/water filter(with primer pump& electric heater)

1

1

10-430

•  FILTER &HEAD

1

2

13-1086

•• FILTER

1

3

NSS

•  HEATER - fuel (12/24V)

1

4

51-1865

•  ELBOW - fuel

2

5

51-1864

•  PLUG

2

6

92-7963

•  NAMEPLATE - Fuel SystemBleeding

1

7

41-9505

•  CABLE

1

8

41-2978

•  FUSE (20 amp)

1

9

41-4740

•  HOLDER - fuse

1

10

41-894

•  RELAY

1

11

13-1197

•  VALVE

1

12

204-1913

TOOL - wrench

1


© All Rights Reserved
refxolod.ru
Made on
Tilda
